MODEL W1822
SLIDING TABLE
ATTACHMENT
OWNER'S MANUAL
(FOR MODELS MANUFACTURED SINCE 9/10)
Phone: (360) 734-3482 • Online Technical Support: tech-support@shopfox.biz
COPYRIGHT © JULY, 2010 BY WOODSTOCK INTERNATIONAL, INC., REVISED JULY, 2011 (TS)
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT
THE WRITTEN APPROVAL OF WOODSTOCK INTERNATIONAL, INC.
#12868TS
Printed in China
Advertisement
Table of Contents
Related Manuals for Woodstock SHOP FOX W1822
Summary of Contents for Woodstock SHOP FOX W1822
- Page 1 MODEL W1822 SLIDING TABLE ATTACHMENT OWNER'S MANUAL (FOR MODELS MANUFACTURED SINCE 9/10) Phone: (360) 734-3482 • Online Technical Support: tech-support@shopfox.biz COPYRIGHT © JULY, 2010 BY WOODSTOCK INTERNATIONAL, INC., REVISED JULY, 2011 (TS) WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF WOODSTOCK INTERNATIONAL, INC. #12868TS Printed in China...
- Page 2 This manual provides critical safety instructions on the proper setup, operation, maintenance, and service of this machine/tool. Save this document, refer to it often, and use it to instruct other operators. Failure to read, understand and follow the instructions in this manual may result in fire or serious personal injury—including amputation, electrocution, or death.
-
Page 3: Table Of Contents
Contents INTRODUCTION ........2 OPERATIONS........13 Important Notice! ........ 2 Operation Overview ......13 Woodstock Technical Support ....3 Crosscut Fence ......... 14 Specifications ........3 Extension Fence ........ 14 Extension Table ......... 14 SAFETY ..........4 Flip Stop ......... 15 Standard Machinery Safety ..... 4 Crosscutting ........ -
Page 4: Woodstock Technical Support
Woodstock International, Inc. is committed to customer satisfaction. Our intent with this manual is to include the basic information for safety, setup, operation, maintenance, and service of this product. -
Page 5: Safety
Model W1822 (For Machines Mfg. Since 9/10) Standard SAFETY SAFETY Machinery Safety READ MANUAL BEFORE OPERATING MACHINE. FAILURE TO FOLLOW INSTRUCTIONS BELOW WILL RESULT IN PERSONAL INJURY. Indicates an imminently hazardous situation which, if not avoided, WILL result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, COULD result in death or serious injury. - Page 6 Model W1822 (For Machines Mfg. Since 9/10) 10. NEVER LEAVE WHEN MACHINE IS RUNNING. Turn power OFF and allow all moving parts to come to a complete stop before leaving machine unattended. 11. DO NOT USE IN DANGEROUS ENVIRONMENTS. DO NOT use machinery in damp, wet locations, or where any flammable or noxious fumes may exist.
-
Page 7: Additional Safety For Sliding Table Saws
Model W1822 (For Machines Mfg. Since 9/10) Additional Safety for Sliding Table Saws READ and understand this USE this and other machinery with caution entire manual AND the and respect. Always consider safety first, table saw owner's manual as it applies to your individual working before using this attach- conditions. -
Page 8: Setup
Model W1822 (For Machines Mfg. Since 9/10) SETUP Unpacking The Model W1822 has been carefully packaged for safe transportation. If you notice the machine has been damaged during shipping, please contact your authorized Shop Fox dealer immediately. Inventory Refer to Figures 1–2 and the listing below to inventory the contents of the shipping box. -
Page 9: Assembly
Model W1822 (For Machines Mfg. Since 9/10) Assembly The assembly process typically requires modifications to NOTICE your table saw. To make the process easier, we strongly recommend that you have another person help you. Also, Additional tools will be needed for if you have to drill new holes, we recommend clamping cutting, grinding, drilling, and tapping the components in place when marking or drilling;... - Page 10 Model W1822 (For Machines Mfg. Since 9/10) 3. Thread the foot pad bolts into the bottom of the support legs, as shown in Figure 6. For now, do not Foot tighten the jam nuts against the legs so that you can adjust the height of the legs in a later step.
- Page 11 Model W1822 (For Machines Mfg. Since 9/10) 7. Align the mounting holes, then thread (2) M8-1.25 x 30 cap screws, 8mm lock washers, and 8mm flat washers through the sliding table into the mounting holes of the saw table. 8. Move the sliding table to the right and install the remaining M8-1.25 x 30 cap screw, 8mm lock washer, and 8mm flat washer.
- Page 12 Model W1822 (For Machines Mfg. Since 9/10) 13. Mark the right blade edge that is even with the table, then move the sliding table all the way toward the table saw front. If the sliding table does not travel exactly parallel to the saw blade, the 14.
- Page 13 Model W1822 (For Machines Mfg. Since 9/10) 17. Remove the T-bolt from the knurled pivot handle of the crosscut fence and set it aside for use in the Forward Set Screw next steps. T-Bolt 18. Slide the miter gauge bar into the sliding table miter gauge slot, as shown in Figure 13.
-
Page 14: Operations
Model W1822 (For Machines Mfg. Since 9/10) OPERATIONS Operation Overview The purpose of this overview is to provide the novice woodworker with a basic understanding of how the sliding table attachment is used during a typical operation, so they can more easily understand how to use it. Note: Due to the generic nature of this overview, it is not intended to be an instruction guide for performing actual machine operations. -
Page 15: Crosscut Fence
Model W1822 (For Machines Mfg. Since 9/10) Crosscut Fence The crosscut fence can be positioned anywhere along the Pivot sliding table and at angle between 50° left and 50° right. Handles To position the fence along the sliding table, loosen the two pivot handles, the set screw on the forward end of the miter gauge bar, and the miter gauge lock knob (see Figure 15). -
Page 16: Flip Stop
Model W1822 (For Machines Mfg. Since 9/10) Flip Stop Use the flip stop to make repetitive cuts of the same dimension. Lock Lever Slide the flip stop T-nut into the fence top T-slot, then secure the assembly in place with the lock lever, as shown in Figure 18. -
Page 17: Miter Cutting
Model W1822 (For Machines Mfg. Since 9/10) Miter Cutting The crosscut fence can be positioned for miter cuts between 50° the left and 50° right. To perform a miter cut, do these steps: Blade 1. DISCONNECT SAW FROM POWER! Workpiece 2. - Page 18 Inc. Dealer. If you do not have a dealer in your area, these products are also available through online dealers. Please call or e-mail Woodstock International Inc. Customer Service to get a current listing of dealers at: 1-800-840-8420 or at sales@woodstockint.com.
-
Page 19: Parts
Model W1822 (For Machines Mfg. Since 9/10) PARTS Table PART # DESCRIPTION PART # DESCRIPTION XPBHS09M BUTTON HD CAP SCR M6-1 X 12 X1822113 LOCK LEVER M8-1.25 XPLW03M LOCK WASHER 6MM X1822114 SUPPORT LEG XPW03M FLAT WASHER 6MM XPN03M HEX NUT M8-1.25 X1822104 SLIDING TABLE SIDE COVER X1822116... -
Page 20: Fence
Model W1822 (For Machines Mfg. Since 9/10) Fence 156V2 136 137 130V2 127V2 PART # DESCRIPTION PART # DESCRIPTION X1822121 KNURLED HANDLE M8-1.25 XPCAP01M CAP SCREW M6-1 X 16 X1822122 LONG CROSSCUT FENCE XPSS03M SET SCREW M6-1 X 8 X1822123 KNOB BOLT M6-1 X 35 X1822147 FLIP STOP BRACKET... - Page 22 Fold along dotted lIne place stamp Here Woodstock international inc. p.o. box 2309 bellingham, Wa 98227-2309 Fold along dotted lIne tape along edges--please do not staple...
-
Page 23: Warranty
