My TV has several scart sockets. Which one
should I use?
Select that scart socket which is suited for the
video output as well as for the video input.
My TV offers me a selection menu for the
scart socket.
Select 'TV' as a connection source of this scart
socket.
6.If the connection was properly made
6.
and your TV was automatically switched
to the programme number for the scart
socket, you will see the following picture:
PLEASE CONNECT AERIAL OR
CABLE TO THE VCR
THEN...
PUSH P + KEY
OR...
FOR PLAY ONLY - PUSH PLAY
Then, read the paragraph 'Preparation for use' in the
chapter 'Installing your video recorder'.
My screen is empty
Many TVs are switched to the programme num-
ber for the scart socket by way of a control sig-
nal sent through the scart cable.
If the TV does not automatically switch to the
scart socket programme number, manually
change to the corresponding programme num-
ber on your TV (see your TV's operating instruc-
tions).

Connecting without a scart cable

Have the following cables ready:
an aerial cable.
1.Switch off your TV.
1.
2.Remove the aerial
2.
cable plug from the
aerial input socket of
the TV. Insert it into
the AERIAL at the
back of the video
recorder.
3.Insert one end of the
3.
supplied aerial cable
into the RF OUT at
the back of the video
recorder and the
other end into the
aerial input socket at
the back of the TV.
4.Insert AC cable into the wall socket.
4.
5.Switch on your TV and select the programme
5.
number used for video playback on your TV
set (see your TV's operating instructions).
You can find more details in chapter 'Preparation
for use.

Connecting additional devices

You can connect additional devices such as
decoders, satellite receivers, camcorders, etc. to
the socket AV2(DECODER).
AERIAL
RF OUT
3
6.Select this programme number and manually
6.
start the TV's channel search as if you wanted
to save a new TV channel until the next
screen appears.
PLEASE CONNECT AERIAL OR
CABLE TO THE VCR
THEN...
PUSH P + KEY
OR...
FOR PLAY ONLY - PUSH PLAY
I do not see the picture
* Check the cable connections.
* Repeat the channel search on your TV.
7.Save this programme number setting on your
7.
TV for video recorder operation.
Programme number for video recorder oper-
ation
You have now saved a programme number for
use by your video recorder as you would a reg-
ular TV channel. This programme number must
now be used in future for video recorder play-
back ('video recorder' TV channel).
AV2 ( DECODER )
