Sharp XV-Z100 Operation Manual

Hide thumbs Also See for XV-Z100:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
PROJECTOR
PROJEKTOR
PROJECTEUR
PROJEKTOR
PROYECTOR
PROIETTORE
PROJECTOR
XV-Z100
OPERATION MANUAL
BEDIENUNGSANLEITUNG
MODE D'EMPLOI
BRUKSANVISNING
MANUAL DE MANEJO
MANUALE DI ISTRUZIONI
GEBRUIKSAANWIJZING

Advertisement

Table of Contents
loading

Related Manuals for Sharp XV-Z100

Summary of Contents for Sharp XV-Z100

  • Page 1 XV-Z100 PROJECTOR OPERATION MANUAL PROJEKTOR BEDIENUNGSANLEITUNG PROJECTEUR MODE D’EMPLOI PROJEKTOR BRUKSANVISNING PROYECTOR MANUAL DE MANEJO PROIETTORE MANUALE DI ISTRUZIONI PROJECTOR GEBRUIKSAANWIJZING...
  • Page 3 SPECIAL NOTE FOR USERS IN THE U.K. The mains lead of this product is fitted with a non-rewireable (moulded) plug incorporat- ing a 10A fuse. Should the fuse need to be replaced, a BSI or ASTA approved BS 1362 fuse marked and of the same rating as above, which is also indicated on the pin face of the plug, must be used.
  • Page 5 Before using the projector, please read this operation manual carefully. Introduction IMPORTANT • For your assistance in reporting the loss Model No.: XV-Z100 or theft of your Projector, please record the Serial Number located on the bottom of the projector and retain this information. Serial No.: •...

  • Page 6: Product Disposal

    Caution Concerning Lamp Replacement See “Replacing the Lamp” on page 50. This SHARP projector uses a DMD panel. This very sophisticated panel contains 409,920 pixels (micromirrors). As with any high technology electronic equipment such as large screen TVs, video systems and video cameras, there are certain acceptable tolerances that the equipment must conform to.

  • Page 7: How To Read This Operation Manual

    Press Q or O and select “Picture” Picture SCR - ADJ PRJ - ADJ Help Picture Mode Standard to adjust. Contrast Bright Color Tint On-screen Sharp CLR Temp 7 5 0 0 Bright Boost display Progressive 3D Progressive Lamp Setting Bright Reset SEL./ADJ. ENTER Info ..Indicates safeguards for using the projector.

  • Page 8: Table Of Contents

    Contents Preparing Introduction Setup How to Read this Operation Manual ..3 Setting up the Projector ...... 18 Contents ..........4 Setting up the Projector ....... 18 Standard Setup (Front Projection) ..18 IMPORTANT SAFEGUARDS ....6 Ceiling-mount Setup ......18 Accessories ........
  • Page 9 Reference Appendix Connecting Pin Assignments ..... 53 RS-232C Specifications and Command Maintenance ........47 Settings ..........54 Maintenance Indicators ...... 48 Computer Compatibility Chart .... 55 Regarding the Lamp ......50 Troubleshooting ........56 Lamp ............. 50 Specifications ........58 Caution Concerning the Lamp ....

  • Page 10: Important Safeguards

    IMPORTANT SAFEGUARDS CAUTION: Please read all of these instructions before you operate this product and save these instructions for later use. Electrical energy can perform many useful functions. This product has been engineered and manufactured to assure your personal safety. BUT IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARDS.
  • Page 11 15. Overloading 19. Replacement Parts Do not overload wall outlets, extension cords, or When replacement parts are required, be sure integral convenience receptacles as this can the service technician has used replacement result in a risk of fire or electric shock. parts specified by the manufacturer or have the same characteristics as the original part.
  • Page 12 I Continuously watching the screen for long Internal cleaning should only be performed hours will cause eye strain. Be sure to occa- by a Sharp Authorized Projector Dealer or sionally rest your eyes. Service Center. Do not set up the projector in places ex- Avoid locations with extremes of tem- posed to direct sunlight or bright light.
  • Page 13 I When turning off the projector, the cooling fan Using the projector in other countries runs to decrease the internal temperature for I The power supply voltage and the shape of a while. Unplug the power cord after the cool- the plug may vary depending on the region ing fan stops.

  • Page 14: Accessories

    I Lamp unit AN-100LP I DIN-D-sub RS-232C adaptor (5 o (15 cm)) AN-A1RS Note • Some of the optional accessories may not be available depending on the region. Please check with your nearest Sharp Authorized Projector Dealer or Service Center.

  • Page 15: Part Names And Functions

    Part Names and Functions Numbers in Z refer to the main pages in this operation manual where the topic is explained. Projector Top View Power Lamp indicator 28, 48 28, 48 indicator Temperature warning indicator STANDBY/ON button For turning the power on and Volume buttons putting the...

  • Page 16: Rear View

    Part Names and Functions (Continued) Numbers in Z refer to the main pages in this operation manual where the topic is explained. Rear View Exhaust vent Speaker Intake vent AC socket Kensington Security Connect the Standard connector supplied Power cord. Rear adjustment foot Using the Kensington Lock...
  • Page 17 Numbers in Z refer to the main pages in this operation manual where the topic is explained. STANDBY button ON button For putting the For turning the power on. projector into the standby mode. MENU/HELP button For displaying adjustment KEYSTONE button and setting screens, and For entering the help screen.

  • Page 18: Inserting The Batteries

    Part Names and Functions (Continued) Inserting the Batteries Press the P mark on the cover and slide it in the direction of the arrow. Insert the batteries. • Insert the batteries making sure the polarities correctly match the m and n marks inside the battery compartment. Attach the cover and slide it until it clicks into place.

  • Page 19: Usable Range

    Usable Range Remote control sensor The remote control can be used to control the projector within the ranges shown in the illustra- tion. Note • The signal from the remote control can be re- flected off a screen for easy operation. How- ever, the effective distance of the signal may differ depending on the screen material.

  • Page 20: Quick Start

    Quick Start This section shows the basic operation (projector connecting with the video equipment). For details, see the page described below for each step. Setup and Projection In this section, connection of the projector and the video equipment is explained using one ex- ample.
  • Page 21 4. Turn the video equipment on and start playback 5. Select the INPUT mode Select the “INPUT 3” using the INPUT button on the projector or D INPUT 3 on the remote control. On the On the remote On-screen display projector control INPUT 3...

  • Page 22: Setting Up The Projector

    • Refer to page 20 for additional information concerning “Screen Size and Projection Distance”. Ceiling-mount Setup I It is recommended that you use the optional Sharp ceiling-mount bracket for this installa- tion. Before mounting the projector, contact your nearest Sharp Authorized Projector...

  • Page 23: Projection (Prj) Mode

    Projection (PRJ) Mode The projector can use any of the 4 projection modes, shown in the diagram below. Select the mode most appropriate for the projection setting in use. (You can set the PRJ mode in “SCR-ADJ” menu. See page 43.) I Table mounted, front projection I Ceiling mounted, front projection Menu item ©...

  • Page 24: Screen Size And Projection Distance

    Setting up the Projector (Continued) Screen Size and Projection Distance When using a wide screen (16:9) and projecting 16:9 image Picture (Screen) size Projection distance [L] Distance from the lens center to the bottom of the image [H] Diag. [χ] Width Height Minimum [L1]...
  • Page 25 When using a normal screen (4:3) and projecting 16:9 image Picture (Screen) size Projection distance [L] Distance from the lens center to the bottom of the image [H] Diag. [χ] Width Height Minimum [L1] Maximum [L2] 300 (762 cm) 240 (610 cm) 180 (457 cm) 32 0 (9.8 m) 37 0 (11.3 m)

  • Page 26: Samples Of Cables For Connection

    RCA adaptor plug (commercially available) Audio or connect directly to AUDIO (INPUT 3, 4). RGB cable (commercially available) INPUT1, 2 Computer video ø3.5 mm stereo audio cable AUDIO INPUT (commercially available or available as Sharp Computer service part QCNWGA038WJPZ) audio...

  • Page 27: Connecting To Video Equipment

    Connecting to Video Equipment Before connecting, ensure that the power cord of the projector is unplugged from the AC outlet and turn off the devices to be connected. After making all connections, turn on the projector first and then the other devices. The projector is equipped with input terminals that support component, S-video, and video signals.
  • Page 28 Connecting to Video Equipment (Continued) When connecting to equipment with S-video output terminal (INPUT3) DVD, etc. To S-video output terminal To audio To AUDIO output terminal To INPUT3 (INPUT3, 4) terminal terminal S-video cable RCA audio cable* (commercially available) (commercially available) *Use the cable when you want to enjoy the sound from the projector’s speaker.

  • Page 29: Connecting To A Computer

    • Depending on the computer you are using, an image may not be projected unless the computer’s external output port is switched on. (e.g. Press “Fn” and “F5” keys simultaneously when using a SHARP notebook computer). Refer to the specific instructions in your computer's operation manual to enable your computer’s external output port.

  • Page 30: Connecting To A Monitor With Rgb Input Terminal

    Connecting to a Monitor with RGB Input Terminal You can display computer images on both the projector and a separate monitor using two sets of RGB cables. Computer Monitor To INPUT 1 To OUTPUT To RGB To RGB terminal (INPUT 1, 2) input output terminal...

  • Page 31: Controlling The Projector By A Computer

    Controlling the Projector by a Computer When the RS-232C terminal on the projector is connected to a computer with a DIN-D-sub RS- 232C adaptor (optional accessory: AN-A1RS) and an RS-232C serial control cable (cross type, commercially available), the computer can be used to control the projector and check the status of the projector.

  • Page 32: Turning The Projector On/Off

    Turning the Projector On/Off Supplied Power cord Connecting the Power Cord accessory Plug the supplied power cord into the AC socket on the rear of the projector. AC socket Info • English is the factory default language. If you Turning the Projector on want to change the on-screen display to another language, change the language according to Note that the connections to external equip-...

  • Page 33: Turning The Power Off (Putting The Projector Into Standby Mode)

    STANDBY button Turning the Power off (Putting the Projector into Standby Mode) Press SSTANDBY/ON on the pro- jector or eSTANDBY on the re- mote control, then press that but- ton again while the confirmation message is displayed, to put the projector into standby mode.

  • Page 34: Image Projection

    Image Projection Switching the Input Mode Select the appropriate input mode for the connected equipment. C INPUT PressC INPUT DINPUT 3 or EINPUT 4 on the remote control to select the input mode. • When pressing INPUT (P/R) on the projector, input mode switches in the following order: INPUT1 INPUT2...

  • Page 35: Adjusting The Height

    3 Adjusting the Height The height of the projector can be ad- justed using the adjustment feet at the front and rear of the projector. When the screen is above the projec- tor, the projection image can be made higher by adjusting the projector. HEIGHT Lift the projector to adjust its ADJUST lever...

  • Page 36: Adjusting The Volume

    Image Projection (Continued) Adjusting the Volume Press K/L on the remote control or –O/Q+ on the projector to adjust the vol- ume. AV MUTE button Note • Pressing K/–O will lower the volume. • Pressing L/Q+ will raise the volume. Volume buttons •...

  • Page 37: Correcting Trapezoidal Distortion

    KEYSTONE button Correcting Trapezoidal Distortion When the image is projected either from the top or from the bottom towards the screen at an angle, the image becomes Adjustment buttons (P/R/O/Q) distorted trapezoidally. The function for correcting trapezoidal distortion is RETURN button called Keystone Correction.

  • Page 38: Resize Mode

    Image Projection (Continued) Resize Mode This function allows you to modify or customize the resize mode to enhance the input image. De- pending on the input signal, you can choose “STRETCH”, “SIDE BAR” or “CINEMA ZOOM” image. Press HRESIZE. • See page 43 for setting on menu screen. RESIZE button VIDEO •...
  • Page 39 Computer STRETCH SIDE BAR SVGA (800 K 600) XGA (1024 K 768) 4:3 aspect ratio 854 K 480 640 K 480 SXGA (1280 K 960) SXGA L (1400 K 1050) SXGA (1280 K 1024) 854 K 480 640 K 480 Other aspect ratios 1280 K 720 854 K 480...

  • Page 40: Operating With The Remote Control

    Operating with the Remote Control Freezing a Moving Image Press NFREEZE. • The projected image is frozen. Press NFREEZE again to return to the moving image from the cur- rently connected device. FREEZE button Selecting the Picture Mode PICTURE MODE button You can select the appropriate picture mode to best match the projected im-...

  • Page 41: Menu Items

    SCR - ADJ PRJ - ADJ Help Contrast Picture Mode Standard Bright Contrast Color Bright Color Tint *1*2 Tint Sharp Sharp CLR Temp 7 5 0 0 Bright Boost Blue Progressive 3D Progressive Page 42 Lamp Setting Bright Reset 5500K CLR Temp SEL./ADJ.
  • Page 42 Menu Items (Continued) “Projection adjustment (PRJ-ADJ)” menu Main menu Sub menu Picture SCR - ADJ PRJ - ADJ Help PRJ - ADJ Auto Search [On/Off] Page 44 Page 44 Auto Search Auto Sync Auto Sync [On/Off] Auto Power Off Page 44 System Sound Speaker Auto Power Off [On/Off]...

  • Page 43: Using The Menu Screen

    Press Q or O and select “Picture” Picture SCR - ADJ PRJ - ADJ Help Picture Mode Standard to adjust. Contrast Bright Color Tint Sharp CLR Temp 7 5 0 0 Bright Boost Progressive 3D Progressive Lamp Setting Bright Reset SEL./ADJ. ENTER...
  • Page 44 SCR - ADJ PRJ - ADJ Help to adjust. Picture Mode Standard • The selected item is highlighted. Contrast Bright Color Tint Sharp CLR Temp 7 5 0 0 Bright Boost Progressive 3D Progressive Lamp Setting Bright Reset SEL./ADJ. Single ADJ...

  • Page 45: Picture Adjustment ("Picture" Menu)

    Help Picture Mode Standard Picture Mode Standard Contrast Contrast Bright Bright Color Tint Blue Sharp CLR Temp 7 5 0 0 CLR Temp 7 5 0 0 Bright Boost Bright Boost Lamp Setting Bright Progressive 3D Progressive Reset Lamp Setting...

  • Page 46: Adjusting The Image

    Tint* For making skin For making skin film transformed with three-two pull down tones purplish. tones greenish. (NTSC and PAL60Hz) or two-two pull Sharp* For less For more down (PAL50Hz and SECAM) enhance- sharpness. sharpness. ment to progressive mode images.

  • Page 47: Adjusting The Projected Image ("Scr - Adj" Menu)

    4 Selecting the Background Image Note Selectable items Description • For details of the Resize mode, see pages 34 Logo Sharp logo screen and 35. Blue Blue screen • You can also press HRESIZE on the remote None — control to set the resize mode. (See page 34.)

  • Page 48: Adjusting The Projector Function ("Prj - Adj" Menu)

    Adjusting the Projector Function (“PRJ - ADJ” menu) Menu operation n Page 39 Picture SCR - ADJ PRJ - ADJ Help Auto Search Auto Sync Auto Power Off System Sound Speaker RS-232C 9600 bps Fan Mode Normal Lamp Timer(Life) 100% SEL./ADJ.

  • Page 49: Setting The Confirmation Sound (System Sound)

    Menu operation n Page 39 4 Setting the Confirmation 7 Fan Mode Setting Sound (System Sound) This function changes the fan rotation speed. Selectable Selectable Description Description items items Normal Suitable for normal environments. A confirmation sound is made when the projector turns on/off.

  • Page 50: Troubleshooting With "Help" Menu

    Troubleshooting with “Help” menu This function advises you to solve the problems during usage. Adjustment buttons (P/R/O/Q) Utilizing “Help” menu functions MENU/HELP button ENTER button Example: When the picture has a green tint When the picture has a green tint on INPUT 1 (Component)/INPUT 2 (Component).

  • Page 51: Maintenance

    Maintenance Cleaning the projector Cleaning the lens I Ensure that you have unplugged the power I Use a commercially available blower or lens cord before cleaning the projector. cleaning paper (for glasses and camera lenses) I The cabinet as well as the operation panel is for cleaning the lens.

  • Page 52: Maintenance Indicators

    Maintenance Indicators I The warning lights (power indicator, lamp indicator and temperature warning indicator) on the projector indicate problems inside the projector. I If a problem occurs, either the temperature warning indicator or the lamp indicator will illuminate red, and the projector will enter standby mode. After the projector has entered standby mode, follow the procedures given below.
  • Page 53 (see page 8) indicator high. • Cooling fan • Take the projector to your breakdown nearest Sharp Authorized • Internal circuit Projector Dealer or Service failure Center for repair. • Clogged air intake Lamp The lamp does •...

  • Page 54: Regarding The Lamp

    Sharp Authorized Projector Dealer or Service Center. * If the new lamp does not light after replacement, take your projector to the nearest Sharp Authorized Projector Dealer or Service Center for repair.

  • Page 55: Removing And Installing The Lamp Unit

    Removing and Installing the Lamp Unit Warning! Optional Lamp unit accessory AN-100LP • Do not remove the lamp unit from the projec- tor right after use. The lamp and parts around the lamp will be very hot and may cause burns or injury.

  • Page 56: Resetting The Lamp Timer

    Regarding the Lamp (Continued) Remove the lamp unit. Handle • Loosen the securing screws from the lamp unit. Hold the lamp unit by the handle and pull it in the direction of the arrow. At this time, keep the lamp unit horizontal and do not tilt it.

  • Page 57: Connecting Pin Assignments

    Connecting Pin Assignments COMPUTER-RGB/COMPONENT INPUT1, 2 and COMPUTER-RGB/COMPONENT OUTPUT Terminals: 15-pin Mini D-sub female connector COMPUTER-RGB Input/Output Component Input/Output Video input (red) PR (CR) Video input (green/sync on green) Video input (blue) PB (CB) Not connected Not connected Not connected Not connected Earth (red) Earth (PR)

  • Page 58: Rs-232C Specifications And Command Settings

    RS-232C Specifications and Command Settings Computer control A computer can be used to control the projector by connecting an RS-232C serial control cable (cross type, sold separately) to the projector. (See page 27 for connection.) Communication conditions Set the serial port settings of the computer to match that of the table. Signal format: Conforms to RS-232C standard.

  • Page 59: Computer Compatibility Chart

    Computer Compatibility Chart Computer • Multiple signal support • Compatible with the signals below in Horizontal Frequency: 15-70 kHz, intelligent compression Vertical Frequency: 45-85 Hz, SVGA, XGA, SXGA, SXGA+ Pixel Clock: 12-108 MHz • Intelligent Compression and Expansion Sync signal: Compatible with TTL level System resizing technology •...

  • Page 60: Troubleshooting

    Troubleshooting Problem Check Page • Projector power cord is not plugged into the wall outlet. • Power to the external connected devices is off. – • The selected input mode is wrong. • Cables incorrectly connected to the projector. 23–27 •...
  • Page 61 Problem Check Page • Change the input signal type setting. Picture is green on INPUT 1 (Component)/ Select “Color is faded or poor” in the “Help” menu, and then select INPUT 2 (Component). an input signal type. Picture is pink (no green) on INPUT 1 (RGB)/INPUT 2 (RGB).

  • Page 62: Specifications

    D-sub adaptor, 21 pin RCA conversion adaptor, Video cable, Operation manual As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specifica- tion figures indicated are nominal values of production units. There may be some deviations from...

  • Page 63: Dimensions

    Dimensions Units: inches (mm) ø9 (69.2) (77.5) (80) (315) (33.8) (46.2) (65.5) (75)

  • Page 64: Index

    HEIGHT ADJUST lever ......... 31 SCR - ADJ ............. 43 Help ..............46 Screen Size and Projection Distance ...... 20 Sharp ............. 42 INPUT 1 terminal ......23, 25, 26 SIDE BAR ..........34, 35 INPUT 1 – 4 modes ........30 Speaker ............

  • Page 65: Sharp Corporation

    SHARP CORPORATION Printed in China Gedruckt in China Imprimé en Chine Triykt i Kina Impreso en China Stampato in Cina Gedrukt in China TINS-C079WJZZ 05P09-CH-NG...
