- Page 1 OWNER'S MANUAL 66CM WIDE SCREEN LCD TV/MONITOR MODEL: TFTV665UBK N111 PALSONIC CORPORATION PTY LTD 1 JOYNTON AVENUE WATERLOO NSW 2017 AUSTRALIA TEL: (02) 9313 7111 FAX: (02) 9313 7555 www.palsonic.com.au PALSONIC CUSTOMER SERVICE TELEPHONE AUSTRALIA: 1300 657 888...
-
Page 2: Table Of Contents
Table of Contents Important Safety Precautions ....................... Preparations ............................Identification of Controls ........................Connections ............................Basic Operations ..........................Memorising the Channels ........................Setting Picture ............................Setting Sound ............................Setting Advanced ..........................Parental Control ............................ Adjusting In-Screen Display ......................... Adjusting in PC (VGA/YPBPR) Mode ....................Troubleshooting ............................ -
Page 3: Important Safety Precautions
Important Safety Precautions Electrical energy can perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety. But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. - Page 4 Important Safety Precautions (continued) 12. Stand---Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. Do not place the product on an unstable trolley, stand, tripod or table. Placing the product on an unstable base can cause the product to fall, resulting in serious personal injuries as well as damage to the product.
- Page 5 Important Safety Precautions (continued) 22. Power source---This product is intended to be supplied by a listed power supply indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the cable system.
-
Page 6: Preparations
Preparations Using the Remote Control Use the remote control by pointing it towards the remote sensor window of the set. Objects between the remote control and sensor window may prevent proper operation. Note: the illustration is for your reference only, the remote sensor may locate differently with different model. - Page 7 Preparation (continued) To open or close the back cover Push downward and then pullout the cover carefully to remove the cover. Before you connect external devices with the unit, please remove the Back Cover first. After you finish connecting, aim the Hook toward the Locating groove, then carefully push the Cover until the Cover locks in place with a click.
-
Page 8: Identification Of Controls
Identification of Controls Main Unit Power Switch VOL+ VOL- MENU INPUT 1. POWER Press this button to turn the unit ON from STANDBY mode. Press it again to turn the set back to STANDBY. 2. Power Indicator 3. Remote Sensor 4. - Page 9 Identification of Controls (continued) Main Unit 1. HDMI interface 2. VGA input/Audio in Connect to the VGA /audio output sockets on your PC. 3. COM port For service only. The user cannot operate the unit through the COM port. 4. Component inputs Connect to the component and audio output sockets of a DVD player or Set-Top Box.
- Page 10 Identification of Controls (continued) Remote Control POWER Turn the unit on or off MAG.C To demo magic picture ADJUST To rectify the picture automatically in VGA mode STILL to freeze current picture CH+/- ( ), VOL+/- ( ), MENU CH+/- ( To select channels upwards or downwards: to move upwards or downwards in menu operation VOL+/- (...
-
Page 11: Connections
Connections Cautions before connecting Carefully check the terminals for position and type before making any connections. The illustration of the external equipment may be different depending on your model. Loose connectors can result in image or colour problems. Make sure that all connectors are securely inserted into their terminals. - Page 12 Connections (continued) Connect a Camcorder Video cable Audio cable Cables are often colour-coded to connectors. Connect red to red, white to white, etc. How to connect: Connect the Audio/Video cables between the Audio (L/R) Video jacks on the unit and camcorder. To playback Camcorder 1.
- Page 13 Connections (continued) Connect a DVD player Video cable Audio cable Cables are often colour-coded to connectors. Connect red to DVD player red, white to white, etc. How to connect a DVD Player using Component Video Connections: Connect the Video cable between the Y, Cb/Pb, Cr/Pr input jacks on the unit and Y, Pb, Pr output jacks on the DVD player. Connect the Audio cable between the AUDIO input jack on the unit and AUDIO output jacks on the DVD player.
- Page 14 Connections (continued) Connect a HDMI device HDMI cable Device with HDMI jack How to connect: Connect the HDMI cable between the HDMI input jacks on the unit and HDMI output jacks on the product. Note: If the external device has DVI output only, use a DVI to HDMI adapter cable to connect to the HDMI terminal. Connect the audio cable to the VGA AUDIO IN jack on the TV rear.
- Page 15 Connections (continued) Connect a VCR (for recording) or external amplifier Video Audio cable cable Audio Cables are often colour-coded cable to connectors. Connect red to red, white to white, etc. VCR for recording To Audio inputs External Amplifier Rear of the VCR How to connect: Connect the Audio/Video cables between the Audio (L/R) Video jacks on the unit and VCR.
-
Page 16: Basic Operations
Basic Operations Turning the Unit On and Off Turning On Insert the power cord into the wall outlet, press the Power Switch on the unit to power on. If the unit is in STANDBY mode, press the Power button on the remote control to turn on the unit. -
Page 17: Changing Channels
Basic Operations (continued) Changing Channels Using the Channel Buttons (CH+ or CH-) Press the CH+ or CH- to change channels. When you press the CH+ or CH-, the unit changes channels in sequence. You will see all the channels that the unit has memorised. You will not see channels that were skipped. -
Page 18: Memorising The Channels
Memorising the Channels Your LCD TV can memorise and store all of the available channels. After the available channels are memorised, use CH+/- to scan through the channels. Searching Channels Automatically Press MENU to display the menu main page. Press repeatedly to select TV-CHANNEL menu, and TV-CHANNEL COLOR SYSTEM... -
Page 19: Manual Fine Tuning
Memorising the Channels (continued) Manual Fine Tuning Press MENU to display the menu main page. Press repeatedly to select TV-CHANNEL menu, and press to access. Press repeatedly to select CHANNEL SORT item, and press to access. TV-CHANNEL CURRENT CH SKIP Press to select FINE TUNING item. -
Page 20: Editing Channels
Memorising Channels (continued) Editing Channels The EXCHANGE function is for you to arrange channel order as you wish. Navigate to the CHANNEL SORT submenu. Highlight the CURRENT CH item, use to select a channel number TV-CHANNEL you want to exchange. CURRENT CH SKIP TARGET CH... -
Page 21: Setting Picture
Setting Picture Customising the Picture Press MENU to display the PICTURE menu, and press to access. PICTURE PERSONAL PICTURE MODE Within the menu, use to navigate or adjust. CONTRAST BRIGHTNESS SATURATION Press MENU button repeatedly to exit the menu. SHARPNESS WARM COLOR MODE FULL... -
Page 22: Setting Sound
Setting Sound Adjusting the Volume Using the volume buttons (VOL+ and VOL-) Press the VOL + or VOL- to increase or decrease the volume. Using the MUTE button At any time, you can temporarily cut off the sound using the MUTE button. Press the MUTE button and the sound cuts off. -
Page 23: Setting Advanced
Setting Advance Setting Clock Time Making use of this function can set the current time for the TV. Press MENU to display the menu main page. ADVANCE Press repeatedly to select ADVANCE menu, and press to access. 14:16 CLOCK --:-- ON TIMER Then the [CLOCK] item will be highlighted automatically. -
Page 24: Setting Sleep Timer
Setting Advance (continued) Setting Sleep Timer Making use of this function allows you to have the set automatically turn off at a preset time. Press MENU to display the menu main page. Press repeatedly to select ADVANCE menu, and press to access. -
Page 25: Parental Control
Parental Controls The Parental Control function enables parents to prevent their children from watching inappropriate programs on TV. To use Parental Control function, you first need to set your password. Setting Password Press MENU to display the menu main page. ADVANCE Press repeatedly to select ADVANCE menu, and press... -
Page 26: Locking Or Unlocking Tv Channels
Parental Contol (continued) Setting Channel Control On or Off Within the PARENT CONTROL submenu, press repeatedly to highlight the CHANNEL CONTROL item. ADVANCE to select ON or OFF. CHANGE PIN ---- KEY LOCK OTHER SOURCE CHANNEL CONTROL When the CHANNEL CONTROL item is set to ON, the AUTO SCAN, CHANNEL SELECT BLOCK SELECT MANUAL SEARCH and CHANNEL SORT items cannot be operated,... -
Page 27: Adjusting In-Screen Display
Adjusting On-Screen Display Adjusting OSD Position Press MENU to display the menu main page. Press repeatedly to select SYSTEM menu, and press to access. SYSTEM OSD LANGUAGE ENGLISH OSD H-POSITION Press repeatedly to select OSD H-POSITION or OSD V-POSITION item. OSD V-POSITION OSD HALFTONE OSD DURATION... -
Page 28: Adjusting In Pc (Vga/Ypbpr) Mode
Adjustment in PC (VGA)/YPBPR Mode Adjusting the Picture Press MENU to display the PICTURE menu, and press to access. PICTURE PICTURE MODE USER CONTRAST BRIGHTNESS Within the menu, use to navigate or adjust. COLOR MODE FULL SCALE Press MENU button repeatedly to exit the menu. : SEL : ADJ : EXIT... -
Page 29: Troubleshooting
Troubleshooting Before calling for repair service, check the following items for possible remedies to an encountered symptom. Symptoms Check item "Ghost" or double images This may be caused by obstruction to the antenna due to high rise buildings or hills. Using a highly directional antenna may improve the picture. No power Check that the AC power cord is plugged into the mains socket. -
Page 30: Care And Maintenance
Care and Maintenance LCD Display panel information Important Information Regarding Use of Video Games, Computers, Captions or Other Fixed Image Displays. The extended use of fixed image program material can cause a permanent "shadow image" on the LCD panel. This background image is viewable on normal programs in the form of a stationary fixed image. This type of irreversible LCD panel deterioration can be limited by observing the following steps: A. -
Page 31: Specifications
Specifications Type: LCD TV Display Size diagonal: 26" Power Supply: AC 100-240V 50/60Hz Power Consumption: 100W Dimensions: 746 (W) x 548 (D) x 215 (H) (mm) Unit Weight (kg): TV system: PAL-BG, NTSC (AV) Design and specification are subject to change without notice. - Page 32 PALSONIC CORPORATION PTY LTD 1 JOYNTON AVENUE WATERLOO NSW 2017 AUSTRALIA TEL: (02) 9313 7111 FAX: (02) 9313 7555 www.palsonic.com.au PALSONIC CUSTOMER SERVICE TELEPHONE AUSTRALIA: 1300 657 888 604-L26HU193-00 Ver.1.0...
