12 Vdc Power - SGC MAC-200 Operating Manual

All connections to the MAC-200 are made on the back panel.
NOTE: Under normal operating conditions, it is good practice to
connect a dummy load to one of the 50-Ohm antenna connectors in
order to have it available for test purposes.

3.2.1 12 VDC Power

ATTENTION: The MAC-200 RF Path is open when power is
off in both receive and transmit modes. To prevent damage to
transceivers, do not operate with power off to this device.
NOTE: For efficient operation of the MAC-200, apply 12
VDC from the same power supply as the transceiver.
