Optoma TX783 Brochure

Dazzling and Intense
Meets Flexible and Capable
4
1 2 3
8
6 7
11
10
12 13 14 15
18 19
21
Combining high performance and brightness, the
Optoma TX783 has almost limitless install possibilities
to achieve perfect images from a distance.
Incorporating a center lens design, motorized lens
shift and power focus plus extensive connectivity and
networking, the flexible and powerful TX783 is ideal
for conference facilities and large auditoriums. The
latest BrilliantColor™ and scaling technologies plus a
DarkChip3™ DLP chipset from Texas Instruments
®
allow the Optoma TX783 to deliver powerful and vivid
images.
1 RJ45
2 HDMI
22
3 DVI-D
4 Audio-In (VGA 1)
5 VGA 1 - SCART & Component
6 +12v Trigger
7 Audio-In (DVI-D)
8 Audio-In (VGA 2)
5
9 VGA 2 - SCART & Component
10 Audio-In (BNC)
9
11 BNC (RGBHV/YPbPr)
12 USB (Remote Mouse)
13 Audio-Out
14 Audio-In (S-Video)
15 S-Video
16 17
16 Audio-In (Composite)
17 Composite Video
18 RS232 - 9 Pin
20
19 VGA Loop - Through
20 Power
21 Lamp Cover
22 Optional WIreless Module
TX783
| Multimedia Projector
2
5
6
8
11
12
14
16
17
21
1
Remote Control
3
Power
1
4
2 Laser
7
3 AV Mute
9
4 Re-Sync
5 Freeze
6 Display
10
7 Keystone
8 Zoom Control
9 Page Up/Down
10 Volume Control
11 Remote Mouse
13
12 Left Mouse Control
15
13 Right Mouse Control
14 Menu
15 Enter
18
16 Four Directional Keys
19
17 Lens Function
20
18 Format
19 Wireless
20 Source
21 Direct Input Source Selection
TX783 FEATURES
Professional installation-based DarkChip3 DLP
J
projector with XGA resolution
Stunning brightness at 5000 ANSI lumens with
J
3000/2000 hours (STD/Bright) of lamp life
J Power zoom, focus and lens shift provide
installation flexibility
Optional wireless connectivity provides both a
J
link for data and video
Powerful and convenient complete network
J
management through RJ45 connection
J Extensive connections including: HDMI, DVI
w/HDCP, two VGA-in, BNC (RGBHV)
connectors, S-Video, Composite, RS-232,
RJ45, USB mouse control, six Audio-In,
Audio-Out, VGA-Out, and a 12V Trigger
