Replacing The Keyboard - Lenovo 32597CU User Manual

7. With the notched end of the memory module toward the contact edge side of the socket, insert the
memory module 1
Note: If you install a memory module in only one of the two memory slots, install it in the bottom slot.
8. Pivot the memory module downward until it snaps into place.
9. Make sure that the memory module is firmly installed in the slot and cannot be moved easily.
10. Reinstall the computer cover
11. Reinstall the battery. See "Replacing the battery" on page 63.
12. Turn the computer over again. Connect the ac power adapter and all cables.

Replacing the keyboard

Before you start, print these instructions.
82
User Guide
into the socket at an angle of about 20 degrees; then press it in firmly
1 . Then tighten the screws 2 .
2 .
