Cabinet Parts - Jenn-Air JS42NXFXDW00 Parts List

Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10231366 Use & Care Guide
W10246792 Energy Guide
W10234135 Service & Wiring
Sheet
W10234151 Icemaker and
Ingredient Care
Center
Service Sheet
W10234149 Main Control
Service Sheet
W10231368 Installation
Instructions
2 Cabinet (Not A
Serviceable Part)
3 2318189 Tray, Drip Filter
4 W10138054 Roller, Front &
Rear (4)

CABINET PARTS

For Model: JS42NXFXDW00
(Base Model)
Illus. Part
No. No. DESCRIPTION
5 Support, Leveler
Assembly
W10138423 Refrigerator Side
W10138425 Freezer Side
6 Cap, Water Filter
2260518B Black
7 2307640 Mounting Stud,
Grille
8 Support, Grille
W10188499 Left
W10188500 Right
9 W10121451 Nutsert, Support
10 2260526 Housing, Water
Filter
12 4396841 Filter, Water
13 489399 Screw
14 W10234202 Pin−Stop, Door
15 Hinge (Top)
W10167397 RC
W10167398 FC
16 W10223655 Bracket, Mount
(Water Filter)
17 489464 Screw
2
Illus. Part
No. No. DESCRIPTION
18 486194 Screw
19 W10129069 Wire Clip (5)
20 Hinge (Bottom)
W10182692 RC
W10182693 FC
21 8533913 Screw 1/4−20 x 5/8
22 W10188549 Skirt−Grille,
Bottom
23 W10182717 Grille Bottom,
Front
24 1157158 Screw
25 2006617 Bracket, Support
Base (Rear) (2)
26 1163283 Screw
27 8281163 Screw
28 2260503B Button, Filter
29 C3680314 Switch, Rocker Arm
30 Cover, Switch
W10167387 Left
W10167341 Right
31 487415 Screw (2)
32 2215612 Cover, Rear
W10249719
