Commercial Mower Owner's Manual
For Stander X, Serial Numbers 54956 and Higher Until Superseded
WARNING: READ THIS MANUAL BEFORE USING
For your safety and for proper operation and maintenance read
carefully and keep readily available for future reference.
Additional replacement owner's manuals as well as illustrated parts lists are available from your
authorized Wright Dealer for a nominal charge. Also check
date product literature. Please note the complete model number and serial number of your Wright
product.
For reference please note the following information at the time of purchase:
*Unit must be registered by your dealer at time of sale or with-in 14 days to activate your two year warranty*
Revised 6/2011
SERIAL # ________________________________
MODEL # ________________________________
DATE OF PURCHASE ______________________
www.wrightmfg.com
for the most up to
Advertisement
Table of Contents
Related Manuals for Wright Manufacturing Stander X 54956
Summary of Contents for Wright Manufacturing Stander X 54956
- Page 1 Commercial Mower Owner’s Manual For Stander X, Serial Numbers 54956 and Higher Until Superseded WARNING: READ THIS MANUAL BEFORE USING Revised 6/2011 For your safety and for proper operation and maintenance read carefully and keep readily available for future reference. Additional replacement owner’s manuals as well as illustrated parts lists are available from your authorized Wright Dealer for a nominal charge.
- Page 2 ©1998-2011 Wright Manufacturing, Inc. All rights reserved. This material may not be reproduced or copied, in whole or part, without written permission from Wright Manufacturing, Inc. Grass Gobbler, Gobbler, Leaf Gobbler, Velke, Pro 1, X2, Stander, and Sentar are...
-
Page 3: Table Of Contents
TABLE OF CONTENTS ......................... 3 ELIVERY ERVICE OF OWER BY EALER ................................. 5 AFETY NSTRUCTIONS ..................................... 5 NTRODUCTION ..............................5 ENERAL AFETY NSTRUCTIONS .................................. 5 WNER OTICE ................................. 5 UALIFICATIONS ................................... 6 LOTHING ............................6 NSPECT OWER EFORE ..........................6 EGULAR OWER AFETY... -
Page 4: Pre-Delivery Service Of Mower By Dealer
PRE-DELIVERY SERVICE OF MOWER BY DEALER Before proceeding with the Pre-Delivery Service of your mower, please read the safety instructions manual in its entirety. Only your authorized Wright dealer should perform the Pre-Delivery WARNING Service of the mower. The Wright Stander X is shipped completely assembled and has been adjusted and tested at the factory. However, due to the jostling of the shipping process and the delivery time lapse, the following items need to be repeated again before starting the mower. - Page 5 Before testing the blade clutch/brake operation, make sure the area is clear and there is nothing vulnerable to possible thrown objects from under the mower. No one should be near the mower deck or in its line of discharge at this or at any time. The discharge chute deflector should be in the down position. Move the engine throttle control to ¾...
-
Page 6: Safety Instructions
Make sure every operator is properly other material provided by Wright Manufacturing, trained and thoroughly familiar with all of the Inc. before using or allowing others to operate the information in this manual before operating the equipment. -
Page 7: User Clothing
engine contrary to engine manufacturer specifications. Failure to comply can compromise operator safety, shorten equipment life and void your WARNING manufacturer’s warranty. Keep all nuts, bolts, and screws tight to be sure the equipment is in safe User Clothing working condition. Check the blade mounting bolts for DO NOT operate the mower while wearing sandals, proper tightness every eight (8) hours of operation. -
Page 8: Initial Operating Safety Guidelines
• If the mower discharges grass clogs, turn off the blade clutch switch, apply the parking brake, stop the engine and remove the key before WARNING removing obstruction(s). • Keep all shields and covers in place, namely, all Initial Operating Safety Guidelines blade and belt covers, engine shields, and •... -
Page 9: Zero-Radius Turn Operation
Recommendations for this angle: • Lean back with arms stretched out straight while holding onto the stationary handlebar. This transfers more of your body weight to the rear WARNING drive wheels for more traction. • Do not change speed suddenly to minimize the Zero-Radius Turn Operation During zero-radius turns (when one mower wheel tendency of going into a slide. -
Page 10: Hydraulic Safety
WARNING Replacement Parts Use of parts other than specified parts supplied by Wright Manufacturing, Inc. may compromise the safe use of the mower, are not recommended and their use could void the warranty. Always check with your Dealer or the Wright Mfg website, www.wrightmfg.com... -
Page 11: Operating Instructions
OPERATING INSTRUCTIONS If you are not completely familiar with the Safety Instruction Manual read it now before proceeding with the operation of the WARNING mower. REMEMBER THERE ARE CERTAIN PRECAUTIONS LISTED IN THIS MANUAL THAT YOU MUST NOW TAKE BEFORE STARTING THE MOWER. -
Page 12: How To Stop And Park The Mower
brake. The higher engine speed will make the curb is not too high, drive the right-front caster off controls much more responsive and the mower first while driving toward the curb at a 45 degree much quicker; Use caution if it is your first time. angle (the curb should be to your right). -
Page 13: How To Adjust Neutral
control rods) and adjusting the control rods. Once How to Adjust Neutral the jam-nuts are loosened at the top and bottom of Neutral refers to the mower movement when the the control rod proceed to turning the control rod engine is set to full throttle, parking brake is off, and clockwise or counter-clockwise. -
Page 14: How To Test/Use The Blade Clutch/Brake Switch
The height-of-cut can be adjusted the following How to Test/Use the Blade Clutch/Brake ways: Switch • Pull the deck lift lever on the right hand side Before testing the blade clutch/brake operation, of the mower towards the rear of the mower make sure the area is clear and there is nothing until it clicks once into the locked transport vulnerable to thrown objects from under the mower. -
Page 15: Belt Tension Adjustment
height of cut range after any adjustments are made to these hangers to ensure that the height of cut adjustments work properly. If unable to make the adjustments needed to align deck properly, contact Clutch your dealer for assistance. Stop Belt Tension Adjustment The pump drive belt is self-adjusting, and requires no adjustment, just replacement. -
Page 16: Spring Platform
• Spring platform Adjustment Connect grease gun to fitting and pump until grease begins to ooze out from the The factory setting is both springs set at the most bearings. forward position. The more rearward the spring • Wipe off excess grease. position, the stiffer the platform gets. -
Page 17: Battery Service
port. Use fully synthetic oil: Mobil1 15W-50. With the bypass valves open and the engine running, slowly move the control levers back and forth five or six times. Now close the bypass valves and with the engine running, slowly move the control levers back and forth five or six times. -
Page 18: Spindle And Drive Pulley Split Hub R&R
Torque Specifications Thread Torque Critical Application Models Locker Range (ft-lbs) Wheel motor bolts (Securing Big/Small Stander, Stander X, Sport X, Loctite 40-50 motor to support) RH, WSES, Velke 2760 Wheel motor bolts / nuts ZK, MMZ, Sentar3 103-125 (Securing motor to support) Loctite Clutch to engine shaft All Models... - Page 19 71440008 - BLADE, FUSION, ½” OFFSET 16.5” 71440009 - BLADE, FUSION, ½”OFFSET 18" 71440010 - BLADE, FUSION, ½” OFFSET 21" 3 Top ¼” Blade Spacer Set-Up 3 Bottom 71440001 - BLADE 18" 71440002 - BLADE 16.5” 71440003 - BLADE 21” 1 Top ¼”...
-
Page 20: Consumables / Maintenance Items
• An Illustrated Parts List (IPL) is available to download or print online at www.wrightmfg.com. Select Stander X from the “PRODUCTS” list, under “DOWNLOADS”, Illustrated Parts Stander X Consumables / Maintenance Items Description 13990017 MACH BUSH, 7/8 ID X 1 3/8 OD X 14 GA 13990024 WASHER, NEOPRENE 14990002 HBUSH SMALL 17460005 BUSHING, RUBBER, .75 X 1.125 X .75... -
Page 21: Maintenance Interval Chart
Maintenance Interval Chart MAINTENANCE ITEM Inspect for cracks in frame, cutter deck or other steel parts Inspect all belts for wear and alignment Check all bolts and nuts for tightness (tighten as necessary) Check hydraulic oil reservoir level and fill as needed - Use SYNTHETIC oil - Mobil1 15W-50 (refer to Hydro Oil Tank Check &... -
Page 22: Maintenance Record
Maintenance Record Unit Date Maintenance/Service Performed Shop/Technician Hours... -
Page 23: Power Equipment Limited Warranty
WRIGHT MANUFACTURING, INC. POWER EQUIPMENT LIMITED WARRANTY THIS WARRANTY SUPERSEDES ALL PREVIOUS ON UNITS WITH A RETAIL SALES DATE ON OR AFTER 04/01/05 • • • • Exclusions: All Repair parts (excluding wear or otherwise excluded items) installed during the warranty period are warranted until the end... - Page 24 The United States Environmental Protection Agency (EPA), California Air Resources Board (CARB) and Wright Manufacturing, Inc. (WMI) are pleased to explain the evaporative emission control system (EECS) warranty on your 2011 commercial mower. In the United States, new equipment that use small off-road engines must be designed, built and equipped to meet the Federal’s stringent evaporative emissions...
- Page 25 (2) Any warranted part that is scheduled only for regular inspection in the written instructions supplied is warranted for the warranty period stated above. Any such part repaired or replaced under warranty will be warranted for the remaining warranty period. (3) Any warranted part that is scheduled for replacement as required maintenance in the written instructions supplied is warranted for the period of time before the first scheduled replacement date for that part.
-
Page 26: Cut Quality And Mowing Tips
Cut Quality and Mowing Tips Problem Description Possible Cause Solution Streaking is when strips of uncut grass are left behind. Blades are not sharp Sharpen blades Blades are worn down too far Replace blades Streaking Engine RPM is too low Mow at full throttle GROUND SPEED IS TOO FAST SLOW DOWN... -
Page 27: Decals
DECALS CE DECALS EUROPEAN MODELS ONLY 76490090 DECAL, STANDER X 76490023 DECAL, CIRCLE WITH “W” 76490030, DECAL CE MAIN INST. PANEL 76490013 DECAL, MAIN INST. PANEL 76490095 DECAL, FUSION BLADE 76490031 DECAL CE THROTTLE INST. 76490008 DECAL, 76490005 DECAL, THROTTLE 48"... - Page 29 Notes:...
- Page 30 Notes:...
- Page 32 4600X Wedgewood Blvd Frederick, MD 21703 www.wrightmfg.com...
