LED INDICATIONS

The LED indicator at the front of the Ap1310-DC has a number of colour combinations, which repeat
in up to a 4-phase pattern to provide status information (see table below).
In summary, if the LED is constant green it indicates that the printer is operating normally. Flashing
on and off indicates that Spool mode is active and no printing can take place. Red warns of a low
power supply voltage or other problem. No light indicates that the unit is off.
LED Pattern Table
Pattern
Constant Green
Fast Flashing Green
Long Green - Short Red
Short Green - Short Red
Fast Flashing Red
No light
*
(Spool may have resulted from Paper Out or Head Up conditions)
Although this table may seem complicated, few applications will produce many of the combinations.
Other LED Patterns
Other LED patterns may be programmed into the Ap1310-DC on request or by the system designer.
Please refer to the Programmers' Guide for details of how to configure these functions.
Power Status
OK
OK
Low Voltage
Low Voltage
Error Condition
Ap1310-DC User Guide Page 7 of 13
Buffer Mode
Normal
Spool *
Normal
Spool *
Spool (Printing prohibited)
Printer is off
