Using the LCD Screen

The high resolution 3" touch screen LCD screen shows all important information
regarding camera settings as well as the visual image of your photo or video. The
display on the LCD screen is called the On Screen Display or OSD.

LCD Screen Layout

The following illustrations show the LCD screen layout and icon descriptions.

Record Mode Screen Layout

1
16
No.
Item
1
Record Mode
2
Flash
3
Focus Mode
4
Self-timer / Burst
5
Zoom indicator
6
Shots available
7
Resolution
8
Quality
9
Focus frame
Chapter 3: Using the LCD Screen
2
3
4
15
14
13
Indicates the current record mode settings.
Indicates flash settings.
Indicates focus mode settings.
Indicates drive mode settings.
Displays zoom.
Indicates the remaining shots available.
Displays resolution settings.
Displays quality settings.
Use to frame subject to capture.
11
5
6
7
307
307
307
8
9
10
0.0EV
0.0EV
0.0EV
11
3200
3200
3200
12
