Oki C7300 Installation Instructions Manual
Hard disk drive install replacement instructions
Hide thumbs
Also See for C7300:
- User manual (238 pages) ,
- Reference manual (44 pages) ,
- Software installation manual (20 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for Oki C7300
Summary of Contents for Oki C7300
-
Page 1: Hard Disk Drive
Hard Disk Drive Installation Instructions HDD PART NUMBER 70040902... -
Page 2: Prepare The Printer
Prepare the Printer Note: Models designated “Letter/Legal” are those which take paper up to legal size. Models designated “Tabloid” take the larger tabloid and tabloid extra size paper as well. 1. Turn off the printer and unplug the power cord. 2. - Page 3 4. Grasp the control board and loosen it by wiggling it back and forth, then slide it out of the printer. Letter/Legal Models Tabloid Models...
-
Page 4: Install The Hard Disk Drive (Hdd)
Install the Hard Disk Drive (HDD) 1. Locate the drive connector (1) on the control board: 2. Remove the HDD from its shipping package. - Page 5 3. Lift the handle on the HDD and lower it onto the control board. 4. Insert the board firmly into the connector and press down on the handle to lock it in place.
-
Page 6: Complete The Installation
Complete the Installation 1. Align the bottom of the control board with the track in the printer and slide it back into place. Letter/Legal Models Tabloid Models... - Page 7 2. Reinstall the screws at the top and bottom of the board. Letter/Legal Models Tabloid Models 3. Reattach the interface cable, then plug the power cord into the power outlet and turn on the printer.
-
Page 8: Check For Proper Installation
Check for Proper Installation 1. On the printer control panel, press MENU once or twice until INFORMATION MENU appears on the display. 2. Press SELECT. PRINT MENU MAP appears on the display. 3. Press SELECT. The MenuMap prints. 4. Check the MenuMap printout: •... -
Page 9: Print Driver
Activate the Hard Disk in the Print Driver ® Windows PCL Driver → Settings → Printers 1. Click Start 2. Right click the Oki PCL driver icon, then click Printing Preferences Properties , depending on the Document Defaults Windows system. 3. Click tab. - Page 10 PostScript Driver, OS 10.3 Note: Mac OS 10.1x and 10.2x do not have Configure printer activated. 1. Open the Printer Setup Utility 2. Select the appropriate OKI printer. 3. Click Show Info 4. Select from the drop-down Installable Options list.
-
Page 11: Limited Warranty
Limited Warranty. Oki Data will repair (or at its option, replace) at no charge, any defective part(s) of the OPTION for one (1) year from the date of purchase. This Limited Warranty extends to the original purchaser only. - Page 12 Oki Data service center. THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE ON THE FACE HEREOF AND DESCRIBED ABOVE. NO WARRANTIES WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF...
- Page 13 1-800-OKI-DATA (U.S. and Canada), or by contacting one of the service depots listed on the next page. This Limited Warranty applies to this Oki Data Option. However, the procedure for obtaining service may vary outside the continental United States. Contact your Oki Data dealer for such warranty service information.
- Page 14 2735 Matheson Blvd. East, Unit 1 Mississauga, Ontario Canada L4W 4MB Tel: 1-800-654-3282 Fax: 1-905-238-4427 MEXICO __________________________________ Oki Data de Mexico, S.A. de C.V. Mariano Escobedo No. 748 - 8 Piso Col Anzures, e.p. 11590 Mexico, DF Tel: 52-55-263-8780 Fax: 52-55-250-3501 BRAZIL ___________________________________ Oki Data do Brasil Informática, Ltda.
- Page 16 Oki Data Americas, Inc. 2000 Bishops Gate Blvd. Mt. Laurel, NJ 08054-4620 Tel: (800) 654-3282 Fax: (856) 222-5320 http://www.okidata.com 58365202...
