  • Page 1 Service Parts Diagrams For Model: UF55 UF55w UF55-RFK-500...
  • Page 2 © 2011 SMART Technologies ULC. All rights reserved. SMART Board, smarttech, Unifi and the SMART logo are trademarks or registered trademarks of SMART Technologies ULC in the U.S. and/or other countries. All other third-party product and company names are for identification purposes only and may...
  • Page 3 Service Parts Diagrams for the UF55, UF55w and UF55-RFK-500 Identifying Your Product Using the Serial Number ..............1 Ordering Parts ..........................1 UF55/UF55w Mount ........................2 UF55/UF55w Projector ......................... 4 Optional Parts Kit for SMART Board 560 and 580 Interactive Whiteboards and UF55 Projectors (Part No. UF55-RFK- 500) ..............................
  • Page 4 Service Parts Diagrams for the UF55, UF55w and UF55-RFK-500...

  • Page 5: Identifying Your Product Using The Serial Number

    Identifying Your Product Using the Serial Number To make sure that you have the correct service parts diagrams, you must verify the serial number of your UF55/UF55w Projector. When mounted on the boom the serial number will be visible on the top of the projector. An example of the serial number format is shown below.

  • Page 6: Uf55/Uf55W Mount

    UF55/UF55w Mount Service Parts Diagrams for the UF55, UF55w and UF55-RFK-500...
  • Page 7 Item Part No. Description 52-00611-20 Base, upper wall 20-01005-21 Assembly, extended connection panel (ECP) 20-01016-23 Assembly, boom, rear 51-00735-21 Strap, limit NOTE: Contact Technical Support to discuss replacement. 52-00612-20 Base, lower wall 20-01009-20 Kit, documentation 30-01190-20 Screw, M4 × 12 mm, Phillips, pan head 52-00605-20 Access door, projector position adjustment 20-01017-20...

  • Page 8: Uf55/Uf55W Projector

    UF55/UF55w Projector Item Part No. Description 03-00131-20 Remote control NOTE: Battery not included with replacement remotes. 20-01033-20 CD, user manual, UF55/UF55w projector 52-00633-20 Cover, cable, UF55/UF55w projector NOTE: Comes attached to the UF55/UF55w projector. 20-01010-20 Assembly, SBP-10X Projector for UF55 NOTE: Includes items 1, 2 and 3.

  • Page 9: Optional Parts Kit For Smart Board 560 And 580 Interactive Whiteboards And Uf55 Projectors (Part No. Uf55-Rfk)

    Optional Parts Kit for SMART Board 560 and 580 Interactive Whiteboards and UF55 Projectors (Part No. UF55-RFK-500) Item Part No. Description 20-00963-20 Kit, spacer FRU-SB6WM FRU, wall mount kit Service Parts Diagrams for the UF55, UF55w and UF55-RFK-500...
