Oki ES1624n Connection Manual

Oki ES1624n Connection Manual

Executive series computer connections & software install guide
Hide thumbs Also See for ES1624n:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Configuration Manual, User Manual
Installation Overview:
Windows
Network Installation:
□
Ethernet Connection ............................... 2
□
Software: TCP/IP ..................................... 3
□
Software: Novell ...................................... 8
USB Port Installation
□
Computer Connection .......................... 10
□
□
□
□
Parallel Port Installation
□
Computer Connection .......................... 15
□
Driver Installation .................................. 16

Additional Software

□
Installation Overview:
Macintosh
□
Network Connection ............................. 18
□
USB Connection .................................... 19
□
Software, OS 9.1+ .................................. 20
□
OKI, OkiLAN ® Oki Electric Industry Company, Ltd. Microsoft, Windows, Internet Explorer ®/™ Microsoft Corporation in the United States and other
countries. Netscape, Netscape Navigator U.S. ™, Netscape Communications Corporation. Novell, NetWare ® Novell Corporation in the U.S. and other
countries. PCL ® Hewlett Packard Company. Adobe, Acrobat, Acrobat Reader, PostScript ™ Adobe Systems, Inc. which may be registered in certain
jurisdictions. Ethernet ® Digital Equipment Corporation. EtherTalk, LaserWriter, Mac, Macintosh ® Apple Computer, Inc.
Executive Series 1624n

Computer Connections

& Software Install Guide
Windows Environment
Considerations
USB Versus Parallel
Installation instructions are included for both USB and
parallel connections. We recommend using a USB
connection, as your printer is performance optimized for a
USB interface.
Printer Drivers Available
The printer comes with a PCL driver and a Postscript
emulation driver.
When to Use the PCL Driver
If you use TrueType fonts and you do not print
®
PostScript
graphics (including ".eps" files), choose the
PCL driver. This will be more efficient and give good
results.
When to Use the Postscript Emulation Driver
If you use PostScript fonts or you will be printing
PostScript graphics, choose the Postscript emulation
driver. Performance will be faster and graphics will be
printed at their best quality.
Service and Support
Consult the store where you purchased your printer/color
•
copy system.
Visit
.
•
my.okidata.com
Call 1-800-654-3282, 24 hours a day, 7 days a week.
•

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ES1624n and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Oki ES1624n

Summary of Contents for Oki ES1624n

  • Page 1: Table Of Contents

    Software, OS 10.1 and higher ....22 OKI, OkiLAN ® Oki Electric Industry Company, Ltd. Microsoft, Windows, Internet Explorer ®/™ Microsoft Corporation in the United States and other countries. Netscape, Netscape Navigator U.S. ™, Netscape Communications Corporation. Novell, NetWare ® Novell Corporation in the U.S. and other countries.

  • Page 2: Ethernet Connection

    Windows Network Installation Ethernet Connection ® No Ethernet cable is supplied with the printer. Use an Ethernet cable with two twisted Note: wire pairs and an RJ45 plug. □ Turn off the printer. □ Remove the plug ( ) from the Ethernet port ( ), then connect your Ethernet cable to the port.

  • Page 3: Software: Tcp/Ip

    Properties dialog box. Oki LPR The IP Address Supports TCP/IP printing. Creates an OKI printer port and installs a pop-up utility to monitor the printer status. An IP address is required to install the drivers. If you are using DHCP, the IP address will automatically be detected.
  • Page 4 URL line in the email → → [Start Programs Oki Setup to download the printer driver(s) from the → Utility AdminManager]. web page set up by the administrator. •...
  • Page 5 The PCL driver is located on the Drivers CD under drivers\ES1624n\english\win2k_xp\ok725.inf □ Click Finish. Use the Oki LPR Utility to discover the printer: □ To activate/install the LPR utility: from the Menu Installer Software Installation dialog box on the driver CD, click Network Software → Installation/ Config →...
  • Page 6 Netscape Navigator 6.0 or above. of the Web Driver Utility window. Email access • Web Driver Installer Functions Oki LPR utility installed • [on driver CD, Network Software → Set up your Login Name (default = admin) and Password •...

  • Page 7: Readme File

    Windows Network Installation Software: TCP/IP (cont.) Configuring the Print Server via Windows 2000, XP and NT 4.0: □ Click the Device Settings tab. the Embedded Web Page □ Scroll down to Installable Options. □ Click Duplex, then click Installed. Do the same For more detailed information, see the OkiLAN Note: thing for Hard Disk.

  • Page 8: Software: Novell

    You can either set up the network while running the Note: [Oki LPR: TCP/IP only] utility off the CD, or you can choose to install the utility on your computer and then launch it from Admin Mgr / Quick Setup Utility →...
  • Page 9 Windows Network Installation Software: Novell (cont.) Activating the Optional The On-Line Printer User’s Accessories Guide □ If your printer has an optional duplex unit, internal hard Note: In order to open the on-line manual, you must have drive or second paper tray installed, you must enter the Acrobat Reader installed.

  • Page 10: Computer Connection

    Windows USB Port Computer Connection No USB interface cable is supplied with the printer. Note: Use a USB cable that is compatible with USB specification 1.1 or 2.0. □ A USB interface will only operate using Windows 2000, Windows XP, Windows Me, and Windows 98. Windows 95 and NT 4.0 do not support USB.

  • Page 11: Driver Installation, Windows Xp

    Windows USB Port Driver Installation, Windows XP Install the Printer Driver To Install the Second Driver as Well □ Make sure the USB cable is connected to your printer and PC and your printer is turned OFF. □ With the Menu Installer Software Installation dialog □...

  • Page 12: Driver Installation, Windows 2000

    Windows USB Port Driver Installation, Windows 2000 Install the Printer Driver To Install the Second Driver as Well □ Make sure the USB cable is connected to your printer and PC and your printer is turned OFF. □ With the Menu Installer Software Installation dialog □...

  • Page 13: Driver Installation, Windows Me

    Windows USB Port Driver Installation, Windows Me Install the Printer Driver To Install the Second Driver as Well □ Make sure the USB cable is connected to your printer and PC and your printer is turned OFF. □ With the Menu Installer Software Installation screen □...

  • Page 14: Driver Installation, Windows 98

    Windows USB Port Driver Installation, Windows 98 Install the Printer Driver To Install the Second Driver as Well □ Make sure the USB cable is connected to your printer and PC and your printer is turned OFF. □ With the Menu Installer Software Installation screen □...

  • Page 15: Computer Connection

    Windows Parallel Port Computer Connection □ Turn off both the computer and the printer. □ Attach a standard IEEE-1284 parallel cable (not supplied) to the parallel port (1) on the printer, securing it with the spring clips. □ Attach the other end to the parallel port on the computer and secure it in place with the screws.

  • Page 16: Driver Installation

    Windows Parallel Port Driver Installation Drivers Supplied To Install the Second Driver as Well Drivers are supplied for the following Windows systems: Windows XP, 2000 • □ With the Menu Installer Software Installation dialog Windows Me, 98, 95B • box still open, click the Printer Driver Installer Windows NT 4.0 button.

  • Page 17: Utilities, Activating Accessories, Etc

    Windows Software Installation Utilities, Activating Accessories, etc. Color Print Utilities To Activate in the Postscript Emulation Driver: Color Swatch Utility: Prints swatches of color samples • with RGB values. Enter the corresponding RGB value in Click Start → Settings → Printer. □...

  • Page 18: Network Connection

    Macintosh Installation Network Connection ® Requires Mac OS 9.1 or above, running on a Macintosh computer with EtherTalk interface. Note: The Ethernet cable is not supplied with the printer. Use an Ethernet cable with RJ45 connectors at either end. □ Turn off the printer.

  • Page 19: Macintosh Installation

    Macintosh Installation USB Connection No USB interface cable is supplied with the printer. Use a cable that is compatible with Note: USB specification 1.1 or 2.0. □ Requires Mac OS 9.1 or higher □ Printer operation is not assured if another USB compatible device is connected concurrently with it. □...

  • Page 20: Install The Driver

    Macintosh Installation Software, OS 9.1+ Install the Driver Create the Desktop Printer □ Turn on the printer, then turn on the computer. Networks □ Place the Drivers CD supplied with your printer into the □ Activate Chooser from the Apple menu, then wait for CD-ROM drive.

  • Page 21: Software, Os 9.1

    Macintosh Installation Software, OS 9.1+ (cont.) Accessing Advanced Features On-Line Manuals □ Select File on the desktop menu. Two on-line manuals are provided on the Manuals CD supplied with your printer: □ Click Print Desktop from the drop down menu. □...

  • Page 22: Software, Os 10.1 And Higher

    Macintosh Installation Software, OS 10.1 and higher Install the Driver Adding the Printer □ Mac 10.1-10.2: Be sure to switch off antivirus software before Note: Run the Print Center (Local HD → Applications installing a printer driver. → Utilities → Print Center). □...
  • Page 24 Oki Data Americas, Inc., 2000 Bishops Gate Blvd., Mt. Laurel, NJ 08054-4620 Tel: (856) 235-2600 Fax: (856) 222-5320 Oki Data Americas, Inc., 2735 Matheson Blvd. East, Unit 1, Mississauga, Ontario L4W 4M8, Canada Télép: 1-800-654-3282 Téléc: 1-905-238-4421 © 2004 Oki Data Americas, Inc.
