Freecom MediaPlayer II
Coaxial output connection
EN

Coaxial output: Connect the product coaxial connector with the coaxial connector of
your video or audio device by using a coaxial cable. Enter the product's audio setup and
select the Digital Output option "SPDIF LPCM" or "SPDIF RAW". It is possible to enjoy 5.1
high quality sound through a multi channel decoder/amplifier with coaxial input.
HDMI output mode
HDMI is an output with best audio and video quality which outputs digital video and
audio composited at the same time. Connect HDMI cable to output of product and
display device with HDMI input. Select HDMI mode in TV until it displays the interface
of initiation.
3. Connection and setup of network
The product can play files stored on the PC directly through network. Please connect the
RJ45 cable according to the following illustration. The network is connected well when
the LEDs of network status and R/W are blinking (on RJ45 connector).
Connect one end of the RJ45 cable to the product like the PC does and connect the
video output. Press "setup" key or select "setup" menu in the initiation interface. Select
"Network" option in the setup window and press "ENTER" to confirm. It is available for
both automatic and manual IP setup. Press "setup" key again to exist after setup. Before
access the PC through network by the product, the media files must be shared in the
network.
Following is the setup of media file sharing in PC.
