Kicker Comp Woofer Technical Manual page 20

1.00 cf, Fb=44Hz
.14 cf = Port Vol.
Comp8-BOX-VENTED-100
B
E
21-3/4
Front View
C
4-13/16
Kicker Comp Subwoofers
Recommended Applications / Version 2.0
Page 20
Side View
D
13-3/4
1-1/2
9 1/2
6-7/8
∅
4-13/16
POWER HANDLING:
55W with 25Hz Subsonic Filter
set at 24db/Octave.
Without subsonic filter 35W
Cut List: 3/4" MDF
(2) 13 3/4" x 9 1/2" Top & Bottom(A)
(2) 13 3/4" x 20 1/4" Sides(B)
(2) 8" x 20 1/4" Front & Back(C)
(1) 8" x 13" Port(D)
(4) 2" x 2" Gusset(E)
13-3/4
3/4
8
A
R 3/8
1-1/2
3/4
