4 MAC-200 Operation

4.1 Powering on the MAC-200

Power Button
Momentarily press the Red Power button on the front panel to
activate the MAC-200. You should see the LEDs behind the meter
displays light up.

Backlighting

4.1.1
During power on, the MAC-200 checks to see if the AUTO or
MANUAL keys are pressed. If the AUTO key is pressed, meter
backlighting is turned ON. If the MANUAL key is pressed, meter
backlighting is turned OFF. Default from the factory is
backlighting ON. The current backlighting settings are stored and
will be recovered whenever the MAC-200 is started.
