Page 1: Table Of Contents
Contents Safety Precautions Location Features Components Dismantling and Installing the Door Connecting the Water Supply Line Preparation Before Use Usage Function About the Fresh Food Compartment Precaution when Refrigerating Food Tips and Hints in Using the Fresh Food Compartment About the Freezer Precaution when Freezing Food Use of the Ice Maker and the Cold Water Dispenser Dismantling and Installing the Ice Container... - Page 2 Before operating this appliance, please thoroughly read and retain this manual for your reference. Because we offer a variety of models, the characteristics of your refrigerator may differ slightly from those described in this manual. The appliance is not intended for use by children without adult supervision. Children should be supervised to ensure that they do not play with the appliance.
- Page 3 Flammable, explosive, and dangerous Drugs, vaccines, and chemical reagents Do not store or use petrol or other items, and highly corrosive acid and must not be put in fridge. This fridge is flammable substances near the fridge to alkali must not be put in fridge. for household use only.
- Page 4 The fridge should be put in a location Do not put the fridge in a place where it The fridge must be put in an environment that is far away from any heat source or is humid, or where there may be with good ventilation.
- Page 5 Ice-cream Shelf Tilt bin Crispers Movable Board Due to product modification, your purchased Haier refrigerator may not be identical with the one shown in the manual. We hereby express our apologies to you for this possible difference.
-
Page 6: Dismantling And Installing The Door
Dismantling and Installing the Door Before dismantling and installing the door, take food out of the door bin and dismantle the bottle bin. Cut off power and water source to avoid personal injury and damage to the product or the surrounding area. - Page 7 Dismantling and Installing the Door If necessary, dismantle the middle hinge. To install the freezer door, follow these directions in reverse. When raising the hinge to separate it from the door, be careful not to drop the door. Dismantling and Installing the Convertible Drawer O p e n t h e c o n v e r t i b l e d r a w e r Take out the screws on both sides with a screwdriver.
-
Page 8: Connecting The Water Supply Line
Connecting the Water Supply Line Install the shutoff valve on the nearest frequently used drinking water line. Shut off the main water supply: Turn on the nearest faucet long enough to clear the line of water. Choose the valve location: Choose a location for the valve that is easily accessible. - Page 9 Connecting the Water Supply Line Connect the tubing to the valve: Place the compression nut and ferrule (sleeve) for copper onto the end of the tubing and connect it to the shutoff valve. Make sure the tubing is fully inserted into the valve.
-
Page 10: Preparation Before Use
Preparation Before Use Check accessory and documents: Remove all packing materials, including Check materials against packing list. If any are foam base pad and tape used to attach different or missing, inquire with the retailer. accessories. Installation of the lower decoration strip: Put the fridge in a proper place. - Page 11 Extra Ice Button Express Freeze Button Express Chill Button...
- Page 12 Lock and Release (Only applicable to PRCS25**** series) (Only applicable to RRCS25**** series) Push I Button ,the lock button will light, and it is now in lock status. Push I Button again , the lock button light will turn off, and it is now not in lock status. Fresh Food Compartment Temperature Adjustment (Only applicable to PRCS25ED** series) (Only applicable to PRCS25TD** series)
-
Page 13: Freezer Compartment Temperature Adjustment
Freezer Compartment Temperature Adjustment (Only applicable to PRCS25ED** series) (Only applicable to PRCS25TD** series) Push the O or N button once the freezer compartment temperature P indicator will flash. This indicates that you are in the temperature-setting mode. The temperature range is from -6°F to 8°F (-21°C to -13°C). The range increases one level every time you press the O button until it reaches the 7 level, which is the maximum. - Page 14 Express Freeze Setting: This function is designed to preserve food's nutritional value by deeply freezing it in a short period of time. Press the M button. The express freeze indicator will light up. This indicates that the express freeze mode is chosen, and express freeze will function automatically.
-
Page 15: Water Filter Indicator
Ice Maker Switch Function: When the unit is in the locked status, press G and F at the same time for 3 seconds. A buzzer will sound, indicating that the ice maker is closed and in the locked status. To turn the icemaker back on, press G and F again for 3 seconds. You will hear another buzzer, and the ice maker will be back on. - Page 16 Temporary stored food or frequently used foods should be kept in the fresh food compartment. Although the average temperature in most parts of the fresh food compartment is 34 to 48°F (1 to 8°C), this compartment cannot keep food fresh for extended periods of time. The fresh food compartment should only be used for short-term storage.
-
Page 17: About The Fresh Food Compartment
About the Fresh Food Compartment The suggested storage section of various foods: Because of the cool air circulation, there is a temperature difference among different sections in the cabinet. Therefore different foods should be put in different temperature sections. 1.Eggs, butter, cheese, etc 2.Cans, glass jars, spices, batteries, gallon milk, etc 3.Soft drinks, gallon milk, bottled foods 4.Preserved foods, cans, jars, etc... -
Page 18: Tips And Hints In Using The Fresh Food Compartment
Tips and Hints in Using the Fresh Food Compartment Radish leaves should be cut Defrost frozen food in the Some foods, like onion, R e f r i g e r a t i o n c a n off otherwise the leaves will fresh food compartment to g a r l i c , g i n g e r, w a t e r accelerate the ripening of... -
Page 19: Precaution When Freezing Food
After 6 months of use, the “Change Filter” indicator light will turn on. At this time, we suggest you go to an authorized Haier after-sale service center or shop to buy a new filter and change it. - Page 20 Usage of Ice Maker and Cold Water Dispenser Working Principle: The ice maker can make 8 ice cubes per cycle. The ice content will depend on room temperature, door openings, water pressure, freezer temperature, etc. It is considered normal when ice cubes stick together.
-
Page 21: Usage Of The Dispenser
Usage of the Dispenser Usage of the Dispenser: Select one crushed ice, cold water, and ice cubes and push the ice/water lever gently as follows: When you want cold water: When you want cubed ice: When you want crushed ice: Press the selecting button until the Press the selecting button until Press the selecting button until the... -
Page 22: About The Convertible Compartment
About the Convertible Compartment When it is used for refrigeration or freezer function: 1. When the convertible compartment is changed from fresh food to freezer temperatures, remove all of the food and store it temporarily in the main fresh food compartment. Open the moveable board in the convertible compartment. -
Page 23: Water Filter
6.Run the refrigerator water dispenser for 5 minutes after replacing the filter, to flush out the refrigerator system. Discard this water. 7.After replacing the Haier filter cartridge, reset the refrigerator display. 1.The refrigerator water dispenser and icemaker cannot be used without the water filter. -
Page 26: Discontinuing Or Breaking In Usage
Discontinuing or Breaking in Usage Handling Power Failure Foods can be stored well after several hours of power failure, even during the summer. You should call your electric company to ask how long the food will last. After a power failure, do not put new food into the fridge, and open the door as infrequently as possible. - Page 28 The rate of frost buildup and internal condensation increases. Close the door gently. Open the door less often. Keep containers covered.
- Page 29 Confirm whether the ice maker is closed. Ice maker is producing less ice than expected.
- Page 31 Track that drawers slide on are dirty.
- Page 36 02.25...
