USER'S MANUAL FOR BUILT-IN OVEN
Multifunction S4000, cod. 7133 043
Foster
spa
via M.S. Ottone, 18/20
42041 Brescello (RE) - Italy
tel. +39.0522.687425 - tel. Servizio Assistenza +39.0522.684450
fax +39.0522.686019 - fax Servizio Ricambi +39.0522.962166
e-mail: service@fosterspa.com
www.fosterspa.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Multifunction S4000, cod. 7133 043 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Foster Multifunction S4000, cod. 7133 043

Summary of Contents for Foster Multifunction S4000, cod. 7133 043

  • Page 1 USER'S MANUAL FOR BUILT-IN OVEN Multifunction S4000, cod. 7133 043 Foster via M.S. Ottone, 18/20 42041 Brescello (RE) - Italy tel. +39.0522.687425 - tel. Servizio Assistenza +39.0522.684450 fax +39.0522.686019 - fax Servizio Ricambi +39.0522.962166 e-mail: service@fosterspa.com www.fosterspa.com...
  • Page 2 The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
  • Page 5 Thank you for choosing one of our products. We hope you will get the very best performance from this appliance. Therefore we would ask you to carefully comply with the the suggestions and instructions in this manual for proper use of our products. The manufacturer shall not be held liable for damage to persons and property which is due to poor or incorrect installation of the appliance.
  • Page 6 This appliance is in compliance with the following European Directives: 93/68 : General regulations 2006/95/CE : Concerning low tensions 89/336/CEE : Electromagnetic compatibility CE Regulation n° 1935/2004 : this appliance is suitable to come in contact with food products. This manual is an integral part of the appliance. It is necessary to keep it for the life cycle of the oven and to read it carefully for the installation, use, maintenance, cleaning and handling of the appliance.
  • Page 7 Improper repair work can cause serious accidents, damage the appliance and equipment as well as impair proper operation. Appliances repaired in technical service centres must undergo routine tests, especially a continuity test of the earth circuit. THIS PRODUCT WAS DESIGNED FOR HOME USE. THE MANUFACTURER WILL NOT BE HELD LIABLE FOR DAMAGE TO PERSONS OR PROPERTY CAUSED BY IMPROPER INSTALLATION, OR BY IMPROPER, WRONG OR SENSELESS USE.
  • Page 9 After unpacking the oven, installing it in the furniture unit and removing the accessories (drip pan and racks), it is advisable to run it at the highest temperature for about 20 minutes to remove any oily residues left from the manufacturing process which may cause unpleasant odours during cooking.
  • Page 10 _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Keys for selecting temperature for cooking with pre-set functions( to increase, to decrease) Keys for selecting temperature for cooking with food probe to increase, to decrease) Keys to select time for programmed cooking...
  • Page 11 To turn the oven on, press the ON/OFF key ( ) and release it after 1 second. The display will light up and it will show the message . Do not touch any key until the language selection menu appears. Choose the desired language using the keys + - ( ) , and confirm with the Enter key ( ) or wait a few seconds and confirmation will take place automatically.
  • Page 12 First of all, select a cooking function using the selection keys ( ). The temperature can be modified using the keys ( ). You can set a cooking duration time using the keys + - ( ) to increase or decrease the desired time.
  • Page 13 Your new oven lets you memorize the programmes and cooking modes you have tried and found to be best suited to your needs. As illustrated, for each cooking mode you can change the temperature, set a duration or a time for end of cooking. These settings can be memorized and recalled any time you like.
  • Page 14 You can cook your favourite dishes using the probe. The probe is inserted in the appropriate hole inside the oven, on the wall at upper left. The temperature sensor is instead inserted in the food you are going to cook.. It must be completely inserted, if possible in the middle of the food.
  • Page 15 Use the keys ( ) to select the menu followed by Settings. The display will show a further selection menu, which includes the following: language: lets you modify the set language clock setting: includes 3 options. - possibility to show clock on display (YES/NO selection) - adjustment of time - night mode: the display is lit at low intensity from 10:00 pm until 7:00 am.
  • Page 16 It is recommended that the oven is pre-heated before introducing the food. Cooking mode suited to bake bread, pizzas and lasagne. It is recommended that the oven be pre-heated. Keep the oven door closed during this function. Suitable for very slow cooking and warming up of food. This type of cooking is specially slow and delicate.
  • Page 17 This type of cooking allows even heat distribution to all parts of the oven. It is possible to cook two different types of food (e.g. meat and fish) while using their different respective cooking times. This kind of cooking is ideal for pizza and vegetable dishes. With this function, all the heating elements and the fan work together.
  • Page 18 (from bottom) Bread and biscuits Pizza 20/30 Bread 190/200 45/60 Bread with filling 150/160 20/25 1 or 2 White bread 175/210 25/40 1 or 2 Biscuits 140/150 20/30 1 or 2 Pie and pastry Focaccia 40/45 Sponge cake 25/35 Chocolate cake 30/40 Fruit pie 50/70...
  • Page 19 Over Under Cuts of thin meat Cuts of normal meat Fish (e.g. trout, salmon) Sausages Toast Depending on the type of food (e.g. meats, fish, poultry, etc.), you will need to turn the food to expose both sides to the infrared rays. The data provided above is approximate.
  • Page 20 Before performing any maintenance, you must either unplug the oven or disconnect the power supply via the omni-polar switch of the electrical system. and clean it to keep burnt on residues from being repeatedly heated. For tough dirt, use a product specifically for oven cleaning. Follow the instructions on the container of the product.
  • Page 21 To make it easier to clean the oven, it is possible to remove the door from the hinges as follows: The hinges A are equipped with 2 mobile U-bolts B. When the U-bolts B are lifted, the hinges are disconnected from their housing. After this, lift the door up and pull it outwards, holding the door on both sides near the hinges.
  • Page 22 The side rails are to be hooked onto the wall of the oven. Slide the racks and tray provided into the side rails. To remove the side rails press on part A as shown . Disconnect the oven from the electrical power supply. Use a screwdriver to remove the light cover.
