Removing the scanner top

Note: The following procedures should be done with two persons.
The scanner top (document cover) uses two locking tabs to prevent accidentally separation. To remove the document
cover:
1
Turn the printer off.
2
Unplug the power cord from the wall outlet.
3
Disconnect the two scanner cables.
4
Open the document cover.
5
Lift the cover.
6
Press and hold the locking tabs while lifting the cover.
Note: If the cover is leaning forward, it is difficult to unlock the tabs.
