- Page 1 Split Type Inverter Room Air Conditioner OPERATION MANUAL MODELS AY-X09LCJ AE-X09LCJ AY-X12LCJ AE-X12LCJ AY-X18LCJ AE-X18LCJ Thank you for choosing a SHARP air conditioner. Please read this manual thoroughly before using your air conditioner and keep it for future reference.
- Page 3 and cleaning Specifications NOTE: The figures in this manual may be different to the actual product. that should be prevented. that Collection of such waste should be separated for special treatment as required by local regulations.
- Page 5 To change the airflow direction, adjust the vertical and lateral air flow direction by using the , pl ease ref er the mat ter to remote control. a qualified air conditioner contractor. objects Don’t expose animals and plants directly to the output air flow as it may have a detrimental effect on them.
- Page 6 Air conditioners absorb heat in the room and transmits it to the outdoor unit, so that indoor ambient temperatures are decreased. Its cooling capacity will increase or decrease according to outdoor ambient temperature. If the unit is running in COOL mode and in low ambient temperature, frost may be formed on the heat exchanger.
-
Page 7: Name And Function Of Each Part
Na me and function of each part... - Page 8 Note: Be sure that there are no obstructions between receiver and remote control; Don't drop or throw the remote control; Don't spill any liquid on the remote control; Don't leave remote control directly in sunlight or hot environments. Pres s this button to turn Sleep mode on or off.
- Page 9 Name and function of wireless remote control Some buttons on this control are not applicable to this unit. Preset temperature is increased by pressing this button. Continuously pressing and holding for 2 seconds changes the temperature rapidly. Preset temperature is decreased by pressing this button.
- Page 10 Some buttons on this control are not applicable to this unit. Press this button to select Timer On setting. Pressing the + or - button during the first 5 seconds adjusts the time value by one minute each time pressed. Holding the + or - button down for more than 2 seconds changes the time rapidly.
- Page 11 Press On /Off button to start or stop operation. to switch On or Off the display on the main unit. odels to switch BLOW the fan will con tinu e to bl ow af ter the un it is stop pe d to rem ove BLOW BLOW BLOW...
- Page 12 o set the guide louvre to a desired position, press Swing Up and Down button continuously for more than 2 seconds and hold until desired position is achieved. Releasing the button now stops the swinging at the desired position. After Swing Up and Down mode is switched on, pressing the button again within 2 seconds circulates between the various settings.
- Page 13 on the main unit. Operation will be in Auto Run mode and the temperature setting or fan speed cannot be changed. To operate: Press the AUTO/STOP button and the unit will enter into AUTO RUN mode. The microcomputer will monitor the room temperature to select the (COOL, HEAT, FAN) mode automatically, to obtain the comfortable effect.
-
Page 14: Care And Cleaning
Care and Cleaning at the circuit breaker to prevent the risk of electric shock. pour or spray liquids directly onto the indoor or outdoor units for cleaning, to prevent risk of electric shock. Only wipe the Rotate the front panel upwards in the direction of the arrow. - Page 15 Care and Cleaning Removing Rotate the front panel upwards in the direction of the arrow. Pull the air filter downwards and remove from the unit. water temperature should be and leave to dry naturally in a shady location. Never dry it with a heater or open flame, as fire or deformation may occur.
- Page 16 The air conditioner is not user serviceable. if attempt to If a bad smell has been accumulated from the environment, clean the air filter. If smells persist, contact your Approved Service Centre to arrange cleaning. fluid gurgling noises. This is not a fault - it is the sound of flowi ng refrigerant.
- Page 17 will Has the circuit breaker device tripped off? Have the wiring or connections been damaged?Please report to an authorised air conditioner contractor. Is the fan other working Check that there is no magnetic or electrical interference near the main unit that may be affecting the operation of the controller.
- Page 18 flow is stopped fros t can be for med on the outdoor heat exchanger. The unit will automatically defrost and the indoor unit will stop blowing air for 3-12 mins. During defrost operation, water or vapour may be emitted. ,disco nnect from the power supply, and report to an authorised air conditioner contractor in the following situations.
- Page 19 The unit mus t only be installed by authorised air conditioner contractors according to mun icipal or governmen t regulations and in compl iance wi th this man ual. The unit should be installed with a dedicated electrical circuit, and a circuit breaker should be fitted in accordance with regulations.
- Page 20 A dedicated power supply circuit should be used, in accordance with local electrical safety regulations. The product should be installed by a licenced air conditioning contractor in accordance with AS/NZS3000 and your electrical supplier's rules. A circuit breaker should be installed. WARNING: inadequate or incorrect electrical connections may cause electrocution or fire.
- Page 21 Height...
-
Page 22: Installing The Indoor Unit
Installing the indoor unit is at the lef t, the righ t si de sh ou ld be slightly higher to allow drainage. Spirit Level proper Drainage hoses passing through indoor areas should be wrapped with insulation material. by rotating upwards. Remove the electrical connection cover plate and screw. - Page 23 Installing the indoor unit All interconnecting wiring between indoor and outdoor unit must be performed by a licenced electrical contractor in accordance with AS/NZS3000. unit to screws adequately to prevent loosening. Ensure the electrical connections are properly earthed to prevent electrical shocks. Ensure all wiring connections are secure and the cover plates are reinstalled properly.
-
Page 24: Installing The Outdoor Unit
Installing the Outdoor Unit Remove electrical connection access plate (either right hand side or front) from the outdoor unit. Replace access plate (either right hand side or front) on the outdoor unit. Incorrect unit failure. has been fitted,... - Page 25 Installing the Outdoor Unit soapy gas detection are leaking. Outdoor attach satisfactorily.
- Page 26 satisfactory to the product. product. Are the inlet and outlet air openings blocked? Is the quantity of gas charge sufficient may be for the length of pipe run? insufficient.
-
Page 27: Specifications
Specifications Model AY-X09LCJ; AE-X09LCJ Function Cooling Heating Rated Voltage (V) 220-240 Frequency (Hz) Total Capacity (W) (High/Standard): 2600/1188 2805/1109 Total Capacity (Btu/h) (High/Standard): 9000/4063 9800/3792 Power Input (W) (High/ Standard/Low): 1200/610/264 1250/670/230 Rated Input (W) Rated Current (A) Air Flow Volume (m Dehumidifying Volume (l/h) EER / C.O.P (W/W) 4.25... - Page 28 Model of Outdoor Unit AE-X09LCJ Compressor SANYO Manufacturer/trademark Compressor Model C-6RZ110H1A Compressor Type Twin rotary L.R.A. (A) Compressor RLA(A) 4.59 Compressor Power Input(W) Overload Protector Int11l-3979 Throttling Method Capillary throttling Starting Method Transducer starting Working Temp Range (℃) -7℃≤T≤43℃ Condenser Aluminum fin-copper tube Pipe Diameter (mm) 9.52...
- Page 29 Model AY-X12LCJ；AE-X12LCJ Function COOLING HEATING Rated Voltage (V) 220-240V~ Frequency (Hz) Total Capacity (W) (High/Standard): 3500/ 1233 3850/830 Total Capacity (Btu/h) (High/ Standard): 12000/4200 13000/2830 Power Input (W) (High/ Standard/Low) 1400/1000/262 1450/1066/233 Rated Input (W) (High/ Standard) 1000 1066 Rated Current (A) (High/ Standard) Air Flow Volume (m Dehumidifying Volume (l/h) EER / C.O.P (W/W)
- Page 30 Model of Outdoor Unit AE-X12LCJ Compressor Manufacturer/trademark SANYO Compressor Model C-6RZ110H1A Compressor Type Twin rotary L.R.A. (A) Compressor RLA(A) 4.59 Compressor Power Input(W) Overload Protector Int11l-3979 Throttling Method Capillary throttling Starting Method Transducer starting Working Temp Range (℃) -7℃≤T≤43℃ Condenser Aluminum fin-copper tube Pipe Diameter (mm) 9.52...
- Page 31 Model AY-X18LCJ；AE-X18LCJ Function COOLING HEATING AC Rated Voltage (V) 220-240V~ Rated Frequency (Hz) Total Capacity (W) (High/Standard): 5300/1610 5600/1217 Total Capacity (Btu/h) (High/Standard): 18000/5500 19100/4150 Power Input (W) 2100/1540/370 2300/1610/398 Rated Input (W) 1540 1610 Rated Current (A) 10.7 11.5 Air Flow Volume (m Dehumidifying Volume (l/h) EER / C.O.P (W/W)
- Page 32 Model of Outdoor Unit AE-X18LCJ Compressor Manufacturer/trademark SANYO Compressor Model C-6RVN93H0N Compressor Type twin rotary L.R.A. (A) Compressor RLA(A) Compressor Power Input(W) 1610 Overload Protector 1NT11L-3979 Throttling Method Capillary Starting Method Capacitor Working Temp Range (℃) -7℃≤T≤43℃ Condenser Aluminum fin-copper tube Pipe Diameter (mm) Rows-Fin Gap(mm) 2-1.4...
- Page 34 SHARP APPROVED SERVICE CENTRE VISIT OUR WEBSITE AT www.sharp.net.au OR CALL SHARP CUSTOMER CARE 1300 135 022 (LOCAL CALL COST APPLY WITHIN AUSTRALIA) SHARP CORPORATION OF AUSTRALIA PTY LTD SHARP FOR LOCATION ENQUIRIES WITHIN NEW ZEALAND REGARDING YOUR LOCAL SHARP APPROVED SERVICE CENTRE VISIT OUR WEBSITE AT www.sharp.net.nz...
- Page 36 SHARP CORPORATION OF AUSTRALIA PTY LTD ABN 40 003 039 405 1 Huntingwood Drive HUNTINGWOOD NSW 2148 www.sharp.net.au 6612990...
