LED INDICATIONS

The LED indicator at the front of the Ap1300 has a number of colour combinations, which repeat in up
to a 4-phase pattern to provide status information (see table below).
In summary, if the LED is constant green it indicates that the printer is operating normally from its
battery pack. Flashing on and off indicates that Spool mode is active and no printing can take place.
Orange advises the battery is being charged. Red warns of a low battery or other problem.
No light indicates that the unit is in sleep mode, has a flat battery, or the battery is not connected.
LED Pattern Table
Pattern
Constant Green
Fast Flashing Green
Long Green - Short Red
Short Green - Short Red
Short Green - Long Orange
Long Orange Flashing
Fast Flashing Orange
Fast Flashing Red
No light
*
(Spool may have resulted from Paper Out or Head Up conditions)
Although this table may seem complicated, few applications will produce many of the combinations.
Other LED Patterns
Other LED patterns may be programmed into the Ap1300 on request or by the system designer.
Please refer to the Programmers' Guide for details of how to configure these functions.
Battery
Running
Running
Battery Low
Battery Low
Trickle Charging
Trickle Charging
Fast Charging
Error Condition
Flat, or in sleep mode
Ap1300 User Guide Page 9 of 16
Buffer Mode
Normal
Spool *
Normal
Spool *
Normal
Spool *
Spool (Printing prohibited)
Spool (Printing prohibited)
