Kicker Comp Woofer Technical Manual page 13

Kicker Comp Subwoofers
Recommended Applications / Version 2.0
Page 13
Vented Box Response Curves
C12 1.75cu.ft./2.0cu.ft./2.25cu.ft.
C
C12 Compact Enclosure Response Curve
C12 Street Bass Response Curve
C12 SPL/Deep Bass Enclosure Response Curve
dB G r a p h 1 > A c o u s t i c O n A x i s R e s p o n s e : S P L , P h a s e
100
95
90
85
80
75
70
65
60
1 0 F r e q u e n c y
C15 3.0cu.ft./3.5cu.ft./4.0cu.ft.
C
C15 Compact Enclosure Response Curve
C15 Street Bass Response Curve
C15 SPL/Deep Bass Enclosure Response Curve
dB G r a p h 1 > A c o u s t i c O n A x i s R e s p o n s e : S P L , P h a s e
100
95
90
85
80
75
70
65
60
1 0 F r e q u e n c y
5 0 1 0 0 H z
5 0 1 0 0 H z
C
5 0 0 1 K
C
5 0 0 1 K
