Philips 190V5FB Specifications

19 inch LCD Monitor
Commercial Specifications
Picture/ Display
• LCD panel type 1280 x 1024 pixels,
Anti-glare Polarizer,
RGB vertical stripe
• Panel size 19"/ 48 cm
• Effective viewing area 376.3 x 301.1 mm
• Pixel pitch 0.294 x 0.294 mm
• Brightness (nits) 240
• Contrast ratio 500:1
• Display colors 16.2 M
• Viewing angle (C/R > 5) - Horizontal : 160°
- Vertical : 160°
• Response time 12 ms
• White chromaticity, 6500º K x = 0.313 / y = 0.329
• White chromaticity, 9300º K x = 0.283 / y = 0.297
• Maximum resolution 1280 x 1024 @ 75Hz
• Recommended resolution 1280 x 1024 @ 60Hz
• Factory preset modes 15 modes
• User definable modes 14 modes
• Horizontal scanning frequency 30 - 82 KHz
• Vertical scanning frequency 56 - 76 Hz
• sRGB Yes
Connectivity
• Signal input Analog (VGA)
• Video sync input signal Composite sync,
Separate sync,
Sync on green
Convenience
• Convenience enhancements
• Monitor controls
• OSD languages
• Other convenience features
• Plug & Play compatibility
• Regulatory approvals
• Tilt
• VESA mount
Accessories
• Included accessories
• Optional accessories
• User manual
Dimensions
• Depth (with base)
• Height (with base)
• Width (with base)
• MTBF
• Relative humidity
• Temperature range (operation)
• Temperature range (storage)
• Weight
Power
• Complies with
• Consumption
• Off mode
• Power LED indicator
• Power supply
Trademarks owned by Royal Philips Electronics
2004 © Royal Philips Electronics - All rights reserved
As an Energy Star partner, Philips has determined that
this product meets the Energy Star guidelines for
energy efficiency.
Microsoft and Windows are registered trademarks of
Microsoft Corporation.
All data subject to change without notice
Release date: March 2005, v.2
www.philips.com
On-screen display
Auto, Brightness control,
Left/Right, Menu (OK),
Power On/Off, Up/Down
English, French, German,
Italian, Simplified Chinese,
Spanish
Kensington lock compatible
DDC/CI, sRGB,
Windows 98/ME/2000/XP
CE Mark, E2000, NUTEK,
Energy Star, SEMKO,
TCO'99, TÜV/GS, TÜV-Ergo,
FCC-B, UL, CSA
-5° to 25°
100 mm x 100 mm
AC power cord, VGA cable
Super Ergo base
Yes
235 mm
419 mm
425 mm
50,000 hrs
20 % - 80 %
5°C to 35°C
-20°C to 60°C
5.8 kg
E2000, Energy Star,
NUTEK
34 W (Typical)
1 W
Operation, green;
Stand by/Sleep,
amber
Built-in, 90-264 VAC, 50/60 Hz
190V5FB
