N58L00002.eps N58FFDBGA1.eps N58RFDCHA3.eps N58BABAAC2.eps
N58SDDLEE1.eps N58TBBAAB5.eps N58CACBAA3.eps N58XEAAAA1.eps
N58YDAAAC5.eps N58I115TServo.eps W241638600.eps S241638600.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
GHSC39EJPB0 GHSC39EJPW0
Series
counter depth
Color
black
Volts
115
Wiring Diagram
241638600
Owner's Guide
241857500
Market
North America
Energy Guide
241868030
Service Data Sheet 241639000
Publication No.
5995511598
08/04/11
(EN/SERVICE/DCS)
137
counter depth
white
115
241638600
241857500
North America
241868030
241639000
SIDE-BY-SIDE
REFRIGERATOR
Model No.
GHSC39EJP
©
Copyright
2008 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GHSC39EJPB - 22.6 Cu. Ft. 8 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire GHSC39EJPB - 22.6 Cu. Ft. 8

Summary of Contents for Frigidaire GHSC39EJPB - 22.6 Cu. Ft. 8

  • Page 1 Product No. GHSC39EJPB0 GHSC39EJPW0 Series counter depth counter depth Color black white Volts Wiring Diagram 241638600 241638600 Owner's Guide 241857500 241857500 Market North America North America Energy Guide 241868030 241868030 Service Data Sheet 241639000 241639000 SIDE-BY-SIDE N58L00002.eps N58FFDBGA1.eps N58RFDCHA3.eps N58BABAAC2.eps REFRIGERATOR N58SDDLEE1.eps N58TBBAAB5.eps N58CACBAA3.eps N58XEAAAA1.eps N58YDAAAC5.eps N58I115TServo.eps W241638600.eps S241638600.eps...

  • Page 2: Freezer Door

    Publication No: 5995511598 GHSC39EJP FREEZER DOOR N58FFDBGA1 04/08...
  • Page 3 GHSC39EJP Publication No: 5995511598 FREEZER DOOR Model Index: A GHSC39EJ (GHSC39EJPB0) B GHSC39EJ (GHSC39EJPW0) POS. NO PART NO. DESCRIPTION 241510204 Gasket-frzr door, black, magnetic 241510202 Gasket-frzr door, white, magnetic 241808216 Bin-door, pseudo, frzr 241545001 Bin-tilt out, tilt-out 241526790 Door-frzr, black, complete assy 241526789 Door-frzr, white, complete assy 240581906...

  • Page 4: Refrigerator Door

    Publication No: 5995511598 GHSC39EJP REFRIGERATOR DOOR N58RFDCHA3 04/08...
  • Page 5 GHSC39EJP Publication No: 5995511598 REFRIGERATOR DOOR Model Index: A GHSC39EJ (GHSC39EJPB0) B GHSC39EJ (GHSC39EJPW0) POS. NO PART NO. DESCRIPTION 241510203 Gasket-refr door, black, magnetic 241510201 Gasket-refr door, white, magnetic 241516102 Rack-can 241515901 Lug-dairy compartment 241515601 Door-dairy 241808601 Label-nameplate 240581905 Door Stop, black, ref 240581901 Door Stop, white, refr 241534585...
  • Page 6 Publication No: 5995511598 GHSC39EJP CABINET N58BABAAC2 04/08...
  • Page 7 GHSC39EJP Publication No: 5995511598 CABINET Model Index: A GHSC39EJ (GHSC39EJPB0) B GHSC39EJ (GHSC39EJPW0) POS. NO PART NO. DESCRIPTION 241509804 Cover-air duct 241719711 Cover-evap coil, lower 5303208309 Plug-hole, factory test 241547901 Switch-light/lamp, frzr door 218252201 Screw, #8 truss hd, 10-32CA x 0.500 240457702 Plate-door closer 240457701...
  • Page 8 Publication No: 5995511598 GHSC39EJP SHELVES N58SDDLEE1 04/08...
  • Page 9 GHSC39EJP Publication No: 5995511598 SHELVES Model Index: A GHSC39EJ (GHSC39EJPB0) B GHSC39EJ (GHSC39EJPW0) POS. NO PART NO. DESCRIPTION 241510605 Trim-basket 241711213 Shelf-freezer, glass, lower 241711214 Shelf-freezer, glass, upper 241552801 Light Bulb 241622802 Socket-light 241513102 Harness-wiring 5304455658 Screw, hx wshr hd sems, 8-15A x 0.625 240355239 Shelf-"Spill-Safe", fixed 240350126...
  • Page 10 Publication No: 5995511598 GHSC39EJP CONTROLS N58TBBAAB5 04/08...
  • Page 11 GHSC39EJP Publication No: 5995511598 CONTROLS Model Index: A GHSC39EJ (GHSC39EJPB0) B GHSC39EJ (GHSC39EJPW0) POS. NO PART NO. DESCRIPTION 5308000010 Fan Blade, red, evaporator fan 215474201 Washer, "slinger", nylon, evap fan shaft 241518301 Bushing, motor mounting 241509402 Motor, evaporator fan 241510501 Seal-diffuser 241517701 Clip, evap fan motor...
  • Page 12 Publication No: 5995511598 GHSC39EJP SYSTEM N58CACBAA3 04/08...
  • Page 13 GHSC39EJP Publication No: 5995511598 SYSTEM Model Index: A GHSC39EJ (GHSC39EJPB0) B GHSC39EJ (GHSC39EJPW0) POS. NO PART NO. DESCRIPTION 240333605 Condenser 218679607 Block-evap coil, styrofoam, (2) 218944001 Drier-filter, R134a System 241516901 Cord-service 6* # 241510802 Harness-wiring, control box 6* # 241519902 Harness-wiring 6* # 241527202...

  • Page 14: Ice And Water Dispenser

    Publication No: 5995511598 GHSC39EJP ICE & WATER DISPENSER N58XEAAAA1 04/08...
  • Page 15 GHSC39EJP Publication No: 5995511598 ICE & WATER DISPENSER Model Index: A GHSC39EJ (GHSC39EJPB0) B GHSC39EJ (GHSC39EJPW0) POS. NO PART NO. DESCRIPTION 218976409 Tube, water, door 218976418 Tube-water inlet, inlet valve, to filter 218976421 Tube-water inlet, valve to door 218976915 Tube-water inlet, inlet valve, to filter 240561702 Seal-water inlet, inlet valve, to ice maker 241678703...

  • Page 16: Ice Container

    Publication No: 5995511598 GHSC39EJP ICE CONTAINER 37A 34 34 33 N58YDAAAC5 04/08...
  • Page 17 GHSC39EJP Publication No: 5995511598 ICE CONTAINER Model Index: A GHSC39EJ (GHSC39EJPB0) B GHSC39EJ (GHSC39EJPW0) POS. NO PART NO. DESCRIPTION 241684701 Auger-ice 241685201 Cam-drive 241515202 Container-ice, bucket only 241685101 Drum-ice disp 241515301 Front-ice container 241726501 Bar-drive 241685301 Gate 241555401 Light Bulb 241559801 Socket-light 241684501...

  • Page 18: Ice Maker

    Publication No: 5995511598 GHSC39EJP ICE MAKER INSTALLATION PARTS N58I115TServo 04/08...
  • Page 19 GHSC39EJP Publication No: 5995511598 ICE MAKER Model Index: A GHSC39EJ (GHSC39EJPB0) B GHSC39EJ (GHSC39EJPW0) POS. NO PART NO. DESCRIPTION 218976409 Tube, water, door 218976418 Tube-water inlet, inlet valve, to filter 218976421 Tube-water inlet, valve to door 218976915 Tube-water inlet, inlet valve, to filter 240561702 Seal-water inlet, inlet valve, to ice maker 5304459922...
  • Page 20 Publication No: 5995511598 GHSC39EJP ICE MAKER INSTALLATION PARTS N58I115TServo 04/08...
  • Page 21 GHSC39EJP Publication No: 5995511598 ICE MAKER Model Index: A GHSC39EJ (GHSC39EJPB0) B GHSC39EJ (GHSC39EJPW0) POS. NO PART NO. DESCRIPTION 5304455651 Screw, hex washer head, 8-15A x 0.500 5304455846 Clamp, .31 ID, steel, water tube 5304458374 Bracket-ice maker 5304458392 Switch-on/off 241583301 Deflector-air, ice maker 241806601 Connector-water, straight...

  • Page 22: Wiring Schematic

    Publication No: 5995511598 GHSC39EJP WIRING SCHEMATIC 04/08...

  • Page 23: Wiring Diagram

    GHSC39EJP Publication No: 5995511598 WIRING DIAGRAM DISPENSER ASSY WIRING GRN/YEL BLU/WHT LT. BLU RED/BLK ORG/WHT BARE NATURAL WHT/YEL BRN/YEL BLK/YEL RED/YEL YEL/PNK ORG/WHT YEL/GRY GRN/YEL LT. BLU DIODE SPLICE TAN/YEL SPLICE SPLICE DIODE DIODES MUST BE POLARIZED IN SAME DIRECTION SUPPLY LIGHTS 2416386...
