Reassembly Process
Reinstalling the Keyboard
1. Place the keyboard in its slot in the upper case assembly.
Figure 3-59. Keyboard
2. Secure the keyboard to the upper case assembly using fifty three screws.
Figure 3-60. Keyboard Screws
Table 3-60. Screws
Step
Keyboard Reassembly
Machine Maintenance
Screw
M1.2 × L1
Quantity
Screw Type
53
0
0
3-39
