Connections

Please ensure that the M2 Line, the power amplifier and any source equipment is
switched off before making any connections.
NOTE: It is important that all connections are firm, secure and airtight; any
oxidisation of the interconnects will result in loss of performance. Always use high
quality interconnects; Audio Note interconnects are recommended, as they are
manufactured to the same exacting standards as all of our products.

Inputs

The M2 Line offers four standard unbalanced line inputs and a tape input. All of these
are suitable for connecting to any line level source equipment such as a CD/DVD
player or a dedicated phono stage for a turntable.
The inputs each consist of a pair of RCA connectors, one red and one white, for right
and left channels respectively.

Outputs

The M2 Line provides two unbalanced outputs and a tape output. Again, all of these
outputs consist of a pair of colour coded RCA connectors.
The two main outputs are for connection to a power amplifier and are identical,
making them suitable for biwiring.
The tape output is routed directly from the input selection switch; this provides a
suitable level for recording. The tape input is not routed to the tape output.

Feedback switches

Two feedback switches are located next to the ground terminal on the rear panel.
These are used for matching the pre-amplifier to the rest of your system. Set the
switches to the 'on' position if any of the following apply, when in doubt, choose the
setting that provides the best sonic performance:
If the volume control is too sensitive.
If the interconnects between the pre-amplifier and the power amplifier are
longer than 3 metres.
If your amplifier has an input impedance of less than 50kO
NOTE: Always turn the power off before adjusting the feedback switches. Ensure that
both feedback switches are in the same position.
