Contents Introduction ......... . 6 Printer Overview .
Page 4 Choosing a Color Matching Method ..... 149 Color matching: Postscript emulation driver ....151 Color Matching: PCL Driver .
Page 5: Notes, Cautions, Etc
Notes, Cautions, etc. A note appears like this. A note provides additional information to supplement the main text which helps you to use and understand the product. An important message appears like this. An important message provides supplemental information which can prevent potential problems.
Page 6: Introduction
Introduction Your new printer is designed with advanced features to give you clear, vibrant color printing and crisp black and white pages at high speed on a range of print media. Features: • Up to 16 pages per minute in full color. •...
Page 7: Printer Overview
Printer Overview Front View Output Stacker, face down Standard printed copy delivery point. Holds up to 250 sheets of 20-lb. US Bond (75 g/m²) paper. Operator Panel Menu driven operator controls and LCD display panel (can be changed to show different languages: see page 9). PaperTray Standard blank paper tray.
Page 8: Rear View
Rear View On/Off Switch Socket for Power Cord Parallel Interface USB Interface Network Interface Optional Duplex Unit Rear Stacker (face up), Capacity100 sheets 20-lb. US Bond (75 g/m²) paper When the rear paper stacker is folded down, paper exits the printer through the rear of the printer and is stacked here face up.
Page 9: Changing The Display Language
Changing the display language EADY TTENTION Press MENU SYSTEM CONFIG MENU POWER SAVE DELAY TIME Press ENTER. Press MENU SYSTEM CONFIG MENU LANGUAGE Press ENTER. Press MENU language you wish to select. Press ENTER to select this language. Press ON LINE to exit the menu and return the printer to standby.
Page 10: Media Recommendations
Media Recommendations Your printer can handle a variety of print media, including a range of paper weights and sizes, transparencies, labels and envelopes. This section provides general advice on choice and use of media. Print media must be able to withstand 446°F (230°C) for 0.2 second.
Page 11: Media Types
Media Types Paper The best performance is obtained when using paper designed for use in copiers and laser printers. Suitable types include: Hammermill • g/m²) ® Xerox 4024, 20 lb.US Bond (75 g/m²) • ® 52206101 Bright White Proofing Paper, 32 lb. US Bond •...
Page 12 Envelopes • Use only recommended envelopes (Oki 52206301 and 52206302: see “Selecting/Using OKI Print Media“ in your Handy Reference Guide for more information). • Envelopes should be stored flat and away from moisture, direct sunlight and heat sources. • Don’t use envelopes with windows or metal clasps.
Page 13 Labels • Avery 5161 White Laser Labels (letter size) work well with your printer. Check http://my.okidata.com for the latest information on media for your printer. • Use only labels designed for use in color laser printers and photocopiers. • Labels should cover the entire carrier sheet. •...
Page 14: Media: Tray 1 And Optional Tray 2
Media: Tray 1 and Optional Tray 2 Media Sizes: Trays 1 & 2 Paper size Letter (8½ x 11'') Legal-14 (8½ x 14'') Legal-13.5 (8½ x 13.5'') Legal-13 (8½ x 13'') Executive (7¼ x 10½'') A4 (210 x 297 mm) S, D A5 (145 x 210 mm) S, D A6 (105 x 148 mm) S B5 (182 x 257 mm) S, D...
Page 15: Auto Switching
Auto Switching If you have identical paper stock loaded in the Multi-Purpose Tray or the optional Second Paper Tray, you can have the printer automatically switch to the other tray when the current tray runs out of paper. This function is enabled in the Print Menu. Media: Multi-Purpose Tray Use the Multi-Purpose (MP) Tray for printing card stock, labels, envelopes and transparencies.
Page 16 Media Sizes: Multi-Purpose Tray Paper size Letter (8½ x 11'') Legal-14 (8½ x 14'') Legal-13.5 (8½ x 13.5'') Legal-13 (8½ x 13'') Executive (7¼ x 10½'') A4 (210 x 297 mm) A5 (145 x 210 mm) B5 (182 x 257 mm) Envelopes (COM-10) Custom: min.
Page 17: Top Exit (Face Down Stacker)
Top Exit (Face Down Stacker) • Holds up to 250 sheets of 20-lb. US Bond (42 lb. Index, 75 g/m² metric) standard paper • Handles paper stocks up to 47 lb. US Bond (98 lb. Index, 176 g/m² metric). • Pages are printed in reading order (page 1 first; last page on top, facing down).
Page 18: Loading Paper
Loading Paper Trays 1 and 2 If you have the optional second paper tray installed: • If you are printing from the 1st (upper) tray, you can pull out the 2nd (lower) tray and reload it while the printer is printing. •...
Page 19 Fan the paper to be loaded at the edges (1) and in the middle (2), then tap the edges of the stack on a flat surface to make it flush again (3). Load paper print side down, making sure the rear stopper (1) and paper guides (2) are snug against the paper.
Page 20 NOTE Load letterhead paper face down, with the top edge aimed towards the front of the printer. Gently close the paper tray. Loading Paper • 20...
Page 21 To prevent paper jams: • Do not leave space between the paper and the guides and rear stopper. • Do not overfill the paper tray. Capacity depends on the type of paper stock. • Do not load damaged paper. • Do not load paper of different sizes or types at the same time.
Page 22: Multi-Purpose (Mp) Tray
Multi-Purpose (MP) Tray NOTE The MP Tray will take a stack of media about 3/8'' (10 mm) high, equivalent to about 10 envelopes or 50 transparencies. Do not exceed the 3/8'' (10 mm) media stack height. Open the MP Tray. Loading Paper •...
Page 23 Press down on the loading platform. Load the print media and adjust the guides (1) to the size media being used. Letterhead stationery: • – For single-sided printing, load with pre-printed side up and the top edge into the printer. –...
Page 24 Press the blue tray latch ( ) toward the paper stack to lift the paper platform into the feed position. Loading Paper • 24...
Page 25: Menu Functions
Menu Functions This section lists the menus accessed via the controls on the printer’s operator panel and displayed in the LCD window. Many of these settings can be overridden by settings in the Windows printer drivers. However, several of the driver settings can be left at “Printer Setting,”...
Page 26: For Example
6. When the setting you wish to use appears on the display, press ENTER. An asterisk (*) appears next to the setting, and the setting flashes. To finish: a. If you are through making settings in the menu, press ON LINE to engage the setting and exit the menu.
Page 27 6. Press MENU + to change the setting to ON: DUPLEX The second line of the display begins flashing. Press ENTER to select the new setting: DUPLEX An asterisk appears on the second line of the display. Press ON LINE to engage the new setting and to exit the menu. The printer returns to standby mode.
Page 28: Summary Of Menu Defaults
Summary of Menu Defaults Note: Menus/Items with a dagger (†) only appear when the appropriate option (e.g., Hard Disk Drive, Duplex Unit, Second Paper Tray, etc.) is installed. Menu † PRINT JOBS MENU INFORMATION MENU † SHUTDOWN MENU PRINT MENU Menu Defaults Item ENTER PASSWORD...
Page 29: Color Menu
Menu Defaults (continued) Note: Menus/Items with a dagger (†) only appear when the appropriate option (e.g., Hard Disk Drive, Duplex Unit, Second Paper Tray, etc.) is installed. Menu PRINT MENU ( cont MEDIA MENU COLOR MENU Item EDIT SIZE TRAY1 PAPERSIZE TRAY1 MEDIATYPE TRAY1 MEDIAWEIGHT †...
Page 30: Sys Config Menu
Menu Defaults (continued) Note: Menus/Items with a dagger (†) only appear when the appropriate option (e.g., Hard Disk Drive, Duplex Unit, Second Paper Tray, etc.) is installed. Menu COLOR MENU ( cont SYS CONFIG MENU Item K HIGHLIGHT K MID-TONE K DARK C DARKNESS M DARKNESS...
Page 31 Menu Defaults (continued) Note: Menus/Items with a dagger (†) only appear when the appropriate option (e.g., Hard Disk Drive, Duplex Unit, Second Paper Tray, etc.) is installed. Menu SYS CONFIG MENU cont PCL EMULATION PPR EMULATION Item JAM RECOVERY ERROR REPORT LANGUAGE FONT SOURCE FONT NO.
Page 32 Menu Defaults (continued) Note: Menus/Items with a dagger (†) only appear when the appropriate option (e.g., Hard Disk Drive, Duplex Unit, Second Paper Tray, etc.) is installed. Menu PPR EMULATION ( cont FX EMULATION PARALLEL MENU Item .) LF FUNCTON LINE LENGTH FORM LENGTH TOF POSITION...
Page 33: Parallel Menu
Menu Defaults (continued) Note: Menus/Items with a dagger (†) only appear when the appropriate option (e.g., Hard Disk Drive, Duplex Unit, Second Paper Tray, etc.) is installed. Menu PARALLEL MENU ( cont USB MENU NETWORK MENU Item .) ACK/BUSY TIMING I-PRIME OFFLINE RECEIVE SOFT RESET...
Page 34 Menu Defaults (continued) Note: Menus/Items with a dagger (†) only appear when the appropriate option (e.g., Hard Disk Drive, Duplex Unit, Second Paper Tray, etc.) is installed. Menu † MEMORY MENU † DISK MAINTENANCE † SYS ADJUST MENU MAINTENANCE MENU USAGE MENU Item RECEIVE BUF SIZE...
Page 35: Usage Menu
Menu Defaults (continued) Note: Menus/Items with a dagger (†) only appear when the appropriate option (e.g., Hard Disk Drive, Duplex Unit, Second Paper Tray, etc.) is installed. Menu USAGE MENU ( cont Item TRAY1 PAGE COUNT TRAY2 PAGE COUNT MPT PAGE COUNT COLOR PAGE COUNT MONO PAGE COUNT K DRUM LIFE...
Page 36: Printer Menus
Printer Menus Item ENTER PASSWORD **** SELECT JOB Print Jobs Menu Action NO JOBS ALL JOBS FILE NAME #1 … FILE NAME #n Menu Functions • 36 Explanation MENU + MENU – to enter a digit of the password, then press ENTER to progress to the next digit.
Page 37: Information Menu
Item PRINT MENU MAP PRINT FILE LIST PRINT PCL FONT PRINT PSE FONT PRINT PPR FONT PRINT FX FONT DEMO1 PRINT ERROR LOG Information Menu Action Explanation EXECUTE Prints the MenuMap (menu listing) with current settings shown. Information about your printer is also shown at the top of each MenuMap page.
Page 38: Print Menu
Note: Factory default settings are shown in bold. Item COPIES DUPLEX PAPER FEED AUTO TRAY SWITCH TRAY SEQUENCE MP TRAY USAGE MEDIA CHECK Print Menu Settings to 999 TRAY1 TRAY2 MP TRAY DOWN PAPER FEED TRAY DO NOT USE WHEN MISMATCH ENABLE DISABLE Menu Functions •...
Page 39: Portrait Landscape
Note: Factory default settings are shown in bold. Item RESOLUTION TONER SAVE MODE MONO-PRINT SPEED ORIENTATION LINES PER PAGE Print Menu (continued) Settings 600x1200DPI 600DPI AUTO SPEED MONO 24PPM COLOR SPEED MIXED SPEED PORTRAIT LANDSCAPE 5 to 128 LINES Default = LINES Menu Functions •...
Page 40 Note: Factory default settings are shown in bold. Item EDIT SIZE Print Menu (continued) Settings CASSETTE SIZE LETTER EXECUTIVE LEGAL14 LEGAL13.5 LEGAL13 A4, A5, A6, B5 CUSTOM COM-9 ENVELOPE COM-10 ENVELOPE MONARCH ENV DL ENVELOPE C5 ENVELOPE Menu Functions • 40 Explanation Sets the size of the printable page area to match the size...
Page 41: Media Menu
Notes: • Factory default settings are shown in bold. • Menus/Items with an asterisk (†) only appear when the appropriate option (e.g., Hard Disk Drive, Duplex Unit, Second Paper Tray, etc.) is installed. Item TRAY1 PAPERSIZE TRAY1 MEDIATYPE TRAY1 MEDIAWEIGHT TRAY2 †...
Page 42 Notes: • Factory default settings are shown in bold. • Menus/Items with an asterisk (†) only appear when the appropriate option (e.g., Hard Disk Drive, Duplex Unit, Second Paper Tray, etc.) is installed. Item TRAY2 † MEDIAWEIGHT MPT PAPERSIZE MPT PAPERTYPE MPT MEDIAWEIGHT MEDIUM UNIT OF MEASURE MILLIMETER X-DIMENSION...
Page 43 Notes: • Factory default settings are shown in bold. • Menus/Items with an asterisk (†) only appear when the appropriate option (e.g., Hard Disk Drive, Duplex Unit, Second Paper Tray, etc.) is installed. Item Y-DIMENSION Media Menu (continued) Settings 5 to 35.5 INCH Default = 11 INCH Menu Functions •...
Page 44: Color Menu
The printer automatically adjusts color balance and density at appropriate intervals, optimizing the printed output for bright white paper viewed in natural daylight conditions. The items on this menu provide a means of changing the default settings for special or particularly difficult print jobs.
Page 45 Note: Factory default settings are shown in Item Settings C HIGHLIGHT -3 to + 3 in C MID-TONE increments of 1 C DARK Default = M HIGHLIGHT M MID-TONE M DARK Y HIGHLIGHT Y MID-TONE Y DARK K HIGHLIGHT K MID-TONE K DARK C DARKNESS -3 to + 3 in...
Page 46 Note: Factory default settings are shown in Item Settings CMY 100% DISABLE DENSITY ENABLE CMYK CONVERSION Color Menu (continued) Explanation When enabled, black areas are produced using 100% C, M, and Y instead of black. This results in a glossier finish. Postscript emulation only.
Page 47: System Configuration Menu
System Configuration Menu Note: Factory default settings are shown in Items Settings POW SAVE TIME PERSONALITY AUTO IBM PPR III XL EPSON FX EMULATION PARA PS- ASCII PROTOCOL USB PS- PROTOCOL ASCII NET PS- PROTOCOL ASCII CLEARABLE WARNING AUTO CONTINUE MANUAL TIMEOUT Explanation...
Page 48 System Configuration Menu (continued) Note: Factory default settings are shown in Items Settings WAIT 5 to 300 SEC TIMEOUT Default = 40 seconds LOW TONER CONTINUE STOP RECOVERY ERROR REPORT LANGUAGE English German French Italian Spanish Swedish Norwegian Danish Dutch Turkish Portuguese Polish...
Page 49: Pcl Emulation Menu
Note: Factory default settings are shown in Item Settings FONT RESIDENT / DIMM0 / SOURCE DIMM1 / DOWNLOADED FONT NO. I000 / C001 / S001 FONT PITCH 0.44 to 99.99 CPI Default = 10.00 CPI PCL Emulation Menu Menu Functions • 49 bold Explanation Specifies the location of the...
Page 50: Symbol Set
PCL Emulation Menu (continued) Note: Factory default settings are shown in Item Settings SYMBOL SET PC-8, PC-8 Dan/Nor, PC-8 TK, PC-775, PC-850, PC- 852, PC-855, PC-857 TK, PC-858, PC-866, PC-869, PC-1004, Pi Font, Plska Mazvia, PS Math, PS Text, Roman-8, Roman-9, Roman Ext, Serbo Croat1, Serbo Croat2, Spanish, Ukrainian, VN Int'l, VN Math, VN US,...
Page 51 PCL Emulation Menu (continued) Note: Factory default settings are shown in Item Settings A4 PRINT 78 COLUMN WIDTH 80 COLUMN WHITE PAGE SKIP CR FUNCTION CR CR+LF LF FUNCTION LF+CR PRINT NORMAL MARGIN 1/5 INCH 1/6 INCH TRUE BLACK PEN WIDTH ADJUST Explanation If you are printing a letter...
Page 52: Ppr Emulation Menu
Note: Factory default settings are shown in Item Settings CHARACTER 10 CPI PITCH 12 CPI 17 CPI 20 CPI PROPROTIONAL FONT 12CPI TO 20CPI CONDENSE 12CPI TO 12CPI CHARACTER SET 2 SET 1 PPR Emulation Menu Menu Functions • 52 bold Explanation Specifies character pitch...
Page 53 PPR Emulation Menu (continued) Note: Factory default settings are shown in Item Settings SYMBOL SET IBM-437, IBM-850, IBM-860, IBM-863, IBM-865, PC Set1, PC Ext US, PC Ext D/N, PC Set2 US, PC Set2 D/N, Roma3n-8, ISO L1, PC-8, PC-8 Dan/Nor, PC-850, Legal, ISO-2 IRV, ISO-4 UK, ISO-6 ASC, ISO-10 S/F, ISO-11 Swe, ISO-14 JASC,...
Page 54: Left Margin
PPR Emulation Menu (continued) Note: Factory default settings are shown in Item Settings ZERO Normal CHARACTER Slashed LINE PITCH 6 LPI 8 LPI WHITE PAGE SKIP CR FUNCTION CR+LF LF FUNCTION LF+CR LINE LENGTH 80 COLUMN 136 COLUMN FORM LENGTH 11 INCH 11.7 INCH 12 INCH...
Page 55: Fx Emulation Menu
Note: Factory default settings are shown in Item Settings CHARACTER 10 CPI PITCH 12 CPI 17 CPI 20 CPI PROPORTIONAL CHARACTER Set 2 SET 1 FX Emulation Menu Explanation Specifies character pitch (characters per inch). Specifies which Epson character set is used. Menu Functions •...
Page 56 FX Emulation Menu (continued) Note: Factory default settings are shown in Item Settings SYMBOL SET IBM-437, IBM-850, IBM- 860, IBM-863, IBM-865, PC Set1, PC Ext US, PC Ext D/ N, PC Set2 US, PC Set2 D/ N, Roman-8, ISO L1, PC-8, PC-8 Dan/Nor, PC-850, Legal, ISO-2 IRV, ISO-4 UK, ISO-6 ASC, ISO-10 S/F,...
Page 57 FX Emulation Menu (continued) Note: Factory default settings are shown in Item Settings ZERO NORMAL CHARACTER SLASHED LINE PITCH 6 LPI 8 LPI WHITE PAGE SKIP CR FUNCTION CR+LF LINE LENGTH 80 COLUMN 136 COLUMN FORM LENGTH 11 inch; 11.7 inch 12 inch TOF POSITION 0.0 increments...
Page 58: Parallel Menu
Note: Factory default settings are shown in Item Settings PARALLEL ENABLE DISABLE BI-DIRECTION ENABLE DISABLE ENABLE DISABLE NARROW ACK WIDTH MEDIUM WIDE ACK/BUSY ACK IN TIMING BUSY ACK WHILE BUSY I-PRIME 3 MICRO SEC 50 MICRO SEC DISABLE OFF LINE DISABLE RECEIVE ENABLE...
Page 59: Network Menu
Note: Factory default settings are shown in Item Settings ENABLE DISABLE SOFT RESET ENABLE DISABLE SPEED 480Mbps 12Mbps OFFLINE DISABLE RECEIVE ENABLE SERIAL ENABLE NUMBER DISABLE Note: Factory default settings are shown in Item Settings TCP/IP ENABLE DISABLE NETBEUI ENABLE DISABLE NETWARE ENABLE...
Page 60 Network Menu (continued) Note: Factory default settings are shown in Item Settings FRAME TYPE AUTO 802.2 802.3 ETHERNET II SNAP IP ADDRESS AUTO MANUAL IP ADDRESS xxx.xxx.xxx.xxx Default = 192.168.100.100 SUBNET MASK xxx.xxx.xxx.xxx Default = 255.255.255.000 GATEWAY xxx.xxx.xxx.xxx ADDRESS Default = 192.168.100.254 INITIALIZE [EXECUTE]...
Page 61 Network Menu (continued) Note: Factory default settings are shown in Item Settings TELNET ENABLE DISABLE ENABLE DISABLE SNMP ENABLE DISABLE NORMAL SMALL HUB LINK AUTO SETTING NEGOTIATE 100BASE-TX FUL 100BASE-TX HALF 10BASE-T FULL 10BASE-T HALF Explanation Enables or disables Telnet config. facility.
Page 62: Disk Maintenance Menu
The Disk Maintenance Menu can be used to initialize the printer's internal hard disk drive, to reassign the partition contents, or to reformat the partitions. Unless you know what you are doing, please avoid this section of the Menu. It is recommended that disk maintenance be done through the Storage Device Manager software by the System Administrator, or by someone who is knowledgeable in this area.
Page 63: System Adjust Menu
Note: Factory default settings are shown in Item X ADJUST Y ADJUST DUPLEX X ADJUST -2.00MILLIMETER TO DUPLEX Y ADJUST -2.00MILLIMETER TO PCL TRAY2 ID# PCL MP TRAY ID# DRUM CLEANING System Adjust Menu Settings -2.00MILLIMETER TO +2.00MILLIMETER Default = 0.00 -2.00MILLIMETER TO +2.00MILLIMETER Default = 0.00...
Page 64 System Adjust Menu (continued) Note: Factory default settings are shown in Item HEX DUMP Settings [EXECUTE] Menu Functions • 64 bold Explanation Press ENTER to switch the printer to the Hexadecimal Dump mode in which all data received is printed in both Hexadecimal and ASCII format.
Page 65: Maintenance Menu
Note: Factory default settings are shown in Item Settings MENU RESET EXECUTE SAVE MENU EXECUTE POWER SAVE ENABLE DISABLE PAPER BLACK –2 to +2 in increments of 1 Default = 0 PAPER COLOR –2 to +2 in increments of 1 Default = 0 TRANSPR –2 to +2 in...
Page 66: Usage Menu
This menu is for information only, and provides an indication of total usage of the printer and the expected life left in its consumable items. This is particularly useful if you do not have a full set of replacement consumables on hand and you need to know how soon you will need them Item TOTAL PAGE COUNT...
Page 67: Setting Color Tuning From The Front Panel
Setting Color Tuning from The Front Panel • In most cases, using Color Tuning is not necessary as the printer is optimized for color printing at its default settings. • Once you change these settings, they remain in effect until you go back in and change them.
Page 68 Print the Color Tuning Pattern: a. Make sure letter-size paper is loaded in the tray. b. Press repeatedly, until you see COLOR MENU c. Press ENTER. d. Press one or more times, until you see COLOR TUNING PRINT PATTERN e. Press ENTER. The Color Tuning Pattern prints and the display reads.
Page 69 Adjust the Cyan highlight color. a. Press ENTER to select the Cyan Highlight item. The second line of the display begins flashing. b. Press one or more times, until the new value you wish to use displays (e.g., +3). c. Press ENTER, to select the new value. An asterisk (*) appears at the right of the new selection.
Page 70 4. Adjust the Cyan dark color: a. Press ENTER to select the Cyan Dark item. The second line of the display begins flashing. b. Press one or more times, until the new value you wish to use displays (e.g., +3). c.
Page 71: Replacing Consumables
Replacing Consumables • Toner Cartridge — Life expectancy approximately 5,000 pages assuming about 5% coverage, which means that 5% of the addressable dots in an image are printed with this color of toner. See “Toner Cartridge Replacement” on page 72. When installing a toner cartridge in a new image drum, the life expectancy of the cartridge will be reduced by approximately 1,500 pages (at 5%...
Page 72: Toner Cartridge Replacement
Toner Cartridge Replacement REPLACE TONER : ZZZZ TONER EMPTY * nnn: ZZZZ = 410: YELLOW Toner Color Black, Cyan Magenta Yellow The instructions below show the black toner being replaced. 411: MAGENTA 412: CYAN 413: BLACK Order # 52115101 52115102 52115103 52115104 NOTE...
Page 73 Press the cover release and open the printer’s top cover fully. WARNING! If the printer has been powered on, the fuser is hot. This area is clearly labelled. Do not touch. Replacing Consumables • 73...
Page 74 Note the positions of the four cartridges: Cyan (1), Magenta (2), Yellow (3), Black (4): Pull the colored toner release lever on the cartridge to be replaced (here we are showing replacement of the black toner cartridge) towards the front of the printer. Lift the right-hand end of the cartridge and then pull the cartridge to the right to release the left-hand end as shown.
Page 75 toner cartridge and discard it in accordance with your local regulations. Unpack the new toner cartridge and gently shake it from side to side to loosen and distribute the toner evenly inside the cartridge. Replacing Consumables • 75...
Page 76 Remove the adhesive tape from the underside of the cartridge. Replacing Consumables • 76...
Page 77 Do not touch the toner release lever until the toner cartridge is installed in the image drum. If you do, it will open the toner release slot and spill toner. Holding the cartridge by its top center with the colored release lever to the right, insert the left end of the cartridge into the top of the image drum, pushing it firmly against the spring on the drum unit.
Page 78 Lower the right end of the cartridge into the image drum unit, pressing it firmly down in place, then push the colored lock lever back to open the toner slot and lock it in place. The lever should move easily. If it does not, STOP! and push down on the toner cartridge to be sure that it is properly seated in the image drum, then press back on the lever again.
Page 79 Use the LED lens cleaner supplied with the new toner cartridge to gently wipe the surface of the LED head which corresponds to the color toner cartridge you are replacing: Do not use methyl alcohol or other solvents on the LED head: damage to the lens surface will occur.
Page 80: Image Drum Replacement
Image Drum Replacement REPLACE IMAGE DRUM : ZZZZ DRUM LIFE * nnn: ZZZZ = 350: YELLOW Drum Color Black Cyan Magenta Yellow The instructions below show the black image drum being replaced. Place two sheets of paper on your working surface to protect it. You will put the image drum and toner cartridge on the paper while replacing them.
Page 81 Press the cover release and open the top cover fully. WARNING! If the printer has been powered on, the fuser is hot. This area is clearly labelled. Do not touch it. Replacing Consumables • 81...
Page 82 Note the positions of the four image drums: Cyan (1), Magenta (2), Yellow (3), Black (4): Lift the image drum, complete with its toner cartridge, out of the printer and put it down on one of the sheets of paper. Replacing Consumables •...
Page 83 With the colored toner release lever (1) to the right, pull the lever towards you. This will release the bond between the toner cartridge and the image drum. Lift the right-hand end of the toner cartridge, move the cartridge to the right, and remove the toner cartridge from the image drum. Place the toner cartridge on a sheet of paper to avoid marking your furniture.
Page 84 Unpack the new image drum. CAUTION! Image drum handling: The image drum contains toner. To avoid spilling toner, be careful to keep it upright. Replacing Consumables • 84...
Page 85 Grasp the white tape tab and peel the tape off the drum. Remove the paper sheet, then the clear plastic film. Replacing Consumables • 85...
Page 86 If present, remove the silica gel pack. Place the image drum in the printer. Replacing Consumables • 86...
Page 87 Remove the orange drum seal. Install the toner cartridge in the image drum. Replacing Consumables • 87...
Page 88 Push back the toner cartridge lock lever. Use the LED lens cleaner supplied with the new toner cartridge to gently wipe the surface of the LED head which corresponds to the color toner cartridge you are replacing: Do not use methyl alcohol or other solvents on the LED head: damage to the lens surface will occur.
Page 89 Close and latch the top cover. Replacing Consumables • 89...
Page 90: Belt Unit Replacement
Belt Unit Replacement P/N 42158711 REPLACE BELT 355: BELT LIFE The belt unit is located under the four image drums. This unit requires replacement approximately every 50,000 pages. Press the cover release and open the top cover fully. If the printer has been powered on, the fuser is hot. This area is clearly labelled.
Page 91 Note the positions of the four image drums: Cyan (1), Magenta (2), Yellow (3), Black (4). It is essential that they go back in the correct order! Lift each of the image drum units out of the printer and place them on a flat surface in a safe place away from direct sources of heat and light.
Page 92 Locate the two blue locks (1) and the handle (2). Turn the two locks about 45° counterclockwise to release the belt. Replacing Consumables • 92...
Page 93 Pull up the handle and lift the belt unit out of the printer. Unpack the new belt unit and hold it with the blue handle toward the front of the printer. Place the drive gear at the back of the belt unit in the gear at the left rear corner of the printer, and lower the belt unit into the printer.
Page 94 Turn the two belt locks about 45° clockwise to secure the belt unit in place. Place the four image drums/toner cartridges back in the printer (1 = Cyan, 2 = Magenta, 3 = Yellow, 4 = Black): Replacing Consumables • 94...
Page 95: Fuser Replacement
Close and latch the top cover. Fuser Replacement P/N 42625501 (120V) P/N 42625502 (230V) REPLACE FUSER 354: FUSER LIFE If the printer has recently been powered on, some fuser components will be very hot. Handle the fuser with extreme care, holding it only by its handle, which will only be mildly warm to the touch.
Page 96 Press the cover release and open the printer’s top cover fully. Pull the two blue fuser lock levers (1) towards the front of the printer. Replacing Consumables • 96...
Page 97 Holding the fuser by its handle, lift the fuser out of the printer. If the fuser is still warm, place it on a flat surface which will not be damaged by heat. After letting the fuser cool down, discard it. Remove the new fuser from its packaging, then remove any packing tape.
Page 98 Holding the new fuser by the handle, with the fuser pressure release lever (1) on the right, lower the fuser into the printer. Push the two blue retaining levers (1) toward the rear of the printer to lock the fuser in place. Replacing Consumables •...
Page 99 Close and latch the top cover. Replacing Consumables • 99...
Page 100: Clearing Paper Jams
Clearing Paper Jams Jams can occur due to paper misfeeding from a paper tray or at any point along the paper path. When a jam occurs, the printer immediately stops, and the LCD display indicates the area where the first sheet is jammed. All jammed sheets must be removed in order to restore the printer to normal operation.
Page 101 Jam 382 OPEN TOP COVER 382: PAPER JAM Open the top cover. Gently pull the sheet out. • If the sheet does not come out easily, go to the next step. • If the sheet does come out, close the cover. Lower the rear exit tray.
Page 102 Pull out the jammed sheet. Important! WARNING! The fuser may be HOT! If the sheet is difficult to remove, it is partially jammed in the fuser. To get it out, reach around the top cover and press down on the fuser pressure release lever ( ) before pulling the sheet out.
Page 103 Close the rear exit. Close the top cover. Clearing Paper Jams • 103...
Page 104 Jam 381 OPEN TOP COVER 381: PAPER JAM Press the cover release and open the printer’s top cover fully. Clearing Paper Jams • 104...
Page 105 Note the positions of the four image drums: Cyan (1), Magenta (2), Yellow (3), Black (4). It is essential that they go back in the correct order! If the printer has been powered on, the fuser is hot. This area is clearly labelled. Do not touch it. Clearing Paper Jams •...
Page 106 Lift each of the image drum/toner cartridge units out of the printer and place them on a flat surface in a safe place away from direct sources of heat and light. The green surface at the base of each image drum is very delicate and light sensitive.
Page 107 Remove any sheets of paper on the belt unit. CAUTION! Do not use any sharp or abrasive objects to separate sheets from the belt. This may damage the belt surface. Clearing Paper Jams • 107...
Page 108 NOTE Warning! If the printer has been printing, the fuser will be HOT! To remove a sheet trapped in the fuser, grasp the edge of the sheet, push the fuser pressure release lever (1) towards the front and down, and lift out the sheet. Then let go of the fuser pressure release lever.
Page 109 Place the four image drums/toner cartridges back in the printer, being careful to place them in the proper sequence (1=Cyan, 2 = Magenta, 3 = Yellow, 4 = Black): Close the top cover. Clearing Paper Jams • 109...
Page 110 Jam 372 and 380 OPEN FRONT COVER : PAPER JAM nnn = 372 or 380. Lift the front cover release and pull open the front cover. Remove any jammed sheets. Clearing Paper Jams • 110...
Page 111 Close the front cover. Clearing Paper Jams • 111...
Page 112 Jam 370, 373 and 383 OPEN DUPLEX COVER nnn: PAPER JAM nnn = 370, 373, 383 Press the duplex cover release and open the duplexer cover. Clearing Paper Jams • 112...
Page 113 Remove any jammed sheets. Clearing Paper Jams • 113...
Page 114 Close the duplex unit cover. Jam 371 OPEN DUPLEX COVER 371: PAPER JAM Turn off the printer. Pull out the duplexer. Clearing Paper Jams • 114...
Page 115 Pull the duplexer lid to unlock it. Open the lid and remove the jammed sheet. Clearing Paper Jams • 115...
Page 116 Close the lid and push it back to lock it in place. Push the duplexer back into the printer. Turn on the printer Clearing Paper Jams • 116...
Page 117 Jam 391 and 392 OPEN FRONT COVER nnn: PAPER JAM OPEN FRONT COVER 392: PAPER JAM Pull out the appropriate tray (391 = Tray 1, 392 = Optional Tray 2) and remove any sheet jammed as it exited the tray. Clearing Paper Jams •...
Page 118 Open the front cover. Remove any jammed sheets. Close the front cover. Clearing Paper Jams • 118...
Page 119 Jam 390 CHECK MP TRAY 390: PAPER JAM If the Sheet Has Just Begun to Enter the Printer Gently pull the sheet out of the printer. If the Sheet Can’t Easily Be Pulled Out from the Front Lift the front cover release and pull open the front cover. Clearing Paper Jams •...
Page 120 Remove any jammed sheets. Close the front cover. Clearing Paper Jams • 120...
Page 121: Troubleshooting
Troubleshooting LCD messages Message * TONER SENSOR ERROR ADD MORE MEMORY 420: MEMORY OVERFLOW CANCELING JOB (USER DENIED) CANCELLING JOB (BUFFER FULL) CANCELLING JOB (JAM) Meaning Flashes across the second line of the display: the indicated color toner (*) is missing from the printer.
Page 122 Message CHECK BELT 330: BELT MISSING CHECK FUSER 320: FUSER MISSING CHECK MP TRAY 390: PAPER :JAM Meaning The belt unit is not properly installed. The fuser unit is not properly installed. Paper has jammed while exiting the MP Tray. Troubleshooting •...
Page 123 Message CLOSE COVER 316: DUPLEX COVER OPEN CLOSE COVER : COVER OPEN HARD DISK FULL INSTALL PAPER CASSETTE : TRAY 1 MISSING INSTALL PAPER CASSETTE : TRAY 1 OPEN INVALID ID JOB REJECTED LOAD AND PRESS ONLINE SWITCH 490: MP TRAY EMPTY Meaning The duplex cover is open or not properly...
Page 124 Message LOAD EMPTY tttt LOAD AND PRESS ONLINE SWITCH MEDIA MISMATCH tttt LOAD AND PRESS ONLINE SWITCH SIZE MISMATCH tttt OPEN DUPLEX COVER : PAPER JAM OPEN FRONT COVER : PAPER JAM OPEN TOP COVER : PAPER JAM ORDER POWER ON/OFF 300: NETWORK ERROR Meaning A print job has been...
Page 125 Message PRESS ONLINE SW INVALID DATA PS3 EMULATION ERROR REPLACE TONER : * TONER EMPTY REPLACE YYYY : YYYY LIFE EMPTY tttt LIFE Meaning The printer has received invalid data. Applies to Postscript emulation only. An error occurred or virtual memory was used up.
Page 126 Message YYYY : FATAL ERROR Meaning An error has occurred which requires service. YYYY = the general cause. nnn = error number. Troubleshooting • 126 What to Do Write down the message including the error number “nnn,” then call your local service dealer.
Page 127: Problem Solving
Problem Solving Problems Printing If paper jams are frequent: • More than one sheet feeds at a time. • Paper curls. • Paper feeds at an angle. Possible cause The printer is not horizontal. The paper is too thin. The paper is moist or affected by static.
Page 128 Application error or general protection fault is displayed. Possible cause Application is not suitable for operating system. Memory is insufficient for number of applications running. Print file is corrupted. Memory is insufficient for application. Insufficient free space on hard disk. Printer driver is incorrectly configured.
Page 129 Printing is slow. Possible cause Print resolution is set high. Data is too complex. Simplify data. Printer requests paper size change to continue printing. Possible cause Paper loaded in tray is different size from that formatted in software application. The power is on, but the printer does not go online. Possible cause Bad connection Print processing does not start.
Page 130 Computer Interface Problems Cannot configure for parallel connection. Possible cause Remedy The computer There is no fix for this problem. You should only use does not support a computer that does support a bi-directional bi-directional parallel interface. parallel interface. Parallel cable does Use a bi-directional parallel cable to IEEE 1284 not meet standard.
Page 131 Cannot configure for USB connection. Windows 95 and NT 4.0 do not support USB; Windows 98 upgraded from Windows 95 may not support USB. Possible cause USB cable does not meet specifications. Interface is disabled. Configuration procedure was not correctly followed or cancelled.
Page 132 Printout is garbled or incorrect with parallel connection. Possible cause Possible mismatch on parallel connection between computer and printer. Cannot print. • LPT WRITE ERROR • PRNUSBX WRITE ERROR Possible cause Interface is disabled. Printer is switched OFF. Printer interface cable is disconnected.
Page 133: Print Quality Problems
Print Quality Problems Longitudinal white stripes Remedy Clean LED head with lens cleaner or soft tissue. Change toner cartridge(see “Toner Cartridge Replacement” on page 72). Change image drum(see “Image Drum Replacement” on page 80). Longitudinal fading Possible cause LED head is dirty. Toner is low.
Page 134 Possible cause Toner is low. The paper is moist. Paper is unsuitable for printer. Fading in patches Possible cause The paper is moist. Longitudinal black stripes Possible cause Image drum is damaged. Toner is low. Periodic black lateral lines or spots. The image drum has been exposed to light.
Page 135 Faint shading on unprinted sections Possible cause Paper has been affected by static electricity. Paper is too thick. Toner is low. Remedy Store paper within specified temperature and humidity levels (see “Specifications” on page 142). Use recommended paper (see “Media Recommendations”...
Page 136 Blurred letter edges Possible cause LED is dirty. Cannot print desired color because toner is low. One side of printed pages appears blurred Possible cause Top cover is not properly closed. One or more of the toner cartridges is not seated properly. Toner rubs off when you rub the printed surface.
Page 137: Miscellaneous Problems
Miscellaneous Problems Printer makes a strange noise. Possible cause The printer is not horizontal. There are scraps of paper or other foreign matter inside the printer. The top cover is not firmly shut. Printer takes a long time to start printing. Possible cause The printer has to warm up returning from power...
Page 138: Parallel Transmission Mode: Windows Only
Parallel Transmission Mode: Windows Only The parallel port supports IEEE-1284 and ECP mode. If your computer's parallel port is not compatible with one of these modes, the printer may not print at all or it may print corrupted data. To correct for this, enter the printer's Parallel Menu and change the ECP setting to Disable.
Page 139: Options
(Oki 70043001, 70043101, 70043201) The basic printer comes equipped with 64 MB of main memory. This can be upgraded with an additional memory board containing • 64 MB (Oki 70043001) • 128 MB (Oki 70043101) • 256 MB (Oki 70043201) giving a maximum total memory capacity of 320MB.
Page 140: Second Paper Tray
Second Paper Tray (Oki 42158511) The second paper tray takes: • Up to 530 sheets of 20-lb. paper. • All the same size media as Tray 1 except A6. • Paper weight range 16 to 47 lbs. US Bond (33 to 98 lbs Index, 60 to 177 g/m metric).
Page 141: Duplex Unit
Duplex Unit (Oki 42158411) The duplex unit adds the function of two sided printing and enables booklet printing. The duplex unit slides straight into the rear of the printer and requires no tools to install. The duplex unit handles: • Paper sizes letter, legal-14, legal-13.5, legal-13, A4, A5, B5, custom.
Page 142: Specifications
Specifications Item Specification Dimensions 16.61'' W x 22.09'' D x 13.58'' H (422 mm W x 561 mm D x 345 mm H) Net Weight 57.3 lbs. (26 Kg) Print speeds 16 pages per minute (ppm) color 24 ppm monochrome Resolution 600 dpi or 600 x 1200 dpi Emulations...
Page 143 Item Specification Paper weight Tray 1: 17 to 32 lb. (64 to120 g/m²) Range Optional Tray 2: 17 to 47 lb. (64 to 177 g/m²) Multi-Purpose Tray: 20 to 54 lb. (75 to 203 g/m²) Paper output Top Exit (Face Down Stacker): 250 sheets 20-lb.
Page 144: Windows
Windows Black Printing _________________ Normally, the printer will print black using all four toner colors. If you are doing a lot of black-only printing, you can set the printer to use only black toner. To Select Black Printing for a Particular Job in the PCL Driver: Click on the driver’s Color tab as you print the job: Grayscale...
Page 145 To Select Black Printing as The Default in the PCL Driver: → Click Start Settings Windows XP]. Right-click the printer name and: a. Windows 98/Me: select Properties, then click b. Windows 2000/XP: select Properties, then click Preferences. c. Windows NT 4.0: select On the Color tab, click Once Grayscale is set as the default, you must select either...
Page 146: Color Printing
Color Printing _________________ The printer drivers supplied with this printer provide several controls for changing the color output of your printer. For general use the Auto settings will suffice, providing reasonable default settings that will produce good results for most documents. Many applications have their own color settings, and these may override the settings in the printer driver.
Page 147 Viewing conditions A print can look very different under different lighting conditions. For example, the colors in a print may look different when viewed standing next to a sunlit window, compared to how they look under standard office fluorescent lighting. Printer driver color settings The driver settings for Manual color can change the appearance of a print.
Page 148 How Your Software Application Displays Color ® ® Some graphics applications such as CorelDRAW or Adobe ® Photoshop may display color differently from "office" applications ® such as Microsoft Word. Please see your application’s on-line help or user manual for more information. Paper Type The type of paper used can also significantly affect the printed color.
Page 149: Choosing A Color Matching Method
Typically CMYK documents are only supported in professional Desktop Publishing and Graphics applications. Matching Photographic Images RGB only Oki Color Matching is a generally a good choice. Select a matching method appropriate to your monitor. Windows: Color Printing • 149 NOTE...
Page 150 Matching Specific Colors (e.g., a Company logo): RGB only • Option 1: Select Oki Color Matching, and the sRGB setting on the Color tab in the PCL or Postscript emulation driver. • Option 2: For Postscript emulation print jobs: Select Postscript Color Matching using the Absolute Colorimetric option on the Color tab in the printer driver.
Page 151: Color Matching: Postscript Emulation Driver
Color matching: Postscript emulation driver The Postscript emulation driver color matching options are found: • Windows 98 and Me: on the Graphics tab in the driver: • Windows 2000, XP and NT 4.0: on the Color tab in the driver: Windows: Color Printing •...
Page 152 To change the Postscript emulation driver’s color matching defaults from the Windows Control Panel: → Click Start Settings Windows XP]. Right-click the printer name and choose Click Printing Preferences Click the appropriate tab ( tab for WIndows 2000/XP/NT 4.0) and make your Color changes.
Page 153 Color Matching Options: Windows Me and 98 The Graphics tab on the Postscript emulation driver in these Windows operating systems offers several rendering intents for controlling the color output of the printer. When a document is printed, a conversion takes place from the document’s color to the printer color.
Page 154 Using ICC Profiles a. Not Windows NT 4. Oki Color Matching This is Oki’s proprietary color matching system, and affects RGB data only. • Perceptual settings are best for printing photographic images. • Vivid or Digital Camera settings produce brightest colors.
Page 155 Monitor (9300k) Optimized for printing photographs when using a monitor with a color temperature of 6500K. Digital Camera Optimized for printing photographs taken with a digital camera. This tends to produce prints with lighter and brighter colors. For some photographs, other settings may be better depending on the subjects and the conditions under which they were taken.
Page 156 • Absolute Colorimetric Best for printing solid colors and tints, such as Company logos etc. Matches colors common to both devices exactly, and clips the out of gamut colors to their nearest printed equivalent. Tries to print white as it appears on screen. The white of a monitor is often very different from paper white, so this may result in color casts, especially in the lighter areas of an image.
Page 157 Under “Color Profiles currently associated with this printer,” you should see the names of profiles that match your printer model. If you do not see any profiles associated with the driver, click “Add…” and locate the ICC profiles for your printer. Windows ICM uses the information in these profiles to convert colors in your documents to colors that the printer can reproduce.
Page 158: Color Matching: Pcl Driver
Color Matching: PCL Driver Color Matching Options The Color Matching options in the PCL driver can be used to help match your printed colors to the ones displayed on your monitor. The PCL driver’s color options are only designed to work with RGB data.
Page 159 To set the color matching options manually, click Manual Color. The Color tab screen will change to: Choose from the following options: • Monitor (6500k) Perceptual Optimized for printing daylight photographs. • Monitor (6500k) Vivid Optimized for printing bright colors. Good for office graphics. •...
Page 160 To change the PCL driver’s color matching defaults from the Windows Control Panel: → Click Start Settings Windows XP]. Right-click the printer name and choose Click Printing Preferences Click the tab and make your changes. Color To change the PCL Color Matching options for a particular print job: Open the file in your application and select In the...
Page 161: Pcl Emulation Driver
The Print Color Swatch Utility For use with applications which allow you to set your own RGB values for colors. The Color Swatch utility prints out charts of sample colors. Listed below each color are the corresponding RGB (Red, Green, Blue) values to use in your application to match that printed color: For more information see “Color Swatch Utility”...
Page 162: Windows 98/M E /Xp/Nt 4.0
Windows 98/Me/XP/NT 4.0 The illustrations in this section show the Windows Me Operating System. The other Windows operating systems may appear slightly different, but the principles are the same. • N-up Printing: multiple pages on one sheet (see page 163) •...
Page 163 N-Up Printing (Printing Multiple Pages on One Sheet) 98 / Me / XP / NT 4.0 Open the file in your application and select In the dialog box, select the PCL printer, then: Print a. Windows 98/Me/NT4.0: click Properties. b. Windows XP: click Preferences. On the tab, under Setup...
Page 164 Printing custom Page Sizes 98 / Me / XP / NT 4.0 The printer media size for the tray you’re using must be manually set in the driver to the custom paper size before use (range 3½'' to 8½'' [89 to 216 mm] wide x 5'' to 14'' [127 to 356 mm] long). Up to 32 custom page sizes can be defined in the PCL driver.
Page 165 5. On the Setup tab, under Media, select Size drop-down list. Define the custom size in the dialog box which appears, then click OK. You may see a conflict. If you do, click automatically make the needed changes to correct for the conflict.
Page 166 User Defined Size To save the setting for future use: • Click Paper Feed Options • Select the unit, then enter the relevant information Width name under • Click • Click The Custom Page Size is added to the bottom of the Paper Size list.
Page 167 Changing the Resolution for A Print Job 98 / Me / XP / NT 4.0 These instructions explain how to change the settings as you are printing a job. If you wish to change the settings to apply to all jobs (default settings): →...
Page 168 3. On the Job Options under Quality: = high resolution, slower speed: choose this one for opti- • Fine mum results when printing graphics. = medium resolution, medium speed: the default. • Normal = low resolution, fast speed: choose this one for drafts or •...
Page 169 Duplex Printing (Printing on Both Sides of The Paper) 98 / Me / XP / NT 4.0 The optional duplex unit must be installed in the printer and enabled before duplex printing can be carried out. (See the instructions supplied with the duplex unit.) •...
Page 170 On the tab, under Setup Short Edge Click Windows 98/Me/NT4.0: click Windows XP: click Print. Windows: PCL Emulation Driver • 170 , select 2-Sided Printing Long Edge...
Page 171: Printing Booklets
Printing Booklets 98 / Me / XP / NT 4.0 • You must have the duplex unit installed and enabled in order to print booklets. • Not available on some network connections: see the Help file. • Some software applications may not support booklet printing.
Page 172 On the tab, under Setup drop-down list. Click , enter your settings, and click Options Click Windows 98/Me/NT4.0: click Windows XP: click Print. Windows: PCL Emulation Driver • 172 , select Finishing Mode in the Booklet...
Page 173: Printing Watermarks
Printing Watermarks 98 / Me / XP / NT 4.0 Open the file in your application and select In the dialog box, click the PCL printer, then: Print a. Windows 98/Me/NT4.0: click Properties. b. Windows XP: click Preferences. On the Job Options Select a name from the new watermark.
Page 174 To create a new watermark or edit an existing watermark: • Click the • Enter the text for the watermark and select the font, size, angle, etc., to be used. • Click The new watermark appears in the Watermark list. If you wish to print the watermark only on the first page of the document, select Click...
Page 175 Collating 98 / Me / XP / NT 4.0 Collating can be carried out with or without a hard disk drive installed. However, printers with a hard disk drive will provide greater performance. If your software application has a collate option, use it instead of the collate option in the printer driver.
Page 176 On the Job Options copies required and select Click Windows 98/Me/NT4.0: click Windows XP: click Print. Windows: PCL Emulation Driver • 176 tab, under Job Type Collate , enter the number of...
Page 177: Proof And Print
Proof and Print 98 / Me / XP / NT 4.0 Proof and print allows printing of a single copy of a document for checking before printing multiple copies of the same document. • If the hard disk memory is insufficient for the spooled data, is displayed and only one copy is printed.
Page 178 On the Job Options In the dialog box which appears, enter a password (PIN) of your choice, then click appears, click Enter the number of copies and select click Windows 98/Me/NT4.0: click Windows XP: click The document is processed to a print file and stored on the hard disk drive.
Page 179: Print Jobs Menu
Printing The Additional Copies Press to enter the menu mode. PRINT JOBS MENU Press ENTER. ENTER PASSWORD – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password.
Page 180 Deleting The Document If the proof is not ready for printing, the job must be deleted from the printer: Press to enter the menu mode. PRINT JOBS MENU Press ENTER. ENTER PASSWORD – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD...
Page 181 Press ENTER to delete the job, then press ON LINE. NOTE An alternative method of printing or deleting the remaining copies of the document is to use the Storage Device Manager. Please refer to the On-line help for Storage Device Manager. Windows: PCL Emulation Driver •...
Page 182 Secure Printing (Printing Confidential Documents) 98 / Me / XP / NT 4.0 Secure printing or printing with passwords allows the printing of confidential documents on printers that are shared with other users. • If the hard disk memory is insufficient for the spooled data, copy printed.
Page 183 On the Job Options In the dialog box which appears, enter a password (PIN) of your choice, then click appears, click Enter the number of copies and select click Windows 98/Me/NT4.0: click Windows XP: click Print. The document is processed to a print file and stored on the hard disk drive.
Page 184 Printing A Confidential Document from The Front Panel Press to enter the menu mode. PRINT JOBS MENU Press ENTER. ENTER PASSWORD – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password.
Page 185 Deleting The Confidential Document Before Printing It Press to enter the menu mode. PRINT JOBS MENU Press ENTER. ENTER PASSWORD – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password.
Page 186 7. Press ENTER to delete the job, then press ON LINE. NOTE An alternative method of printing or deleting the document is to use the Storage Device Manager. Please refer to the On-line help for Storage Device Manager. Windows: PCL Emulation Driver • 186...
Page 187 Store to Hard Disk 98 / Me / XP / NT 4.0 Store to hard disk (job spooling) allows print jobs to be prepared and stored on the hard disk for printing on demand. This is good for forms, generic memos, letterhead stationery, etc. •...
Page 188 On the Job Options In the dialog box which appears, enter a password (PIN) of your choice, then click appears, click Enter the number of copies and select click Windows 98/Me/NT4.0: click Windows XP: click Print. The document is processed to a print file and stored on the hard disk drive.
Page 189 To Print A Stored Document Press to enter the menu mode. PRINT JOBS MENU Press ENTER. ENTER PASSWORD – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password.
Page 190 To Delete A Stored Document from The Hard Disk Drive Press to enter the menu mode. PRINT JOBS MENU Press ENTER. ENTER PASSWORD – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password.
Page 191 Press ENTER to delete the job, then press ON LINE. NOTE An alternative method of printing or deleting the remaining copies of the document is to use the Storage Device Manager. Please refer to the On-line help for Storage Device Manager. Windows: PCL Emulation Driver •...
Page 192: Printing Posters
Printing Posters 98 / Me / XP / NT 4.0 This option allows you to configure and print posters by breaking up the document page into multiple pieces which print enlarged on separate sheets. Then the separate sheets are combined to produce a poster.
Page 193: Windows 2000
Windows 2000 • N-up Printing: multiple pages on one sheet (see page 194) • Custom Page Sizes (see page 195) • Selecting Print Resolution (see page 198) • Duplex Printing (see page 200) • Watermarks (see page 203) • Collating (see page 205) •...
Page 194 N-Up Printing (Printing Multiple Pages on One Sheet) 2000 Open the file in your application and select In the dialog box, select the PCL printer. Print On the tab, under Setup number of pages per sheet in the drop-down list. To set additional parameters, click selections and click Click...
Page 195 Printing Custom Page Sizes 2000 The printer media size for the tray you’re using must be manually set in the driver to the custom paper size before use (range 3½'' to 8½'' [89 to 216 mm] wide x 5'' to 14'' [127 to 356 mm] long). Up to 32 custom page sizes can be defined in the PCL driver.
Page 196 5. On the Setup tab, under Media, select Size drop-down list. Define the custom size in the dialog box which appears, then click OK. You may see a conflict. If you do, click automatically make the needed changes to correct for the conflict.
Page 197 User Defined Size To save the setting for future use: • Click Paper Feed Options • Select the unit, then enter the relevant information Width name under • Click • Click The Custom Page Size is added to the bottom of the Paper Size list.
Page 198 Changing the Resolution for A Print Job 2000 These instructions explain how to change the settings as you are printing a job. If you wish to change the settings to apply to all jobs (default settings): → • Click Start •...
Page 199 3. On the Job Options under Quality: = high resolution, slower speed: choose this one for opti- • Fine mum results when printing graphics. = medium resolution, medium speed: the default. • Normal = low resolution, fast speed: choose this one for drafts or •...
Page 200 Duplex Printing (Printing on Both Sides of The Paper) 2000 The optional duplex unit must be installed in the printer and enabled before duplex printing can be carried out. • Paper weight range 20 to 28 lb. US Bond (75 to 105 g/m²). •...
Page 201 On the tab, under Setup Short Edge Click Print Windows: PCL Emulation Driver • 201 , select 2-Sided Printing Long Edge...
Page 202 Printing Booklets 2000 • You must have the duplex unit installed and enabled in order to print booklets. • Not available on some network connections: see the Help file. • Some software applications may not support booklet printing. • The right-to-left setting allows a booklet to be printed for right to left reading, which is used in some languages.
Page 203 Printing Watermarks 2000 Open the file in your application and select In the dialog box, click the PCL printer. Print On the Job Options Select a name from the new watermark. When you’re finished setting up the new watermark, click Windows: PCL Emulation Driver •...
Page 204 To create a new watermark or edit an existing watermark: • Click the • Enter the text for the watermark and select the font, size, angle, etc., to be used. • Click The new watermark appears in the Watermark list. If you wish to print the watermark only on the first page of the document, select Click...
Page 205 Collating 2000 Collating can be carried out with or without a hard disk drive installed. However, printers with a hard disk drive will provide greater performance. If your software application has a collate option, use it instead of the collate option in the printer driver. The following instructions explain how to select collating using the printer driver.
Page 206 Proof and Print 2000 Proof and print allows printing of a single copy of a document for checking before printing multiple copies of the same document. • If the hard disk memory is insufficient for the spooled data, copy is printed. •...
Page 207 On the Job Options In the dialog box which appears, enter a password (PIN) of your choice, then click appears, click On the tab, enter the number of copies and select General , if applicable, then click Collate Click Print The document is processed to a print file and stored on the hard disk drive.
Page 208: Print Jobs Menu
Printing The Additional Copies Press to enter the menu mode. PRINT JOBS MENU Press ENTER. ENTER PASSWORD – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password.
Page 209 Deleting The Document If the proof is not ready for printing, the job must be deleted from the printer: Press to enter the menu mode. PRINT JOBS MENU Press ENTER. ENTER PASSWORD – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD...
Page 210 Press ENTER to delete the job, then press ON LINE. NOTE An alternative method of printing or deleting the remaining copies of the document is to use the Storage Device Manager. Please refer to the On-line help for Storage Device Manager. Windows: PCL Emulation Driver •...
Page 211 Secure Printing (Printing Confidential Documents) 2000 Secure printing or printing with passwords allows the printing of confidential documents on printers that are shared with other users. • If the hard disk memory is insufficient for the spooled data, copy printed. •...
Page 212 On the Job Options In the dialog box which appears, enter a password (PIN) of your choice, then click appears, click Enter the number of copies and select Click Print The document is processed to a print file and stored on the hard disk drive.
Page 213 Printing A Confidential Document from The Front Panel Press to enter the menu mode. PRINT JOBS MENU Press ENTER. ENTER PASSWORD – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password.
Page 214 Deleting The Confidential Document Before Printing It Press to enter the menu mode. PRINT JOBS MENU Press ENTER. ENTER PASSWORD – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password.
Page 215 Press ENTER to delete the job, then press ON LINE. NOTE An alternative method of printing or deleting the remaining copies of the document is to use the Storage Device Manager. Please refer to the On-line help for Storage Device Manager. Windows: PCL Emulation Driver •...
Page 216 Store to Hard Disk 2000 Store to hard disk (job spooling) allows print jobs to be prepared and stored on the hard disk for printing on demand. This is good for forms, generic memos, letterhead stationery, etc. • If the hard disk memory is insufficient for the spooled data, DISK FULL is displayed and only one copy printed.
Page 217 On the Job Options In the dialog box which appears, enter a password (PIN) of your choice, then click appears, click Enter the number of copies and select Click Print The document is processed to a print file and stored on the hard disk drive.
Page 218 To Print A Stored Document Press to enter the menu mode. PRINT JOBS MENU Press ENTER. ENTER PASSWORD – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password.
Page 219 To Delete A Stored Document from The Hard Disk Drive Press to enter the menu mode. PRINT JOBS MENU Press ENTER. ENTER PASSWORD – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password.
Page 220 Press ENTER to delete the job, then press ON LINE. NOTE An alternative method of printing or deleting the remaining copies of the document is to use the Storage Device Manager. Please refer to the On-line help for Storage Device Manager. Windows: PCL Emulation Driver •...
Page 221 Printing Posters 2000 This option allows you to configure and print posters by breaking up the document page into multiple pieces which print enlarged on separate sheets. Then the separate sheets are combined to produce a poster. It is only available with the PCL printer driver Open the file in your application and select In the dialog box, click the PCL printer.
Page 222: Postscript Emulation Driver
Postscript Emulation Driver_____ The Windows Postscript emulation printer driver contains settings for many of the same items as are found in the operator panel menus. Where items in the printer driver are the same as those in the operator panel menus, and you print documents from Windows, the settings in the Windows printer driver will override those items in the operator panel menus.
Page 223 N-Up Printing (Printing Multiple Pages on One Sheet) Me and 98 You can print either 2 or 4 pages on one sheet of paper. Open the file in your application and select In the Print dialog box, click the Postscript emulation printer, then click Properties On the...
Page 224 Printing Custom Page Sizes Me and 98 Custom page sizes can be printed from Tray 1, Tray 2 or the Multi-Purpose (MP) Tray, one-sided printing only, rear exit only. Tray 1 and Tray 2 Custom Size Range • minimum 3.94'' x 5.83'' [100 x 148 mm] •...
Page 225 Load the custom size paper in the tray you will be using. For example, the MP Tray: Open the file in your application and select In the dialog box, select the Postscript emulation printer, Print then click Properties Windows: Postscript Emulation Driver • 225 →...
Page 226 On the tab and select the tray you are using in the Paper drop-down list. source Under Paper Size icons, then click Custom Windows: Postscript Emulation Driver • 226 (1), scroll across and click one of the three (2). Name and define your Custom Paper...
Page 227 custom size in the dialog box which appears, then click twice to go back to the dialog box. Print Click to print the document. Windows: Postscript Emulation Driver • 227...
Page 228 Changing The Resolution for a Print Job Me and 98 These instructions explain how to change the settings as you are printing a job. If you wish to change the settings to apply to all jobs (default settings): → • Click Start •...
Page 229 3. On the Graphics Resolution drop-down list, then click OK: = high resolution, slower speed: the default. Provides • Fine optimum results when printing graphics. = medium resolution, medium speed: choose this set- • Normal ting for documents with lower resolution graphics, line art, or text only.
Page 230 Duplex Printing (Printing on Both Sides of The Paper) Me and 98 The optional duplex unit must be installed in the printer and enabled before duplex printing can be carried out. • Paper weight range 20 to 28 lb. US Bond (75 to 105 g/m •...
Page 231 On the tab, click Paper Edge Flip on Short Edge Click to print the document. Windows: Postscript Emulation Driver • 231 . Select More Options… , then click OK twice. Flip on Long...
Page 232 Collating Me and 98 Collating can be carried out with or without a hard disk drive installed. However, printers with a hard disk drive will provide greater performance. Open the file in your application and select In the dialog box, click the Postscript emulation printer, then Print click Properties...
Page 233 Secure Print (Printing Confidential Documents) Me and 98 Secure printing or printing with passwords allows the printing of confidential documents on printers that are shared with other users. Once the document is printed, it is deleted from the Hard Disk Drive. If you wish to retain the document on the Hard Disk Drive after printing it, use the Store to Hard Disk feature (see page 187).
Page 234 Click the Device Options ), then select Job Type Enter your 4-digit password (0000 to 9999): In the list, click features choice for that digit under for each digit of the password, making note of the number you entered. For collated printing, scroll down under change the setting for Click Click...
Page 235 PRINT JOBS MENU Press ENTER. ENTER PASSWORD – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password. SELECT JOB ALL JOBS To print all jobs stored under your password, press ENTER.
Page 236: Enter Password
– to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password. SELECT JOB ALL JOBS Press CANCEL.
Page 237 Store to Hard Disk Me and 98 Store to hard disk (job spooling) allows print jobs to be prepared and stored on the hard disk for printing on demand. This is good for forms, generic memos, letterhead stationery, etc. • If the hard disk memory is insufficient for the spooled data, DISK FULL is displayed and only one copy printed.
Page 238 Click the Device Options , then select Job Type Enter your 4-digit password (0000 to 9999): In the list, click features choice for that digit under for each digit of the password, making note of the number you entered. For collated printing, scroll down under change the setting for Click Click...
Page 239: Print Jobs Menu
Printing a Stored Document from The Front Panel Press to enter the menu mode. PRINT JOBS MENU Press ENTER. ENTER PASSWORD – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password.
Page 240 Press ENTER. ENTER PASSWORD – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password. SELECT JOB ALL JOBS Press CANCEL.
Page 241: Windows 2000 And Xp
Windows 2000 and XP The illustrations in this section show the Windows 2000 operating system. The Windows XP operating system dialog boxes appear slightly different, but the principles are the same. • N-up Printing: multiple pages on one sheet (see page 242) •...
Page 242 N-Up Printing (Printing Multiple Pages on One Sheet) 2000 and XP Open the file in your application and select In the Print dialog box, select the Postscript emulation printer. Windows XP only: click On the tab, under Layout number of pages. Windows XP only: click Click Print...
Page 243 Printing Booklets 2000 and XP Booklets are restricted to two pages per sheet, i.e., you can print a 5½'' x 8½'' booklet on 8½'' x 11'' paper. • You must have the duplex unit installed and enabled in order to print booklets. •...
Page 244 On the tab, under Layout Select Portrait Make sure Flip on Long Edge Sides(Duplex) Select the desired Windows XP only: click Click Print Windows: Postscript Emulation Driver • 244 Pages Per Sheet under Landscape Orientation is selected under Page Order to return to the , select Booklet...
Page 245 Printing Custom Page Sizes 2000 and XP The printer media size for the tray you’re using must be manually set in the driver to the custom paper size before use (range 3½'' to 8½'' [89 to 216 mm] wide x 5'' to 14'' [127 to 356 mm] long). One custom paper size can be defined in the Windows 2000 and XP Postscript emulation driver.
Page 246 On the tab., click Layout In the Paper Size Size Define your custom size in the dialog box which appears, then click twice. Click the Paper/Quality for the custom size paper from the 10. Windows XP only: click 11. Click Print. Windows: Postscript Emulation Driver •...
Page 247 Changing The Resolution for A Print Job 2000 and XP These instructions explain how to change the settings as you are printing a job. If you wish to change the settings to apply to all jobs (default settings): → • Click Start and Faxes •...
Page 248 4. On the Job Options click OK: = high resolution, slower speed: the default. Provides • Fine optimum results when printing graphics. = medium resolution, medium speed: choose this set- • Normal ting for documents with lower resolution graphics, line art, or text only.
Page 249 Duplex Printing (Printing on Both Sides of The Paper) 2000 and XP The optional duplex unit must be installed in the printer and enabled before duplex printing can be carried out. • Paper weight range 20 to 28 lb. US Bond (75 to 105 g/m²). •...
Page 250 On the tab, under Layout Flip on Long Edge Windows XP only: click Click Print Windows: Postscript Emulation Driver • 250 Print on Both Sides (Duplex) Flip on Short Edge to return to the , select dialog box. Print...
Page 251 Printing Watermarks 2000 and XP Open the file in your application and select In the dialog box, select the Postscript emulation printer. Print Windows XP only: click On the Job Options In the dialog box which appears, click or select a predefined watermark from the list box, then click Windows XP only: click Click Print...
Page 252 Collating 2000 and XP Open the file in your application and select In the dialog box, select the Postscript emulation printer. Print Windows XP only: click On the Job Options print, then select Windows XP only: click Click Print Windows: Postscript Emulation Driver • 252 Preferences tab, enter the number of Collate...
Page 253 Secure Printing (Printing Confidential Documents) 2000 and XP Secure printing allows the printing of confidential documents on printers that are shared with other users. First the document is assigned a password and processed to a print file which is saved on the hard disk drive.
Page 254: Print Jobs Menu
On the Job Options tab, select In the dialog box which appears, enter a password (PIN) of your choice (0000 to 9999), then click no dialog box appears, click Enter the number of copies to be printed, then select applicable. Windows XP only: click Click Print...
Page 255 Press ENTER. ENTER PASSWORD – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password. SELECT JOB ALL JOBS –...
Page 256 ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password. SELECT JOB ALL JOBS Press CANCEL. DELETE THE JOB Y=ENTER/N=CANCEL Press ENTER to delete the job, then press ON LINE. An alternative method of printing or deleting a confidential document is to use the Storage Device Manager.
Page 257 Proof and Print 2000 and XP Proof and Print lets you print a proof of a document for review and approval before printing the document in quantity. First the document is assigned a password and processed to a print file. The file is saved on the hard disk drive and one copy prints.
Page 258 On the Job Options tab, select In the dialog box which appears, enter a password (PIN) of your choice (0000 to 9999), then click no dialog box appears, click Enter the number of copies to be printed, then select applicable. Windows XP only: click Click Print...
Page 259 Press ENTER. ENTER PASSWORD – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password. SELECT JOB ALL JOBS –...
Page 260 – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password. SELECT JOB ALL JOBS Press CANCEL.
Page 261 Store to Hard Disk 2000 and XP Store to hard disk (job spooling) allows print jobs to be prepared and stored on the hard disk for printing on demand. This is good for forms, generic memos, letterhead stationery, etc. • If the hard disk memory is insufficient for the spooled data, DISK FULL is displayed and only one copy printed.
Page 262 On the Job Options tab, select In the dialog box which appears, enter a password (PIN) of your choice (0000 to 9999), then click no dialog box appears, click Enter the number of copies to be printed, then select applicable. Windows XP only: click Click Print...
Page 263 Press ENTER. ENTER PASSWORD – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password. SELECT JOB ALL JOBS –...
Page 264 ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password. SELECT JOB ALL JOBS Press CANCEL. DELETE THE JOB Y=ENTER/N=CANCEL Press ENTER to delete the job, then press ON LINE. An alternative method of printing or deleting documents stored on the Hard Disk Drive is to use the Storage Device Manager.
Page 265: Printing Overlays
Printing Overlays 2000 and XP What are Overlays? An Overlay can be a combination of graphics, fonts, or text that is stored in the printer's flash memory or on the hard disk drive, and printed whenever required. The result is similar to the Watermark feature, but with the ability to be much more elaborate.
Page 266 Once someone has set up all the necessary overlay files on the printer, other users only have to switch on the required settings in the printer driver to use the overlays. • If the hard disk memory is insufficient for the spooled data, copy printed.
Page 267 Select the Overlay Choose Create Form selections in the dialog box which appears and click Windows XP only: click Click Print Instead of sending the print job to the printer, this prompts you to save the print job on your PC's hard disk. Give the file a meaningful name.
Page 268: Windows Nt 4.0
Windows NT 4.0 • N-up Printing: multiple pages on one sheet (see page 269) • Custom Page Sizes (see page 270) • Selecting Print Resolution (see page 272) • Duplex Printing (see page 274) • Watermarks (see page 276) • Collating (see page 277) •...
Page 269 N-Up Printing (Printing Multiple Pages on One Sheet) NT 4.0 Open the file in your application and select In the dialog box, select the Postscript emulation printer, Print then click Properties On the Advanced Click Page Layout (N-UP) Option appears, select the desired number of pages to print per sheet. Click to return to the Click...
Page 270 Printing Custom Page Sizes NT 4.0 The printer media size for the tray you’re using must be manually set in the driver to the custom paper size before use (range 3½'' to 8½'' [89 to 216 mm] wide x 5'' to 14'' [127 to 356 mm] long). One custom paper size can be defined in the Windows NT 4.0 Postscript emulation driver.
Page 271 On the Page Setup the bottom of the custom size in the dialog box which appears and click Select the tray you are using in the box, then click Click to print the document Windows: Postscript Emulation Driver • 271 tab, select Postscript Custom Page Size drop-down list, then define the...
Page 272 Changing The Resolution for A Print Job NT 4,0 These instructions explain how to change the settings as you are printing a job. If you wish to change the settings to apply to all jobs (default settings): → • Click Start and Faxes •...
Page 273 3. On the Job Options Quality, then click OK: = high resolution, slower speed: the default. Provides • Fine optimum results when printing graphics. = medium resolution, medium speed: choose this set- • Normal ting for documents with lower resolution graphics, line art, or text only.
Page 274 Duplex Printing (Printing on Both Sides of The Paper) NT 4.0 The optional duplex unit must be installed in the printer and enabled before duplex printing can be carried out. • Paper weight range 20 to 28 lb. US Bond (75 to 105 g/m²). •...
Page 275 On the Page Setup select Long Side Click to print the document. Windows: Postscript Emulation Driver • 275 tab, under Print on Both Sides(Duplex) Short Side...
Page 276 Printing Watermarks NT 4.0 Open the file in your application and select In the dialog box, select the Postscript emulation printer, Print then click Properties On the Job Options In the dialog box which appears, click or select a predefined watermark from the list box, then click Click to return to the Click...
Page 277 Collating NT 4.0 Open the file in your application and select In the dialog box, select the Postscript emulation printer, Print then click Properties On the Job Options print, then select Click to return to the Click Windows: Postscript Emulation Driver • 277 tab, enter the number of Collate dialog box.
Page 278 Secure Printing (Printing Confidential Documents) NT 4.0 Secure printing allows the printing of confidential documents on printers that are shared with other users. First the document is assigned a password and processed to a print file which is saved on the hard disk drive.
Page 279: Print Jobs Menu
On the Job Options In the dialog box which appears, enter a password (PIN) of your choice (0000 to 9999), then click no dialog box appears, click Enter the number of copies to be printed, then select applicable. Click to return to the Click Print The document is processed to a print file and stored on the printer’s...
Page 280 Press ENTER. ENTER PASSWORD – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password. SELECT JOB ALL JOBS –...
Page 281 – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password. SELECT JOB ALL JOBS Press CANCEL.
Page 282 Proof and Print NT 4.0 Proof and Print lets you print a proof of a document for review and approval before printing the document in quantity. First the document is assigned a password and processed to a print file. The file is saved on the hard disk drive and one copy prints.
Page 283 On the Job Options In the dialog box which appears, enter a password (PIN) of your choice (0000 to 9999), then click no dialog box appears, click Enter the number of copies to be printed, then select applicable. Click to return to the Click Print The document is processed to a print file and stored on the printer’s...
Page 284 Press ENTER. ENTER PASSWORD – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password. SELECT JOB ALL JOBS –...
Page 285 – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password. SELECT JOB ALL JOBS Press CANCEL.
Page 286 Store to Hard Disk NT 4.0 Store to hard disk (job spooling) allows print jobs to be prepared and stored on the hard disk for printing on demand. The job is password protected. • If the hard disk memory is insufficient for the spooled data, DISK FULL is displayed and only one copy printed.
Page 287 On the Job Options In the dialog box which appears, enter a password (PIN) of your choice (0000 to 9999), then click no dialog box appears, click Enter the number of copies to be printed, then select applicable. Click to return to the Click Print The document is processed to a print file and stored on the printer’s...
Page 288 Press ENTER. ENTER PASSWORD – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password. SELECT JOB ALL JOBS –...
Page 289 – to set the number for the first digit of the password, then press ENTER to engage the number and move to the next digit: ENTER PASSWORD Repeat step 3 for each of the remaining digits in the password. SELECT JOB ALL JOBS Press CANCEL.
Page 290 Printing Overlays NT 4.0 What are Overlays? An Overlay can be a combination of graphics, fonts, or text that is stored in the printer's flash memory or on the hard disk drive, and printed whenever required. The result is similar to the Watermark feature, but with the ability to be much more elaborate.
Page 291 Once someone has set up all the necessary overlay files on the printer, other users only have to switch on the required settings in the printer driver to use the overlays. • If the hard disk memory is insufficient for the spooled data, copy printed.
Page 292: Software Utilities
Downloading The Print File To Use as An Overlay Use the Storage Device Manager utility to download the file for use as an overlay. See “Storage Device Manager Utility for Windows” on page 296. Software Utilities ______________ Overview These programs are located on the Drivers CD supplied with your printer.
Page 293: Color Swatch Utility
General Information The Color Swatch Utility allows you to print swatches of color samples on your Oki color printer. The swatches are used with your software program to select and reproduce color accurately. The swatches represent selected samples of the Oki color printer's color palette and provide corresponding RGB values which can be used to set up the desired colors for your printed documents.
Page 294 Using the Color Swatch Utility Selecting Colors When you load the utility, a swatch page displays commonly used colors. Select print to print sample pages. Color Samples Use the color blocks to pick the specific colors that you want to appear in your printed document.
Page 295 Creating Custom Swatch Colors If you don't find your desired color, you can create or customize colors: Select Custom Swatch On the pop-up window, there are 3 slide bars that allow you to customize swatches: – bar changes the hue of the swatches, for example, red to green or blue to yellow.
Page 296: Storage Device Manager Utility For Windows
Storage Device Manager Utility for Windows General Information Storage Device Manager requires Microsoft Internet Explorer 4.0 or higher to run. Storage Device Manager (SDM) lets you manage • The 20 GB internal hard disk drive. • The printer’s built-in 2 MB flash memory. Windows: Software Utilities •...
Page 297 Summary of Storage Device Manager Functions • Create or modify a project. • Download files to a printer. • Add or remove printers being administered. • Reboot the printer. • Manage the Proof & Print and Secure Print spooler queues on the internal hard disk drive.
Page 298 Start Programs → Manager Oki Storage Device Manager The SDM - Printer Discovery dialog box opens. Select the appropriate computer connection(s), then click The printer searches for connected printers and places icons in the window at the bottom of the dialog box.
Page 299: Using Storage Device Manager
3. Click Exit. The Storage Device Manager dialog box opens. Using Storage Device Manager On-Line Help • From the main Storage Device Manager window, click Help Topics from the Help pull-down menu. • From other Storage Device Manager windows, click the Help button. Administration On network systems, the Administrator oversees the Storage Device Manager software and can use it to manage and monitor the...
Page 300 • Reboot the printer. • Delete files. (Show Resources is the preferred method.) With Show Resources, you can browse to the file, click it, click Delete, then click OK to confirm the deletion. Using Administrator Functions to delete a file requires that you print out a File List, then use the information in the File List to type in the exact path (case sensitive) to the file.
Page 301 Setting Up an Administrative Password With the Storage Device Manager program open, click Administrator Functions Passwords consist of eight digits, letters or numbers, and are case sensitive. Type in the default password (p1xs7d0m) under , then click Password Type the 8-digit, alpha-numeric password of your choice under New Password Type the password again under New Password Accepted appears.
Page 302 Creating PostScript Forms PostScript forms are the ones to use if you are not experienced with PCL Macro commands. Creating & Downloading a PostScript Project Remember that file names and paths are case sensitive. Step 1: Create the Forms in Your Software Application Create the document in your software application.
Page 303 → Click Projects The Project dialog box opens. → Click Projects Save Project the project on your hard drive or your network, then click Step 3: Add Files to the Project → Click Projects The Open dialog box appears. Make sure PRN files (*.prn) drop-down list.
Page 304 Step 4: Check the Location for Storing the Files in the Printer’s Memory • If your printer is equipped with an internal hard disk drive, the Storage Device Manager will automatically save the forms to the PostScript partition on the hard drive. •...
Page 305 Creating PCL Macros (Forms) Unless you are experienced with PCL macro commands, it is best to stay with the PostScript Forms. There are two basic processes to producing PCL macros: • A: Creating and downloading the PCL project • B: Test printing the macro A: Creating and Downloading a PCL Project Remember that file names and paths are case sensitive.
Page 306 Step 3: Convert the Files to Binary (.bin) Format → Click Projects The Filter Printer Patterns dialog box appears. Make any adjustments in the settings. Example If you create a black oval in MS Paint and leave all the color command filters checked, the black oval will print as a black rectangle when the overlay is used.
Page 307 Step 4: Add the bin Files to the Project You can also add files to the project by opening either My Computer or Microsoft Explorer, browsing to the directory where the prn files are stored, then selecting the files and dragging them into the Project box. →...
Page 308 The Test Macro dialog box appears. Enter the ID number for the macro file you wish to print (you can get this from the File List printout: look under Volume 0; e.g., for 2:OKI.BIN, enter 2), then click Command Issued appears. Click and wait for the macro to print.
Page 309 Maintaining the Internal Hard Drive and Flash Memory HDD Print Jobs The HDD Print Jobs feature allows you to view and delete the Proof & Print and Secure Print files stored on the printer’s internal hard drive. Open Storage Device Manager and click the icon for the printer whose contents you wish to view.
Page 310 Click • Print Job(s) ically deleted. Show Resources Use the Show Resources feature to delete files from the internal hard drive and flash memory. Open Storage Device Manager and click the icon for the printer whose contents you wish to view. →...
Page 311 Using Overlays Before overlays can be printed, they must be created in a software application and saved as a print file, then downloaded to the printer’s internal hard disk drive or flash memory using Storage Device Manager. General Information To use overlays, the Storage Device Manager software must be installed.
Page 312 If the hard disk memory is insufficient for the spooled data, the • message DISK FULL appears. If the software application has a collate print option, it must be • turned OFF before you print overlays. Overlay printing cannot be done using the Windows 2000 •...
Page 313 To print a sample of an overlay to see what it looks like, click • the name under If you wish to add more overlays to the list, click • , then fill in the appropriate information in the lays dialog box and click lays Click...
Page 314 Click Define overlays Under Overlay Name Under , enter the ID number for the file saved using ID Value Storage Device Manager (see the File List printout). In the Print on Pages overlay is to be printed, or select numbers under Custom pages Click , then click...
Page 315 Click the Job Options Click Define overlays The Define overlays dialog box appears. Under Defined overlays Make any changes, then click Click Close Click and close the Printers dialog box. Deleting Defined Overlays: Me/98/95 PCL → Click Start Settings Right click the PCL printer icon, then click The Properties dialog box appears.
Page 316 Using Overlays: Windows Me/98/95/PostScript Defining Overlays: Me/98/95 PostScript → Click Start Settings Right click the PostScript printer icon, then click The Properties dialog box appears. Click the Job Options tab. Click the Overlay button. Set up an Overlay Group: Click The Define Overlays dialog box appears.
Page 317 Click up to four groups under Click and print the document. Editing Defined Overlays: Me/98/95 PostScript → Click Start Settings Right click the PostScript printer icon, then click The Properties dialog box appears. Click the Job Options Under Defined Overlay modify, then click The Define Overlays dialog box appears.
Page 318 Using Overlays: Windows NT 4.0 PCL Defining Overlays: NT 4.0 PCL → Click Start Settings Right click the PCL printer icon, then click The Default dialog box appears. Click the Job Options Click Define overlays The Define overlays dialog box appears. Under Overlay Name Under...
Page 319 To print a sample of an overlay to see what it looks like, click its name in the Defined Overlays box, then click Test Print. If you wish to add more overlays to the list, click Define Overlays, then fill in the appropriate information in the Define overlays dialog box and click Close.
Page 320 Click and close the Printers dialog box. Defining Overlays: NT 4.0 PCL → Click Start Setting Right click the PostScript printer icon, then click Defaults The Default dialog box appears. Scroll down to Layout Under Change ‘Overlay’ Setting Click Setting of Overlay The Setting of Overlay dialog box appears.
Page 321 Using Overlays: Windows NT 4.0 PostScript Defining Overlays: NT 4.0 PostScript → Click Start Settings Right click the PostScript printer icon, then click Defaults The Default dialog box appears. Click the Job Options Click The Define Overlays dialog box appears. Under Overlay Name are creating.
Page 322 Select the Overlay group(s) you wish to print, then click The group will appear in the Active Overlay Groups list. Click twice and print the document. Editing Defined Overlays: NT 4.0 PostScript → Click Start Settings Right click the PostScript printer icon, then click Defaults The Defaults dialog box appears.
Page 323: Printsupervision Utility
It provides a full range of management functions for Oki printers, and for other brands of printers as well. Installing PrintSuperVision Place the driver CD supplied with your printer in your CD-ROM drive and wait for the Menu Installer to open.(If the CD does not...
Page 324: Additional Information
Additional Information For more information: • See your on-line OkiLAN supplied with your printer) • Click on Help in the PrintSuperVision program. Network Printer Status Utility This utility creates an additional tab (STATUS) in the PostScript and PCL drivers that allows the client to monitor the selected printer’s status.
Page 325 Click to see the device settings. UPDATE The following window displays: Click on an item to see this information: Trays: Duplex: Disk/Memory: Toner Remaining: If the Automatic Status Check box is checked, this utility will “ping” the printer each time you open the Printer Properties dialog in the printer driver.
Page 326: Lpr Utility
LPR Utility The LPR Utility allows you to print directly to a printer on the network without a print server. It creates an Oki Printer Port, and installs a pop- up status box so you can monitor printer status. LPR operates in Windows Me/98/95, Windows NT 4.0, Windows 2000, and Windows XP operating systems.

This manual is also suitable for:

Es1624n Es1624nccs Executive series 1624n

Oki ES 1624n MFP User Manual

Black Printing

Color Printing

PCL Emulation Driver

Postscript Emulation Driver

Software Utilities

Quick Links

Need help?

Questions and answers

Related Manuals for Oki ES 1624n MFP

Summary of Contents for Oki ES 1624n MFP

This manual is also suitable for:

Table of Contents
