Kicker Comp Woofer Technical Manual page 24

1.75 cf, Fb=40Hz
.15 cf = Port Vol.
C10-BOX-VENTED-175
B
F
29-1/4
Side View
C
Kicker Comp Subwoofers
Recommended Applications / Version 2.0
Page 24
Side View
D
13-1/4
1-1/2
12
∅
6
6
Cut List: 3/4" MDF
(2) 12 3/4" x 12" Top & Bottom(A)
(2) 12 3/4" x 27 3/4" Sides(B)
(2) 10 1/2" x 27 3/4" Front & Back(C)
(1) 10 1/2" x 11" Port(D)
(4) 2" x 2" Gusset(E)
-9-5/32
12-3/4
3/4
POWER HANDLING:
125W with 25HZ Subsonic Filter
set at 24db/Octave.
Without subsonic filter 50W
10-1/2
A
R3/8
1-1/2
3/4
