Summary of Contents for LG LSC21943ST - 21.0 cu. ft

  • Page 2 Table of Contents Introduction Installation Operation Suggestion on food storage Care and maintenance...

  • Page 3: Recommended Grounding Method

    Entry The model and serial numbers are found on the inner case or back of refrigerator compartment of this unit. These numbers are unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase.

  • Page 4: Grounding (Earthing)

    Do not modify or extend the Power Cord length. Warning It may cause electric shock or fire. Child entrapment DANGER: Risk of child entrapment. Before you throw away your old refrigerator or freezer: warning Take off the doors but leave the shelves in place so that children may not easily climb inside.

  • Page 5: When Connecting The Power

    1. When connecting the power The dedicated outlet should be used. • Using several devices at one outlet may cause fire. • The electric leakage breaker may damage food and the dispenser may be leaked. Do not allow the power plug to face upward or to be squeezed at the back of the refrigerator.

  • Page 6: When Using The Refrigerator

    2. When using the refrigerator Do not place the heavy object or the dangerous object (container with liquid) on the refrigerator. It may be dropped to cause injury, fire or electric shock when opening or closing the door. Do not install the refrigerator in the wet place or the place which water or rain splashes.
  • Page 7 2. When using the refrigerator Avoid the heating devices. It may cause fire. Do not place flower vase, cup, cosmetics, medicine or any container with water on the refrigerator. It may cause fire, electric shock or injury by dropping down. Use the submerged refrigerator after checking it.
  • Page 8 Do not use the refrigerator for non-domestic purpose (storing medicine or testing material, using at the ship, etc.). It may cause an unexpected risk such as fire, electric shock, deterioration of stored material or chemical reaction. When disposing the refrigerator, remove the packing materials from the door.
  • Page 9 When the electricity is off, remove ice from the ice bucket (only for the model with the dispenser). The long-time power failure may thaw ice to damage the floor. When the long-time power failure is expected, remove ice from the ice bucket. Supply the automatic ice maker with drinkable water only Drinkable water...

  • Page 10: Identification Of Parts

    Because opening or closing the door of the refrigerator may cause injury to the person around it, be careful, please. Opening or closing the door may cause feet or hands to be caught in the chink in door or the child to be get hurt by the corner.

  • Page 11: Where To Install

    Where to install Unstable installation may cause vibration and Strong and even floor noise. If the floor to install the refrigerator on is not even, make the refrigerator level by rotating the height adjusting screw. Carpet or floor covering on which a refrigerator is 0AECDJ installed may be discolored by heat from the bottom of the refrigerator.

  • Page 12: Door Removal

    Door removal Warning Electric Shock Hazard Disconnect electrical supply to refrigerator before installing. Lower cover Failure to do so could result in death or serious injury. If your entrance door is too narrow for the refrigerator to pass through, remove the Feed water tube refrigerator door and pass the refrigerator laterally.

  • Page 13: Mount The Freezer And Refrigerator Compartment Doors

    Pass the refrigerator laterally through the access Pass the refrigerator door as shown in the right figure. Mount the freezer and refrigerator compartment doors Mount them in the reverse sequence of removal after they pass through the access door. Water supply installation Before Automatic icemaker operation needs water pressure of 21~121 psi (1.5~8.5 installation...

  • Page 14: Tools Required

    Water connection instruction guide Connecting Read all directions carefully before you begin. the refrigerator to a water source Warning Connect to a potable water supply only. IMPORTANT • If operating the refrigerator before installing the water connection, turn icemaker to the OFF position to prevent operation without water. •...
  • Page 15 Connect 1. Unplug refrigerator or disconnect power. the tubing to 2. Turn OFF main water supply. Turn on the nearest faucet to relieve the pressure water line on the line. It may help to open an outside faucet to allow the water to drain from the line in the house.
  • Page 16 Connect the tubing to Before making the connection to the refrigerator, be sure the refrigerator the refrigerator power cord is not plugged into the wall outlet. If your refrigerator does not have a water filter, we recommend installing • one. If your water supply has sand or particles, that could clog the screen of the refrigerator’s water valve.

  • Page 17: Height Adjustment

    Height adjustment If the freezer Make them level by inserting a flat ( - type) driver into the groove of the left height adjusting screw and rotating it clockwise . compartment door is lower than the refrigerator compartment door If the freezer Make them level by inserting a flat ( - type) driver into the groove of the right height compartment door adjusting screw and rotating it clockwise .

  • Page 18: Overall Dimensions

    Dimensions Overall Dimensions Door Swing Dimension 90° LSC279** LSC219** 155° LSC219** LSC279** Clearances Cabinet Dimensions Allow the following clearances for ease of installation, proper air circulation and plumbing and electrical connections. SIDE Back - If the refrigerator faces to a fixed wall, leave Model 4 1/4”(108mm) minimum on each side to LSC219**...

  • Page 19: Adjusting The Temperatures And Functions

    Starting When your refrigerator is first installed, allow it to stabilize at normal operating temperatures 2~3 hours prior to filling it with fresh or frozen foods. If operation is interrupted, wait 5 minutes before restarting. Adjusting the temperatures and functions NOTE Your model may not include every option.
  • Page 20 1. Display Power Saving Mode This function places the display into power saving mode until the next time the door is opened. Press the FREEZER and ICE PLUS buttons simultaneously and hold them for 5 seconds until the Ding sounds. All LEDs will then turn ON, then OFF. When the power saving mode is activated, the display will remain off until the next time the door is opened.

  • Page 21: How To Use Dispenser

    How to use Select among crushed ice, water, and cubed ice and press the push switch with a glass or other container. dispenser Crushed Ice Water Cubed Ice Light the crushed ice Light the water lamp by Light the cubed ice lamp by pressing the pressing the selection lamp by pressing the...
  • Page 22 Ice is lumped together When ice dispensing does If the ice lumps together, take it out, break it apart, and put it back into the storage bin. not operate When the icemaker produces too small or lumped together ice, the amount of smoothly water supplied to the ice maker needs to adjusted.

  • Page 23: Door Alarm

    This button stops operation of different button and dispenser function. Lock Locking or Release is repeated whenever is pressed more than 3 seconds. 3 SECS LOCK 3 SECS LOCK If you use the ALARM/LOCK button, DISPENSER & BUTTON DISPENSER & BUTTON none of the other buttons will work LOCK UNLOCK...

  • Page 24: Other Functions

    Other functions Ambient Temperature Display Window. Temperature is displayed only between 16°F ~ 120°F (-9°C ~ 49°C). Temperature below 15°F (-9°C) is indicated by LO and temperature above 121°F (49°C) is indicated by HI. Diagnostic (failure detection) function The diagnostic function automatically detects failure when failure is found in product during the use of refrigerator.

  • Page 25: Folding Shelf

    Shelf Folding Shelf You can store taller items such as a gallon container or bottles by simply pushing in front half of shelf underneath back half of shelf. Pull toward you to return to a full shelf. Bottle holder (Applicable to some models only) Wine holder Bottles can be stored laterally with adjustment...

  • Page 26: Humidity Control In The Vegetable Compartment

    Egg box You can move the egg box to wherever you want. [Type-1] [Type-2] NOTE Never use the egg box as an ice storage bin. It can be broken. • Never store the egg box in the freezer compartment or fresh compartment. •...

  • Page 27: Temperature Change At Optichill

    Optichill Temperature Transition Corner By pressing the button, store vegetables, fruits or other types of food such as meat to be defrosted, raw fish, etc. Temperature Change at Optichill Method to Use You can select optimum temperature range depending on types of foods stored.

  • Page 28: Location Of Foods

    Location of foods (Refer to identification of parts) Bottle holder Store bottles. Snack drawer Store small foods such as bread, snacks, etc.. Freezer Store various frozen foods such as meat, fish, compartment ice cream, frozen snacks, etc.. shelf Store small packed frozen food. Freezer Temperature is likely to increase as door compartment...

  • Page 29: Storing Foods

    Storing foods Store fresh food in the refrigerator compartment. How food is frozen and thawed is an important factor in maintaining its freshness and flavor. Do not store food which spoils easily at low temperatures, such as bananas and melons. Allow hot food to cool prior to storing.

  • Page 30: How To Remove And Replace Parts

    How to remove and replace parts NOTE Dismantling is done in the reverse sequence of assembly. • Be sure to unplug the power plug before dismantling and assembly. Never apply severe force to dismantle parts. Parts may be damaged. Separate the lamp by pulling it out ➂ while Freezer slightly striking ➀...
  • Page 31 Lamp in Insert the tool into the marked area ( ) and push refrigerator the tool to disconnect. compartment Use the tool with the flat tip such as a flat (-) screw driver. Turn the bulb counterclockwise. Max. 40 W bulb for refrigerator is used and can be purchased at a service center.

  • Page 32: General Information

    General information During average length vacations, you will probably find it best to leave the refrigerator Vacation time in operation. Place freezable items in freezer for longer life. When you plan to turn it off, remove all food, disconnect the power cord, clean the interior thoroughly, and leave each door OPEN to prevent odor formation.

  • Page 33: Troubleshooting

    Troubleshooting Before calling for service, review this list. It may save you both time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Occurrence Possible cause Solution Runing of refrigerator Refrigerator control is off.
  • Page 34 Occurrence Possible cause Solution Refrigerator Thermostat is keeping the refrigerator This is normal. The refrigerator goes on compressor at a constant temperature. and off to keep the temperature constant. does not run. Temperatures are too cold Temperature in the Set the freezer control to a warmer Freezer control is set too cold freezer is too cold setting until the freezer temperature is...
  • Page 35 Possible cause Solution Occurrence Sound and noise Louder sound Today’s refrigerators have increased It is normal for sound levels to be higher. levels when storage capacity and maintain more refrigerator is on. even temperatures. Louder sound Refrigerator operates at higher pressures This is normal.
  • Page 36 Occurrence Possible cause Solution Odors in refrigerator Clean interior with sponge,warm water Interior needs to be cleaned. and baking soda. Cover food completely. Food with strong odor is in the refrigerator. Some containers and wrapping materials Use a different container or brand of produce odors.
  • Page 37 Occurrence Possible cause Solution Dispenser will Ice has melted and frozen around auger Remove ice storage bin, and thaw and not dispense due to infrequent use, temperature the contents. Clean bin, wipe dry and ice. fluctuations and/or power outrages. replace in proper position. When new ice is made, dispenser should operate.
  • Page 38 LG ELECTRONICS, INC. LG REFRIGERATOR LIMITED WARRANTY - USA...
