Summary of Contents for Oki PRO510DW

  • Page 1 p r o 5 1 0 D W U s e r ’ s G u i d e...
  • Page 3: Copyright Information

    The most up-to-date drivers and manuals are available from the web site: http://www.okiprintingsolutions.com Trademark Information _______________________________ Oki and Oki Printing Solutions are registered trademarks of Oki Electric Industry Company Ltd. Adobe and PostScript are registered trademarks of Adobe Systems. Apple, Macintosh, Mac, and Mac OS are registered trademarks of Apple Computers Inc.
  • Page 4: Table Of Contents

    ONTENTS Notes, cautions and warnings! ....7 Safety warnings ......7 Introduction .
  • Page 5 Connecting the parallel interface ... 45 Connecting the USB interface ... . . 45 Connecting the network interface ..46 Using the Drivers CD .
  • Page 6 Print Information example – demonstration page.88 Print Secure Job ......89 Menus....... . .90 Tray Configuration .
  • Page 7: Notes, Cautions And Warnings

    OTES CAUTIONS AND WARNINGS NOTE A note provides additional information to supplement the main text. CAUTION! A caution provides additional information which, if ignored, may result in equipment malfunction or damage. WARNING! A warning provides additional information which, if ignored, may result in a risk of personal injury. AFETY WARNINGS Please be careful to read and understand the safety warnings on the following pages before operating the printer.
  • Page 8 WARNING! Ensure all warning and instruction labels on the product are read, understood and followed in order to prevent any risk of injury. Ensure this and all other documentation is both read carefully and retained for future reference. This printer unit weighs 167.5 lbs (76kg). 3 people are required to lift the printer safely and prevent any risk of personnel injury.
  • Page 9 WARNING! This product has an earthed plug as a safety feature and will only connect to an earthed socket. Do not attempt to defeat the earthing or there is a risk of fire or shock. If using an extension cable or power strip ensure that the total current rating (amperes) of all connected equipment is less than the maximum rating of the extension cable, power...
  • Page 10 WARNING! Use only the power cable supplied. Using a power cable not intended for this product may lead to fire or electric shock. To avoid risk of fire and electric shock, do not use the power cable supplied with this product for any other electrical equipment.
  • Page 11 WARNING! If any liquid (for example water) is allowed to enter the printer, there is a risk of fire. Unplug the mains connector and contact your dealer. Do not place containers containing liquid on the printer as electric shock, fire and/or injuries may occur.
  • Page 12 WARNING! Risk of explosion if battery is replaced by an incorrect type. Do not touch the battery. Printer battery should not require replacement during the life of the printer. After installing additional memory or a hard disk drive, the cover door must be closed and secured to prevent risk of fire.
  • Page 13: Introduction

    NTRODUCTION Congratulations on buying an Oki proColor digital web printer. Your new printer is designed with advanced features to give you clear, vibrant color prints and crisp black and white output at high speed on a range of print media.
  • Page 14 Additionally, the following optional features are available: > Automatic two-sided (duplex) printing for economical use of cut sheet paper and compact printing of larger documents User’s Guide> 14...
  • Page 15: About This Guide

    BOUT THIS GUIDE NOTE Images used in this manual may include optional features that your printer does not have installed. This manual is your user’s guide (check the web site, my.okidata.com, for the most up-to-date version) for your product and forms part of the overall user support listed below: >...
  • Page 16: Software Supplied

    OFTWARE SUPPLIED CDs: > Drivers and Utilities Contains drivers and application software for use by a general user. > Network and Administrator Utilities Contains software for use by system administrators. User’s Guide> 16...
  • Page 17: Online Usage

    NLINE USAGE This guide is intended to be read on screen using an Adobe Acrobat Reader. Use the navigation and viewing tools provided in Acrobat. You can access specific information in two ways: > In the list of bookmarks down the left hand side of your screen, click on the topic of interest to jump to the required topic.
  • Page 18 [Pages from] and [to], (3), for the range of pages you specify by entering their page numbers. Click on [OK]. User’s Guide> 18...
  • Page 19: Printer And Paper Overview

    RINTER AND PAPER OVERVIEW PENING AND CLOSING THE TOP COVER CAUTION! To gain access to the inside of the printer, ensure that the top cover is fully opened. To open the top cover, squeeze the top cover handle (1) to release the catch and raise the cover.
  • Page 20: Identifying Major Components

    DENTIFYING MAJOR COMPONENTS The major components of your printer are identified in the graphics below. Paper holding arm Top cover (face-down stacker) MP Tray (multi-purpose tray)(non-functional w/ pro510DW) Tray 1 side cover Paper size label Paper gauge Tray 1 (paper tray) Control panel User’s Guide>...
  • Page 21 Top cover handle Face-down stacker Power (on/off) switch User’s Guide> 21...
  • Page 22 Face-up stacker Interface unit Network interface connector User’s Guide> 22...
  • Page 23 Parallel interface connector USB interface connector Power connector Ventilation openings Image drum cartridge and toner cartridge (Cyan) Image drum cartridge and toner cartridge (Magenta) User’s Guide> 23...
  • Page 24 Image drum cartridge and toner cartridge (Yellow) Image drum cartridge and toner cartridge (Black) Toner cartridge Image drum cartridge Fuser unit LED heads Belt unit Drum basket handle User’s Guide> 24...
  • Page 25 Drum basket User’s Guide> 25...
  • Page 26: Paper Recommendations

    The best performance will be obtained when using standard weight 20 – 24 lb (75 – 90 g/m²) paper designed for use in copiers and laser printers. Suitable types are: > OKI® Bright White, 32 lb US Bond > HammerMill® Laser Print Radiant, White, 24 lb US Bond >...
  • Page 27: Paper Input And Output Information

    APER INPUT AND OUTPUT INFORMATION The following table relates paper parameters to input trays (Tray 1 and Roll Feeder) and to output areas (Face-down stacker and Face- up stacker). TYPE SIZE WEIGHT INPUT/ OUTPUT Plain paper A3, A3 Nobi, A3 Wide, 17 –...
  • Page 28: Roll Feeder

    EEDER The roll feeder is used for media sizes additional to those of the standard tray, heavier media weights and special media. The roll feeder can handle the same sizes as the tray, in roll format. The roll feeder can feed paper widths as small as 3in (76.2 mm) and lengths up to 300 ft (91.4m).
  • Page 29: Tray And Stacker Examples

    RAY AND STACKER EXAMPLES OADING Tray 1 is used in the following example. Pull out the tray. Press the paper rear stopper tab (1) and adjust the tab to the required paper size. Fan the paper to be loaded then tap the edges of the stack on a flat surface to make it flush.
  • Page 30 Load the paper (face down and top edge towards the right for letterhead paper), press the tab (2) on the paper guide and adjust the guides (3) for a snug fit to the paper. To avoid paper jams: • Do not leave space between the paper and the guides and rear stopper.
  • Page 31: Using The Stackers

    Gently push the tray back into the printer. NOTE: FOR INFORMATION ON LOADING THE ROLL FEEDER, SEE THE ROLL FEEDER GUIDE. SING THE STACKERS Face-down stacker When the face-up stacker (1) on the left side of the printer is closed (its normal position), paper is ejected to the face-down stacker on the top of the printer.
  • Page 32 Face-up stacker The face-up exit path is used for continuous. Open the stacker (1). Flip out the paper support (2). User’s Guide> 32...
  • Page 33 Swivel out the paper support extension (3). NOTE If Take up rewinder is installed the face up stacker must be removed. See feeder guide for more information. User’s Guide> 33...
  • Page 34: Control Panel

    ONTROL PANEL The control panel can be swivelled to 90° (maximum) upwards from its base position (1) as required for ease of use. UTTONS AND LIGHTS The parts of the control panel are identified and briefly explained below: Shutdown/Restart button Hold down for more than 2 seconds for a soft shutdown.
  • Page 35: Ready Light

    Ready light On: indicates ready to print Flashing: indicates processing print data Off: indicates unable to receive data (offline) Attention light Off: indicates normal operation Flashing: indicates error(s) present but printing can continue On: indicates error(s) present and printing cannot continue Display panel Displays status and setup information for the printer and user help information in your chosen language...
  • Page 36: Display Panel Messages

    ISPLAY ANEL MESSAGES There are four types of display panel message: > Status information > Menu (functions) information > Configuration information > Help information TATUS INFORMATION Status information is associated with three printer states: In the Information state, such as idling or printing, the printer is able to process print jobs.
  • Page 37: Configuration Information

    Restart). Available to support staff to allow printer configurations and special functions to be set. ONFIGURATION INFORMATION Configuration information displays printer configuration information such as internal firmware versions. Menu options at each level can be scrolled through by moving the highlight with the Up-arrow/Down-arrow buttons and a highlighted option at that level can be selected by pressing the Enter button.
  • Page 38 The steps involved in using the menus are typically as follows: Ensure that the display panel indicates that the printer is ready to print. Enter User menu mode by pressing either the Enter button or the Up-arrow or Down-arrow button and press the latter two repeatedly until the desired menu is highlighted in the displayed list.
  • Page 39: Getting Started

    ETTING STARTED This section provides information to help you get started with using your printer. RINTER LOCATION Check that you have sufficient space for access: > around your printer: 20cm 8in 60cm 60cm 24in 24in 100cm 40in User’s Guide> 39...
  • Page 40: Turning Off/On

    > above your printer: 70cm 28in URNING URNING Hard disk drive installed Your printer has a hard disk drive installed, hold down the Shutdown/Restart button (1) on the control panel for more than 2 seconds to start the shutdown process. User’s Guide>...
  • Page 41 When the display panel shows that you can either turn off or restart the printer, use the On/Off switch to turn off the printer. User’s Guide> 41...
  • Page 42: Turning On

    URNING NOTE If the display panel shows that you can either turn off or restart the printer, press Shutdown/Restart to turn on the printer. If the printer is turned off (no power), use the On/Off switch to turn on the printer. User’s Guide>...
  • Page 43: Checking Current Settings

    HECKING CURRENT SETTINGS Carry out the following steps to generate a Configuration report (Menu Map) to confirm that your printer is correctly configured. Ensure that there is Letter paper in Tray 1 (to be used in this operation). Ensure that the display panel indicates that the printer is ready to print.
  • Page 44: Interfaces And Connection

    NTERFACES AND CONNECTION Your printer is equipped with a selection of data interfaces: > Parallel – For direct connection to a PC. This port requires a bi-directional (IEEE 1284 compliant) parallel cable. > USB – This port requires a cable conforming to USB version 2.0 or above.
  • Page 45: Connecting The Parallel Interface

    ONNECTING THE PARALLEL INTERFACE Turn off the printer and the computer. Connect a parallel cable between the printer and computer. Turn on the printer and then the computer. ONNECTING THE INTERFACE Do not connect the USB cable at this time. You will be instructed when to connect the USB cable when you run the Drivers CD.
  • Page 46: Connecting The Network Interface

    ONNECTING THE NETWORK INTERFACE CAUTION! Do not connect a USB cable into the network interface connector as this may lead to malfunction. Turn off the printer and the computer. Install the Ferrite core to the Ethernet cable as shown. User’s Guide> 46...
  • Page 47: Using The Drivers Cd

    Connect an Ethernet cable between the printer and an Ethernet hub. Turn on the printer and then the computer. If your printer is to be installed as a network printer, please refer to the relevant section in the Software Installation Guide and Configuration Guide for further details on how to configure the network connection before installing the printer drivers.
  • Page 48: Operation

    PERATION SING THE PRINTER For full details of how to use the printer and any accessories to print jobs efficiently and effectively, please refer to the Printing Guide. User’s Guide> 48...
  • Page 49: Consumables And Maintenance

    ONSUMABLES AND MAINTENANCE This section explains how to replace consumable and maintenance items when due. As a guide, the life expectancy of these items is: > Black Toner — 18,500 Letter pages at 5% coverage. > Cyan, Magenta, Yellow Toner— 16,500 Letter pages at 5% coverage The printer is shipped with sufficient toner for 7,500 Letter pages in the print cartridges of which 1 –...
  • Page 50: Consumable Item Order Information

    ONSUMABLE ITEM ORDER INFORMATION ITEM LIFE ORDER NUMBER Toner, Black 18,500 Letter pages @ 5% 52124004 Toner, Cyan 16,500 Letter pages @ 5% 52124003 Toner, Magenta 16,500 Letter pages @ 5% 52124002 Toner, Yellow 16,500 Letter pages @ 5% 52124001 Image drum, Black 42,000 Letter pages avg 56124004...
  • Page 51: Replacing Consumables/Maintenance Items

    You are advised to follow these instructions carefully. CAUTION! Only use genuine Oki Original consumables to ensure the best quality and performance from your hardware. Non-Oki Original products may damage your printer’s performance and invalidate your warranty.
  • Page 52 With an LED lens cleaner or soft cloth, gently wipe each of the four heads (1). Move the cleaner as shown, using a clean section of the cleaner with each pass. Be careful not to damage the guards (2). Close the top cover. User’s Guide>...
  • Page 53: Cleaning The Paper Feed Rollers

    LEANING THE PAPER FEED ROLLERS Clean the paper feed rollers if paper jams frequently occur. Remove items like a wrist watch or bracelet and follow the correct steps to turn the printer off depending on whether a hard disk drive is installed. Open Tray 1 side cover and pull out the paper guide plate (1).
  • Page 54 Remove Tray 1 completely from the printer. Gaining access through the gap left by Tray 1, wipe the 3 paper feed rollers (2) with a soft cloth lightly moistened with water. Replace Tray 1. User’s Guide> 54...
  • Page 55 Return the paper guide plate to its original position and close Tray 1 side cover. Turn on the printer. User’s Guide> 55...
  • Page 56: Cleaning The Printer Casing

    LEANING THE PRINTER CASING Follow the correct steps to turn the printer off depending on whether a hard disk drive is installed. Wipe the printer surface with a soft cloth moistened sparingly with water or neutral detergent. Use a soft dry cloth to dry the printer surface. User’s Guide>...
  • Page 57 Turn on the printer. User’s Guide> 57...
  • Page 58: Optional Accessories

    PTIONAL ACCESSORIES This section describes optional accessory equipment for your printer. The following accessories are available: > duplex unit (to enable two-sided printing) > rewinder unit CCESSORY ORDER INFORMATION ITEM ORDER NUMBER Duplex unit 42797201 Rewinder unit 70063101 User’s Guide> 58...
  • Page 59: Installing Accessories

    NSTALLING ACCESSORIES Each accessory comes complete with its own documentation which gives full instructions on installation. You are advised to follow these instructions carefully. After installation, print out a Menu Map (Configuration document) to check that the installation has been successful. For the following accessories, you have to make the appropriate setting in your printer driver(s): >...
  • Page 60: Troubleshooting

    ROUBLESHOOTING ENERAL If the printer display panel does not display anything or is still in stand-by mode 10 minutes after switching on, follow the printer shutdown sequence to switch it off. Check all cable connections before restarting the printer. If the problem persists, contact your dealer.
  • Page 61 Squeeze the catch (1) on Tray 1 side cover and open the cover. Holding it by the tab (2), turn the paper guide outward. Carefully remove the jammed paper. User’s Guide> 61...
  • Page 62: Open Cover, Paper Jam, Side Cover

    Put the paper guide back into position and close Tray 1 side cover. PEN COVER PAPER JAM SIDE COVER If the MP Tray is open, close it so that the side cover (1) is visible. User’s Guide> 62...
  • Page 63 Pull the release lever (2) and pull open the side cover. Carefully remove the jammed paper. User’s Guide> 63...
  • Page 64: Open Cover, Paper Jam, Top Cover

    Close the side cover. PEN COVER PAPER JAM TOP COVER Squeeze the top cover handle (1) and open the top cover. WARNING! Be careful not to touch the fuser unit which is hot after printing. User’s Guide> 64...
  • Page 65 Squeeze the basket handle (2) and raise the drum basket. Carefully remove any paper on the belt. If paper is jammed in the fuser unit, push the lock lever (3) in the direction shown to release the unit. WARNING! Be careful not to touch the fuser unit which may be hot after printing.
  • Page 66 Holding the fuser unit (4) by the handle, lift it out of the printer and place it on a flat surface. Pull up the jam release levers (5) and remove the jammed paper. User’s Guide> 66...
  • Page 67 Carefully replace the fuser unit into the printer and turn the lock lever (6) in the direction shown to lock the fuser unit. If paper is jammed near the paper exit, open the face-up stacker (7). User’s Guide> 67...
  • Page 68 Open the side cover (paper exit) (8) and remove the jammed paper. Close the side cover (paper exit) and then the face-up stacker. User’s Guide> 68...
  • Page 69 Return the image drum basket (9) into position and check it is locked. Close the top cover and ensure it is latched. User’s Guide> 69...
  • Page 70: Paper Jams - Duplex Unit (If Installed)

    – APER JAMS DUPLEX UNIT IF INSTALLED HECK DUPLEX UNIT PAPER JAM Operate the duplex cover release button (2) and open the cover. Carefully remove any jammed paper. User’s Guide> 70...
  • Page 71 Operate the levers (3) and pull out the duplex unit. Holding the front top cover by the grip (4), push it gently inwards and raise it. User’s Guide> 71...
  • Page 72 Remove any jammed paper. In similar manner, check for and clear any paper jammed under the rear top cover. User’s Guide> 72...
  • Page 73 Replace the two top covers. Raise the front cover of the duplex unit. User’s Guide> 73...
  • Page 74 Push the duplex unit back into position. User’s Guide> 74...
  • Page 75: Avoiding Paper Jams

    VOIDING PAPER JAMS The following table summarizes possible causes of paper jams and suggests ways of avoiding them. POSSIBLE CAUSE SUGGESTED REMEDY The printer is not level. Place the printer on a steady, level surface. Your print media is too light or Use appropriate media.
  • Page 76: Dealing With Unsatisfactory Printing

    EALING WITH UNSATISFACTORY PRINTING SYMPTOMS POSSIBLE CAUSES STEPS TO TAKE Vertical white lines The LED head is dirty. Wipe the LED head with a can be seen on the LED lens cleaner or with a printed page. soft cloth. The toner is low. Replace the toner cartridge.
  • Page 77: Possible Causes

    SYMPTOMS POSSIBLE CAUSES STEPS TO TAKE Vertical lines The image drum Replace the image drum appear. cartridge is damaged. cartridge. The toner is low. Replace the toner cartridge. Horizontal Lines When the interval is Wipe it lightly with a soft and spots appear about 94mm (4in), the cloth.
  • Page 78: Specifications

    PECIFICATIONS ITEM SPECIFICATION Dimensions 46.3x25.7x24.9in (HxWxD) (includes feeder) 118x65.4x63.3cm (HxWxD) Weight Without options, approx. 337.8 lb (153.2 kg) Print speeds Continuous: 30 ft/min. Cut Sheet: 36 ppm color; 40 ppm monochrome 20 – 28 lb paper Resolution 1200 x 600 dpi or 600 x 600 dpi Emulations PCL 5c, PCL XL 2.1, PS, Memory...
  • Page 79 ITEM SPECIFICATION Noise level Operating: 54dBA maximum Standby: 42dBA maximum Power save: 28dBA maximum after 30 mins background level User’s Guide> 79...
  • Page 80: Appendix A - Display Panel Messages

    A – D PPENDIX ISPLAY ANEL ESSAGES The display panel messages are intended to be self-explanatory. Representative messages are given as examples below. MESSAGE COMMENT Ready to Print Your printer is online and ready to print. Printing tttttt Your printer is printing and paper is currently being fed from tttttt, where tttttt identifies a tray.
  • Page 81 MESSAGE COMMENT Check Image Drum Check that the image drum of color cccccc is cccccc correctly installed. Please see HELP for You can access help details by pressing the HELP details button. User’s Guide> 81...
  • Page 82: Appendixb - Menu System

    B – M PPENDIX ENU SYSTEM The top-level Functions menus are: > Configuration > Print Information > Print Secure Job > Menus > Admin Setup > Calibration > Print Statistics The two other special top-level menus are: > Boot Menu >...
  • Page 83: Configuration

    ONFIGURATION RINT OUNT ITEM VALUE DESCRIPTION Total Pages nnnnnn Displays the total number of pages printed. Note: in duplex printing, each sheet is counted as 2 pages. Color Page nnnnnn Displays number of color printed pages converted to Letter equivalent. Monochrome nnnnnn Displays number of...
  • Page 84: Supplies Life

    UPPLIES ITEM VALUE DESCRIPTION xxxx Drum Remaining nnn% Displays the remaining life span of the xxxx drum as a percentage where xxxx can be Cyan, Magenta, Yellow, Black. Belt Remaining nnn% Displays the remaining life span of the belt unit as a percentage.
  • Page 85: Paper Size In Tray

    APER IZE IN ITEM VALUE DESCRIPTION Traym where Executive Displays detected paper m is 1 Letter Short Edge size of Traym. Letter Long Edge (similar Legal 14 arrangement Legal 13.5 for all trays) Tabloid Tabloid Extra Legal 13 A4 Short Edge A4 Long Edge A3 Nobi A3 Wide...
  • Page 86: Configuration Example - Monochrome Pages Printed

    ITEM VALUE DESCRIPTION Total Memory xx MB Displays total RAM memory installed in the printer. Same as Total Memory of Menu Map. Flash Memory xx MB [Fxx] Displays total flash memory installed in the printer and version. Same as Flash Memory of Menu Map.
  • Page 87: Print Information

    RINT NFORMATION ITEM ITEM DESCRIPTION Configuration Execute Prints printer configuration details. Network Execute Prints summary information about the wired network. Demo Page Demo 1 Execute Prints a demo page. File List Execute Prints a list of jobs stored on the Hard Disk (if installed). PS Font List Execute Prints PostScript font list...
  • Page 88 – RINT NFORMATION EXAMPLE DEMONSTRATION PAGE To print a printer demo page to demonstrate how your printer prints: Ensure that the display panel indicates that the printer is ready to print. Enter menu mode by pressing either the Up-arrow or Down-arrow button and press them repeatedly until the Print Information menu is highlighted.
  • Page 89: Print Secure Job

    RINT ECURE ITEM VALUE DESCRIPTION Encrypted Job Enter nnnn Enter a password to use Password secure printing. Not Found Use to print an encrypted secure job that has been stored on the HDD. Encrypted Print Not Found: (no jobs) is Delete indicated when there is no output file.
  • Page 90: Menus

    ENUS ONFIGURATION ITEM VALUE DESCRIPTION Tray1 Paper Feed Specifies a feed tray. MP Tray Auto Tray Sets the automatic tray Switch switch function. Tray Sequence Down Specifies selection order priority for Paper feed tray automatic tray selection/automatic tray switch. Unit of Inch (L) Specifies units for Measure...
  • Page 91 ITEM VALUE DESCRIPTION Tray Size Traym Config, Paper Size Sets paper in Tray. where m is 1. Custom X Dimension 3.9 – 8.3 (A) – Sets Custom paper 8.5 (L) – 12.9 width for Tray. Sets for inch the direction 100 –...
  • Page 92 ITEM VALUE DESCRIPTION Traym Config, Legal 14 Legal 14 Sets the length of the where m is in Paper Legal 13.5 legal paper in Tray. range 1 to 5 Change this to Legal 13.5 if that is the (similar standard legal size in arrangement your country.
  • Page 93 ITEM VALUE DESCRIPTION MP Tray Config Paper Size A3 Nobi Sets paper size for MP A3 Wide Tray. A4 Sht Edge A4 Long Edge B5 Short Edge B5 Long Edge Legal 14 Legal 13.5 Tabloid Extra Tabloid Letter Sht Edge Letter Long Edge (L) Executive...
  • Page 94 ITEM VALUE DESCRIPTION Plain MP Tray Config Media Type Sets the media type for Letterhead MP Tray. Transparency Labels Bond Recycled Card stock Rough Glossy Envelope User Type1 User Type2 User Type3 User Type4 User Type5 User Type 6 User Type 7 User Type 8 User Type 9 User Type 10...
  • Page 95: System Adjust

    YSTEM DJUST ITEM VALUE DESCRIPTION Power Save 3 min Sets the period after Time 5 min which power save 15 min mode starts. 30 min 60 min 240 min Clearable Online When Online is Warning selected, you must manually clear the warning by pressing the Online button.
  • Page 96 ITEM VALUE DESCRIPTION Continue Low Toner Sets the printing Stop operation when insufficient toner is detected. Continue: the printer can continue printing while remaining online. Stop: the printer stops printing and goes offline. Jam Recovery ON: continues printing the job, including any jammed pages, once the jam has been cleared.
  • Page 97 ITEM VALUE DESCRIPTION 0.00 Print Position Duplex X Adjust During the flip-side Adjust +0.25 – +2.00 printing of duplex -2.00 – -0.25 printing, adjusts the location of the whole printing image (0.25 0.00 mm, 0.01in interval) +0.01 – +0.08 perpendicular to the -0.08 –...
  • Page 98 ITEM VALUE DESCRIPTION Paper Color Used for fine color Setting adjustment for a significantly white horizontal dotted line, a significantly faded image or other such a problem that occurs in results printed on plain paper. Decrement setting when a white horizontal dotted line or a snowy image occurs in high-...
  • Page 99: Menus Example 1 - Tray 1 Transparencies

    ITEM VALUE DESCRIPTION SMR Setting Corrects print result variations caused by differences in temperature and humidity environment, or print density or frequency. This setting must be changed when print quality varies by printed result. BG Setting Corrects print result variations caused by differences in temperature and humidity...
  • Page 100 Press the Enter button to select this Item. Press the Up-arrow or Down-arrow buttons repeatedly until Tray1 Config is highlighted. Press the Enter button to select this Item. Press the Up-arrow or Down-arrow buttons repeatedly until MediaType is highlighted. Press the Enter button to select this Item. Press the Up-arrow or Down-arrow buttons repeatedly to move through the range of media types until Transparency is highlighted.
