E23CS75DSS0.eps N58FKGBGA0.eps N58RKGCHB0.eps N58BABAAD2.eps
N58SDHLBE1.eps N58TBAAAB2.eps N58CACBAA3.eps N58XEBAAA1.eps
N58YDAAAC0.eps N58I115T.eps W241638600.eps S241638600.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
GHSC39ETES3 GHSC39ETEW3
Series
counter depth
Color
stain/blk
Volts
115
Wiring Diagram
241638600
Owner's Guide
241540301
Market
North America
Energy Guide
241607588
Service Data Sheet 241639000
Publication No.
5995449625
05/09/29
(EN/SERVICE/WC)
357
counter depth
white
115
241638600
241540301
North America
241607588
241639000
SIDE-BY-SIDE
REFRIGERATOR
Model No.
GHSC39ETE /
GHSC39ET
©
Copyright
2005 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire GHSC39ET
Summary of Contents for Frigidaire GHSC39ET
- Page 1 Owner's Guide 241540301 241540301 Market North America North America Energy Guide 241607588 241607588 Service Data Sheet 241639000 241639000 REFRIGERATOR Publication No. 5995449625 05/09/29 (EN/SERVICE/WC) Copyright SIDE-BY-SIDE Model No. GHSC39ETE / GHSC39ET © 2005 Electrolux Home Products, Inc. All rights reserved.
-
Page 2: Freezer Door
Publication No: 5995449625 09/05 GHSC39ETE / GHSC39ET FREEZER DOOR N58FKGBGA0... - Page 3 241533807 241533801 241525101 240352102 240411501 240552102 5303918256 # Functional Parts * Non-Illustrated Parts GHSC39ETE / GHSC39ET FREEZER DOOR A GHSC39ETE (GHSC39ETES3) B GHSC39ETE (GHSC39ETEW3) DESCRIPTION Gasket-frzr door, black, magnetic Gasket-frzr door, white, magnetic Bin-door, pseudo, frzr Bin-tilt out, tilt-out Door-frzr, black, complete assy...
-
Page 4: Refrigerator Door
Publication No: 5995449625 GHSC39ETE / GHSC39ET REFRIGERATOR DOOR N58RKGCHB0 09/05... - Page 5 241534202 241533808 241533802 241511704 241505304 241505504 241508401 241515801 # Functional Parts * Non-Illustrated Parts GHSC39ETE / GHSC39ET REFRIGERATOR DOOR A GHSC39ETE (GHSC39ETES3) B GHSC39ETE (GHSC39ETEW3) DESCRIPTION Gasket-refr door, black, magnetic Gasket-refr door, white, magnetic Rack-can Lug-dairy compartment Door-dairy Door Stop, black, ref...
- Page 6 Publication No: 5995449625 N58BABAAD2 09/05 GHSC39ETE / GHSC39ET CABINET...
- Page 7 240423701 100* 240350802 240479601 241591701 5303305345 5303305324 # Functional Parts * Non-Illustrated Parts GHSC39ETE / GHSC39ET CABINET A GHSC39ETE (GHSC39ETES3) B GHSC39ETE (GHSC39ETEW3) DESCRIPTION Cover-air duct Cover-evap coil, lower Plug-hole, factory test Switch-light/lamp, frzr door Screw, #8 truss hd, 10-32CA x 0.500...
- Page 8 Publication No: 5995449625 09/05 GHSC39ETE / GHSC39ET SHELVES N58SDHLBE1...
- Page 9 241513401 241513301 241513202 241504501 241504701 241504702 241630701 241630702 240424502 240430505 # Functional Parts * Non-Illustrated Parts GHSC39ETE / GHSC39ET SHELVES A GHSC39ETE (GHSC39ETES3) B GHSC39ETE (GHSC39ETEW3) DESCRIPTION Trim-basket Shelf-freezer, glass, lower Shelf-freezer, glass, upper Light Bulb Socket-light Harness-wiring Shelf-"Spill-Safe", fixed Shelf-"Spill-Safe", cantilever, sliding...
- Page 10 Publication No: 5995449625 GHSC39ETE / GHSC39ET CONTROLS N58TBAAAB2 09/05...
- Page 11 240397401 240397501 199* 240398401 241544902 3205266 # Functional Parts * Non-Illustrated Parts GHSC39ETE / GHSC39ET CONTROLS A GHSC39ETE (GHSC39ETES3) B GHSC39ETE (GHSC39ETEW3) DESCRIPTION Fan Blade, red, evaporator fan Washer, "slinger", nylon, evap fan shaft Bushing, motor mounting Motor, evaporator fan...
- Page 12 Publication No: 5995449625 09/05 GHSC39ETE / GHSC39ET SYSTEM N58CACBAA3...
- Page 13 240429402 218990801 5304418225 5303316859 5304421068 240553501 240409302 5303918222 5303918300 # Functional Parts * Non-Illustrated Parts GHSC39ETE / GHSC39ET SYSTEM A GHSC39ETE (GHSC39ETES3) B GHSC39ETE (GHSC39ETEW3) DESCRIPTION Condenser Block-evap coil, styrofoam, (2) Drier-filter, R134a System Cord-service Harness-wiring Harness-wiring Harness-wiring, machine compt...
-
Page 14: Ice And Water Dispenser
Publication No: 5995449625 09/05 GHSC39ETE / GHSC39ET ICE & WATER DISPENSER N58XEBAAA1... - Page 15 5304421830 5304421622 5304421621 240411501 5303918256 5304426535 # Functional Parts * Non-Illustrated Parts GHSC39ETE / GHSC39ET ICE & WATER DISPENSER A GHSC39ETE (GHSC39ETES3) B GHSC39ETE (GHSC39ETEW3) DESCRIPTION Tube-water-DOOR Tube-water inlet, inlet valve, to ice maker Tube-water inlet, inlet valve, to filter...
-
Page 16: Ice Container
Publication No: 5995449625 09/05 GHSC39ETE / GHSC39ET ICE CONTAINER 37A 34 34 33 N58YDAAAC0... - Page 17 5304404355 5304404357 5304404360 5304404361 5304404331 241504601 241551601 215005100 240562101 241504301 # Functional Parts * Non-Illustrated Parts GHSC39ETE / GHSC39ET ICE CONTAINER A GHSC39ETE (GHSC39ETES3) B GHSC39ETE (GHSC39ETEW3) DESCRIPTION Auger-ice Cam-drive Container-ice, bucket only Drum-ice disp Front-ice container Bar-drive Gate Light Bulb...
-
Page 18: Ice Maker
Publication No: 5995449625 09/05 GHSC39ETE / GHSC39ET ICE MAKER INSTALLATION PARTS N58I115T... - Page 19 5303001193 241523502 55 # 240531101 218709100 240363601 # Functional Parts * Non-Illustrated Parts GHSC39ETE / GHSC39ET ICE MAKER A GHSC39ETE (GHSC39ETES3) B GHSC39ETE (GHSC39ETEW3) DESCRIPTION Tube-water-DOOR Tube-water inlet, inlet valve, to ice maker Tube-water inlet, inlet valve, to filter Tube-water inlet, valve to door...
- Page 20 Publication No: 5995449625 09/05 GHSC39ETE / GHSC39ET ICE MAKER INSTALLATION PARTS N58I115T...
- Page 21 5304436611 5304436612 218888001 241583301 241627701 # Functional Parts * Non-Illustrated Parts GHSC39ETE / GHSC39ET ICE MAKER A GHSC39ETE (GHSC39ETES3) B GHSC39ETE (GHSC39ETEW3) DESCRIPTION Cap-water valve Screw, hex washer head, 8-15A x 1.000, (2) Clamp, 0.31 ID, steel, copper wtr line...
-
Page 22: Wiring Schematic
Publication No: 5995449625 GHSC39ETE / GHSC39ET WIRING SCHEMATIC 09/05... -
Page 23: Wiring Diagram
2416386 # Functional Parts * Non-Illustrated Parts GHSC39ETE / GHSC39ET WIRING DIAGRAM DISPENSER ASSY WIRING GRN/YEL BLU/WHT LT. BLU RED/BLK ORG/WHT BARE NATURAL WHT/YEL BRN/YEL BLK/YEL RED/YEL YEL/PNK ORG/WHT YEL/GRY GRN/YEL LT. BLU DIODE SPLICE TAN/YEL SPLICE SPLICE DIODE DIODES MUST BE...
