8.5

DATA CABLE

You can attach a suitable data cable terminated with a female D9 connector. As a guide the pinout for
a standard 9 way PC comm port (male) is given below.
D-9 Pin Name
3 TxD
2 RxD
6 & 8 CTS & DSR
5 SGND
8.6

EMC STATEMENT

The Ap1310-DC is fully EMC (Electro-Magnetic Compatibility) compliant and is CE marked
accordingly. A Declaration of Conformity, in accordance with the EMC Directive 89/336/EEC (and as
amended) is available from Able Systems on request. The Ap1310-DC also carries an automotive e-
mark that applies, provided the printer is installed in-line with the directive.
8.7

EMC Caution

System EMC compliance remains the responsibility of the system designer. It is recommended that
screened cables are used; earthing arrangements will depend on the application. Further advice is
available from Able Systems on request.
Function (refers to PC)
Serial Data Output
Serial Data Input
Busy Input
Signal Common 0V
Ap1310-DC User Guide Page 11 of 13
