- Page 1 XV - Z9000E PROJECTOR OPERATION MANUAL PROJEKTOR BEDIENUNGSANLEITUNG PROJECTEUR MODE D’EMPLOI PROJEKTOR BRUKSANVISNING PROYECTOR MANUAL DE MANEJO PROIETTORE MANUALE DI ISTRUZIONI PROJECTOR GEBRUIKSAANWIJZING...
- Page 2 This equipment complies with the requirements of Directive 89/336/EEC and 73/23/EEC as amended by 93/68/EEC. Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/ EWG und 73/23/EWG mit Änderung 93/68/EWG. Ce matériel répond aux exigences contenues dans les directives 89/ 336/CEE et 73/23/CEE modifiées par la directive 93/68/CEE. Dit apparaat voldoet aan de eisen van de richtlijnen 89/336/EEG en 73/ 23/EEG, gewijzigd door 93/68/EEG.
-
Page 3: Operation Manual
Before using the projector, please read this operation manual carefully. OPERATION MANUAL ENGLISH IMPORTANT For your assistance in reporting the loss or theft of your Model No.: XV - Z9000E Projector, please record the Serial Number located on the bottom of the projector and retain this information. Serial No.: Before recycling the packaging, please be sure that you have checked the contents of the carton thoroughly... -
Page 4: Caution Concerning The Lamp Replacement
ALLOW 1 HOUR TO COOL BEFORE REPLACING AVANT DE PROCEDER AU REMPLACEMENT DE LA LAMPE. THE LAMP. REPLACE WITH SAME SHARP LAMP NE REMPLACER QUE PAR UNE LAMPE SHARP DE TYPE BQC-XVZ9000/ 1. UNIT TYPE BQC-XVZ9000/ 1 ONLY. RAYONS ULTRAVIOLETS : PEUVENT ENDOMMAGER LES YEUX. -
Page 5: Important Safeguards
IMPORTANT SAFEGUARDS ATTENTION: Please read all of these instructions before you operate your Projector for the first time. Save these instructions for future reference. For your own protection and prolonged operation of your Projector, be sure to read the following “IMPORTANT SAFEGUARDS”... -
Page 6: Caution Concerning The Lamp Unit
ALLOW 1 HOUR TO COOL BEFORE REPLACING AVANT DE PROCEDER AU REMPLACEMENT DE LA LAMPE. THE LAMP. REPLACE WITH SAME SHARP LAMP NE REMPLACER QUE PAR UNE LAMPE SHARP DE TYPE BQC-XVZ9000/ 1. UNIT TYPE BQC-XVZ9000/ 1 ONLY. RAYONS ULTRAVIOLETS : PEUVENT ENDOMMAGER LES YEUX. - Page 7 IMPORTANT SAFEGUARDS Temperature Monitor Function If the projector starts to overheat due to setup problems or a dirty air filter, “TEMP.” and “ ” will flash in the lower-left corner of the picture. If the temperature continues to rise, the lamp will turn off, the TEMPERATURE WARNING indicator on the projector will flash, and after a 90-second cooling- off period the power will shut off.
-
Page 8: Outstanding Features
Outstanding Features 1. Wide DMD™* (Digital Micromirror Device) Chip The DMD Chip allows for a higher contrast image. Also, as it has an aspect ratio of 16:9, it is possible to view, in the best possible picture frame, software recorded on 16:9 from DVD or DTV. Digital Light Processing, DLP, Digital Micromirror Device and DMD are trademarks of Texas Instruments. -
Page 9: How To Access The Pdf Operation Manuals
How to Access the PDF Operation Manuals of SharpVision Manager PDF operation manuals of supplied GAMMA control software “SharpVision Manager” in several languages are included in the CD-ROM. To utilize these manuals, you need to install Adobe Acrobat Reader on your PC (Windows or Macintosh). -
Page 10: Table Of Contents
Contents Menu Bars ..........27 Adjusting the Picture ......... 29 Important Information Adjusting the Computer Images (RGB menu only) ......... 32 IMPORTANT SAFEGUARDS ....3 Reducing Image Noise Outstanding Features ......6 (VIDEO menu only) ......36 How to Access the PDF Operation Turning On/Off the On-screen Display .. -
Page 11: Part Names
Part Names Numbers next to the part names refer to the main pages in this manual where the topic is explained. Projector Front and Top View Lens shift dial Zoom knob TEMPERATURE WARNING indicator LAMP REPLACEMENT indicator Focus ring POWER indicator Adjuster Intake ventilative hole Adjuster... - Page 12 Part Names Numbers next to the part names refer to the main pages in this manual where the topic is explained. Projector Side and Rear View Intake ventilative hole Intake ventilative hole Exhaust ventilative hole Remote control sensor S-VIDEO INPUT 3 terminal (4-pin Mini DIN) RS-232C port INPUT 5 COMPUTER-RGB port...
-
Page 13: Part Names
Part Names Remote Control Front View Top View Remote control signal transmitter POWER buttons (ON/OFF) MENU button ENTER button ADJUSTMENT buttons (∂/ƒ/ß/©) Wired remote control jack UNDO button INPUT 1 button INPUT 3 button INPUT 2 button INPUT 5 button INPUT 4 button RESIZE button THEATRE MODE button... -
Page 14: Supplied Accessories
Supplied Accessories Remote control Two AA size batteries Power cord (For Europe except (For U.K., Hong Kong U.K.) and Singapore) • The configuration of wall outlets differs from country to country. Use the power cord that corresponds to the wall outlet in your country. -
Page 15: Connections
Connections Power Supply Connecting the Power Cord Plug the supplied power cord into the AC socket on the back of the projector. Power cord CAUTION • Make sure the power cord is firmly connected into the AC socket. • The configuration of wall outlets differs from country to country. Use the power cord that corresponds to the wall outlet in your country. •... - Page 16 Connecting to Video Equipment Projector S-video cable (commercially available) 2 To S-video output terminal Video cable 2 To video output terminal VCR, Laser disc player, DVD player or DTV decoder Connecting a video source (DVD player or DTV decoder) using the RCA INPUT 1 or 2 terminals 1 Connect each RCA connector of a component cable to the corresponding RCA INPUT 1 or 2 terminals on the projector.
-
Page 17: Connecting To A Computer
• The RS-232C function may not operate if your computer port is not correctly set up. Please refer to the operation manual of the computer for details. • The arrows (→, ↔) in the configuration above indicate the direction of the signals. • A Macintosh adaptor may be required for use with some Macintosh computers. Contact your nearest Sharp Authorised Projector Dealer or Service Centre. -
Page 18: Operating The Remote Control
Operating the Remote Control The remote control can be used to control the projec- tor within the range shown on the left. Remote Control • The signal from the remote control can be reflected off a 30˚ screen for easy operation. However, the effective distance of the signal may differ due to the screen material. -
Page 19: Power On/Off
Power ON/OFF Projector Press POWER ON. • The flashing blue LAMP REPLACEMENT indicator shows that the lamp is warming up. Wait until the indicator stops flashing before operating the projector. Remote control POWER • If the power is turned off and then immediately turned buttons on again, it may take a short while before the lamp turns on. -
Page 20: Setting Up The Screen
Setting Up the Screen Using the Adjustment Feet You can adjust the height of the image by raising the projector with the foot releases. 1 Press the foot releases and lift the projector to the desired angle. 2 Remove your hands from the foot releases. Once the adjustment feet have locked in position, release the projector. -
Page 21: Keystone Correction
Keystone Correction This function can be used to adjust the Keystone settings. Press KEYSTONE on the remote control. 1,4a Press ENTER to display the test pattern. Press to make adjustments. a. Press KEYSTONE to return to the normal screen. b. To reset the Keystone setting, press UNDO. •... -
Page 22: Adjusting The Projection Distance
Adjusting the Projection Distance Position the projector perpendicular to the screen with all feet flat and leveled to achieve an optimal image. Move the projector forward or backward if the edges of the image are distorted. • The projector lens should be centred in the middle of the screen. If the lens centre is not perpendicular to the screen, the image will be distorted, making viewing difficult. - Page 23 Adjusting the Projection Distance Upper and Lower Lens Shift Position • This projector is equipped with a lens shift function that lets you adjust the projection height. • Adjust it to match the setup configuration. • The screen can be moved maximum the length of one screen vertically using the lens shift. •...
-
Page 24: Image Projection
Ceiling-mount Projection • It is recommended that you use the optional Sharp ceiling-mount bracket for this installation. • Before mounting the projector, contact your nearest... -
Page 25: Using The Operation Buttons
Using the Operation Buttons Selecting the Input Signal Source Press INPUT on the projector, INPUT 1, INPUT 2, INPUT 3, INPUT 4 or INPUT 5 on the remote control to select the desired input mode. • When no signal is received, “NO SIGNAL” will be displayed. When a signal that the projector is not preset to receive is received, “NOT REG.”... - Page 26 Adjusting the Picture Aspect Ratio VIDEO/DVD/DTV Output screen image Input Signal SIDE BAR SMART STRETCH CINEMA ZOOM STRETCH For 4:3 aspect ratio 480i 480P NTSC SECAM Letter box image With squeeze 720P 1080i For 16:9 aspect ratio EXAMPLE SMART CINEMA SIDE BAR STRETCH STRETCH...
-
Page 27: Gamma Correction Function
Gamma Correction Function • Gamma is an image quality enhancement function that offers a richer image by brightening the darker portions of the image without altering the brightness of the brighter portions. • Four gamma settings are available to allow for differences in the images displayed and in the brightness of the room. -
Page 28: Using The Gui (Graphical User Interface) Menu Screen
Using the GUI (Graphical User Interface) Menu Screen Basic Operations This projector has two sets of menu screens that allow you to adjust the image and various projector settings. These menu screens can be operated from the projector 2,3,5 or the remote control with the following procedure. (GUI) On-screen Display INPUT 3, 4 (VIDEO) mode INPUT 1, 2 (COMPONENT) or 5 (RGB) mode... -
Page 29: Menu Bars
Main menu Main menu Sub menu Sub menu Picture PRJ Mode Front Contrast Ceiling Front Brightness Color Rear Tint Ceiling Rear Sharp Language English Deutsch Blue Español CLR Temp Nederlands Reset Français Progressive Mode 2D Progressive Italiano 3D Progressive Svenska Film Mode Português... -
Page 30: Main Menu
• The resolution, vertical frequency and horizontal frequency figures displayed above are for example purposes only. • “Color”, “Tint”, and “Sharp” appear only when Component is selected in INPUT 1 or 2 mode. • Only the items highlighted in the tree charts above can be adjusted. -
Page 31: Adjusting The Picture
(GUI) On-screen Display e. g. (VIDEO input in INPUT 3 or 4 mode) • “Color”, “Tint” and “Sharp” do not appear for RGB input in INPUT 5 mode. 1 Press MENU. Menu bar and “Picture” menu screen appear. GUI operation guide is also displayed. -
Page 32: Adjusting The Colour Temperature
Adjusting the Picture Adjusting the Colour Temperature This function can be used to adjust the colour temperature to suit the type of image input to the projector (DVD, video, computer image, TV broadcast, etc.). This function can be operated using the CLR TEMP buttons on the remote control, as well as the GUI menu screen. -
Page 33: Selecting The Signal Type
Adjusting the Picture Selecting the Signal Type This function allows you to select the input signal type COMPONENT or RGB for INPUT 1 or 2. 1 Press MENU. Menu bar and “Picture” menu screen appear. GUI operation guide is also displayed. -
Page 34: Adjusting The Computer Images (Rgb Menu Only)
Adjusting the Computer Images (RGB menu only) When displaying computer patterns which are very detailed (tiling, vertical stripes, etc.), interference may occur between the DMD pixels, causing flickering, 2,3,4 vertical stripes, or contrast irregularities in portions of the screen. Should this occur, adjust “Clock”, “Phase”, “H-Pos”... - Page 35 Adjusting the Computer Images (RGB menu only) Saving and Selecting Adjustment Settings This projector allows you to store up to seven adjustment settings for use with various computers. Once these 2,3,4 settings are stored, they can be easily selected each time you connect a computer to the projector.
-
Page 36: Special Mode Adjustment
Adjusting the Computer Images (RGB menu only) Special Mode Adjustment Ordinarily, the type of input signal is detected and the correct resolution mode is automatically selected. 2,3,4 However, for some signals, the optimal resolution mode in “Special Modes” on the “Fine Sync” menu screen may need to be selected to match the computer display mode. -
Page 37: Auto Sync Adjustment
Adjusting the Computer Images (RGB menu only) Auto Sync Adjustment • Used to automatically adjust a computer image. • Auto Sync adjustment can be made manually by 2,3,4 pressing the AUTO SYNC button on the remote control, or automatically by setting “Auto Sync” to “Normal”... -
Page 38: Reducing Image Noise (Video Menu Only)
Adjusting the Computer Images (RGB menu only) Auto Sync Display Function Normally, an image is not superimposed during Auto Sync adjustment. You can, however, choose to 2,3,4 superimpose a background image during Auto Sync adjustment. 1 Press MENU. 2 Press to select “Fine Sync”. -
Page 39: Turning On/Off The On-Screen Display
Turning On/Off the On-screen Display This function allows you to turn on or off the on-screen messages that appear during input select. 2,3,4 Description of OSD Display Selected item Description Normal All On-screen Display are displayed. Level A INPUT and AUTO SYNC are not displayed. All On-screen Display are not displayed (except MENU, Level B KEYSTONE and warning display (Power off, Temp., Lamp... -
Page 40: Theatre Mode Functions
Theatre Mode Functions Function as a toggle switch for controlling the quantity of projected light. Select “NORMAL” or “BRIGHT” to decrease or increase brightness, power consumption and fan noise. This function can be operated using the THEATER MODE button on the remote control, as well as the GUI menu screen. -
Page 41: Selecting A Background Image
Selecting a Background Image This function allows you to select the image displayed when no signal is being sent to the projector. Description of Background Images 2,3,4 Selected item Description Blue Blue screen None Black screen 1 Press MENU. 2 Press to select “Options”. -
Page 42: Subtitle Setting
Subtitle Setting With this function, you can adjust the vertical size of the display to allow for subtitles. Description of Subtitle Setting 2,3,4 button button Compresses the image to adjust Enlarges the image to adjust the the vertical size of the display. vertical size of the display. -
Page 43: Selecting The Economy Mode
Selecting the Economy Mode These functions allow you to reduce the power consumption when the projector is in stand-by mode. RS-232C Off Function 2,3,4 This projector consumes power when using a computer connected to the RS-232C port. When not using this port, “RS-232C Port”... -
Page 44: Selecting The Transmission Speed (Rs-232C)
Selecting the Transmission Speed (RS-232C) This menu allows you to adjust the transmission speed of the RS-232C connection by selecting the baud rate. 2,3,4 1 Press MENU. 2 Press to select “Options”. 3 Press to select “RS-232C”, and then press 4 Press to select the desired baud rate. -
Page 45: Reversing/Inverting Projected Images
Reversing/Inverting Projected Images This projector is equipped with a reverse/invert image function which allows you to reverse or invert the pro- jected image for various applications. Description of Projected Images Selected item Description Front Normal image Ceiling Front Inverted image Rear Reversed image Ceiling Rear... -
Page 46: Displaying The Adjustment Settings
Displaying the Adjustment Settings This function can be used to display all the adjusted settings on the screen simultaneously. 1 Press MENU. 2 Press to select “Status”. 3 Press ENTER to display all the adjustment settings. 4 To exit the GUI, press MENU. (GUI) On-screen Display INPUT 3, 4 (VIDEO) mode INPUT 1, 2 (COMPONENT) or 5 (RGB) mode... -
Page 47: Lamp/Maintenance Indicators
• Clogged air filter. • Clean the filters. (See page 49.) • Cooling fan breakdown. • Take the projector to your nearest Sharp • Internal circuit failure. Authorised Projector Dealer or Service Centre for repair. • Burnt-out lamp. -
Page 48: Lamp Maintenance
The power will automatically turn • Lamp has been used for over 2,000 replaced at your nearest Sharp off and the projector will enter hours. Authorised Projector Dealer or stand-by mode. -
Page 49: Replacing The Lamp
Carefully change the lamp by following the steps on the next page. If the new lamp does not light after replacement, take your projector to the nearest Sharp Authorised Projector Dealer or Service Centre for repair. Purchase a replacement lamp unit (lamp/cage module) of the current type BQC-XVZ9000/1 from your nearest Sharp Authorised Projector Dealer or Service Centre. -
Page 50: Removing And Installing The Lamp Unit
Replacing the Lamp Removing and installing the lamp unit CAUTION • Be sure to remove the lamp cage by the handle. Do not touch the glass surface of the lamp cage or the inside of the projector. • To avoid injury to yourself and damage to the lamp, carefully follow the steps below. •... -
Page 51: Cleaning The Air Filters
Cleaning the Air Filters • This projector is equipped with air filters to ensure the optimal operating condition of the projector. • Periodically clean the air filter by vacuuming it off with a vacuum cleaner. • The air filter should be cleaned every 100 hours of use. Clean the filters more often when the projector is used in a dirty or smoky location. -
Page 52: Troubleshooting
Troubleshooting Problem Check No picture appears. • Projector power cord is not plugged into the wall outlet. • Selected input is wrong. (See page 23.) • Cables incorrectly connected to back panel of the projector. (See pages 13–15.) • Remote control batteries have run down. (See page 11.) •... -
Page 53: Connecting Pin Assignments
Connecting Pin Assignments INPUT 5 RGB Signal Input Port: 15-pin Mini D-sub female connector RGB Input Analog 1. Video input (red) 8. Earth (blue) 2. Video input 9. Not connected (green/sync on green) 10. GND 3. Video input (blue) 11. GND 12. -
Page 54: (Rs-232C) Specifications And Command Settings
(RS-232C) Specifications and Command Settings PC control A computer can be used to control the projector by connecting an RS-232C cable (null modem, cross type, commercially available) to the projector. (See page 15 for connection.) Communication conditions Set the serial port settings of the computer to match those of the table on the next page. Signal format: Conforms to RS-232C standard. - Page 55 INPUT 1 (COMPONENT 1) TINT ( 30 — OK OR ERR H-POSITION ( 150 — 150) OK OR ERR INPUT 1 (COMPONENT 1) SHARP ( 30 — OK OR ERR V-POSITION ( 60 — OK OR ERR INPUT 1 (COMPONENT 1) CLR TEMP ( 3 —...
- Page 56 (RS-232C) Specifications and Command Settings CONTROL CONTENTS COMMAND PARAMETER RETURN CONTROL CONTENTS COMMAND PARAMETER RETURN THEATRE MODE NORMAL OK OR ERR LANGUAGE SELECTION : ENGLISH OK OR ERR THEATRE MODE BRIGHT OK OR ERR LANGUAGE SELECTION : DEUTSCH OK OR ERR VIDEO 3D DNR OFF OK OR ERR LANGUAGE SELECTION : ESPAÑOL...
-
Page 57: Wired Remote Control Terminal Specifications
Data Code • System codes C1 to C5 are fixed at “10110”. • Codes C14 and C15 are reverse confirmation bits, with “10” indicating “Front” and “01” indicating “Rear”. Sharp remote control signal format Transmission format: 15-bit format 67.5 ms 67.5 ms... -
Page 58: Computer Compatibility Chart
Computer Compatibility Chart Horizontal Frequency: 15–81 kHz Vertical Frequency: 43–100 Hz Pixel Clock: 12–120 MHz Compatible with sync on green and composite sync signals SXGA compatible in advanced intelligent compression or intelligent compression AICS (Advanced Intelligent Compression and Expansion System) resizing technology Horizontal Vertical Horizontal... -
Page 59: Dimensions
Dimensions Rear View Side View Top View Side View Front View Bottom View Units: mm... -
Page 60: Specifications
(PCAPH1056CESA), CD-ROM (UDSKA0047CEN1), Two projector operation manuals (TINS-7521CEZZ, TINS-7522CEZZ), SharpVision Manager operation manual (TINS- 7523CEZZ) This SHARP projector uses a DMD chip. This very sophisticated chip This unit has some inactive pixels within acceptable tolerances which contains 921,600 pixels. As with any high technology electronic may result in inactive dots on the picture screen. -
Page 61: Glossary
Glossary Aspect ratio Width and height ratio of an image. The normal aspect ratio of a computer and video image is 4 : 3. There are also wide images with an aspect ratio of 16 : 9 and 21 : 9. Auto Sync Optimises projected computer images by automatically adjusting certain characteristics. -
Page 62: Index
Index AC socket ................13 Rear projection ..............22 ADJUSTMENT buttons ............26 Remote control ..............11 Adjusting the Picture ............29 Remote control sensor ............. 16 Adjustment feet ..............18 Remote control signal transmitter ........11 Air filters ................49 RESIZE button .............. -
Page 63: Sharp Corporation
SHARP CORPORATION Printed in Japan In Japan gedruckt Imprimé au Japon Triykt i Japan Impreso en Japón Stampato in Giappone Gedrukt in Japan TINS-7521CEZZ...
