INSTALLATION
INSTRUCTIONS
IMPORTANT - SAVE FOR THE LOCAL ELECTRICAL INSPECTOR'S USE
IMPORTANT:
Installation should be performed only by an authorized Jenn-Air Service Contractor or other qualified
installer. Read safety precautions in the Use & Care Manual before using this appliance.
D
NOTE: "D" is clearance needed for unit depth measure down from top of countertop. Typical for all units.
D
UNITS PROVIDED WITH 1/2² (1.3 cm) I.D. FLEXIBLE CABLE 48² (121.9 cm) LONG WITH 6² (15.2 cm) WIRE LEADS
AT END, FURNISHED AND INSTALLED BY MANUFACTURER (CONNECT TO 240/120 VOLT ELECTRICAL SERVICE).
INSTRUCTIONS TO INSTALLER:
S
Side Clearance - unit may be safely installed as near as 0² (0 cm) from a side wall if space limitations requires.
Notice To Installer: Leave these instructions with the appliance.
Notice To Consumer: Retain these instructions for future reference.
Radiant Cooktop
Models JEC8430 & JEC8536
(Dimensions shown in both inches and centimeters)
F
E
G
B
A
403 WEST FOURTH STREET, NORTH D NEWTON, IA 50208
FOUR-ELEMENT RADIANT COOKTOPS
inches
A
29-1/16 + 1/16
B
20-3/8 + 1/16
C
2-1/8 min.
D
4-1/8 min. clear
E
29-15/16
F
G
FIVE-ELEMENT RADIANT COOKTOPS
inches
A
34-9/16 + 1/16
B
20-3/8 + 1/16
C
2-1/8 min.
D
4-1/8 min. clear
E
35-5/16
F
G
C
CUTOUT DIMENSIONS
DIMENSIONS
74.0 + 0.2
51.9 + 0.2
10.5
76.0
21-1/2
54.6
3-3/4
DIMENSIONS
87.9 + 0.2
51.9 + 0.2
10.5
89.7
21-1/2
54.6
3-3/4
IMPORTANT
ARE CRITICAL
8101P503-60
cm
5.4
9.5
cm
5.4
9.5
(10-02-00)
