Critical Application
Wheel motor bolts (Securing
motor to support)
Wheel motor bolts / nuts
(Securing motor to support)
Clutch to engine shaft
Wheel hub to wheel motor
Wheel lug nuts
Split Hub (Spindle & Drive) (Gr 8) All Models
Blade Bolts
Spindle and Drive Pulley Split hub R&R
Remove 2, ¼" bolts from split hub and install in threaded holes in hub.
Slowly tighten each bolt, alternating as you tighten bolts against the pulley.
The hub will separate from the pulley.
Replace grade 8 bolts and install in reverse order using the assembly holes to tighten hub onto pulley
and spindle shaft.
Threaded
Assembly
hole

Spindle Set Up / Blade Options

Parts:
Spindle – Thru Bolt
PN - 71460126

Torque Specifications

Big/Small Stander, Stander X, Sport X,
RH, WSES, Velke
ZK, MMZ, Sentar3
All Models
Big Stander, Stander X, Sport X (15P)
ZK, MMZ, Sentar3 (15E)
All Others (12P)
All Models
All Models
Assembly
Removal
hole
holes
Spindle Bolt
PN - 11990014
Models
Spindle Nut
PN - 12990003
Spindle Blade Spacer
PN – 13990007 / 1 or 3 ea
Spindle Blade Spacer
PN – 13990007 / 3 or 5 ea
Spindle Washer
PN - 13990039
17
Thread
Torque
Locker
Range (ft-lbs)
Loctite
40-50
2760
N/A
103-125
Loctite
50-55
138-158
N/A
160-240
138-158
N/A
80-90
N/A
13-17
N/A
70-80
Tightening will
separate the hub
from the pulley
Stock Fusion Blade
PN – 71440008 – 16.5"
71440009 – 18"
71440010 – 21"
