Table of Contents
Advertisement
Usage Notice ...................................................................................................................... 2
Safety Information ........................................................................................................................2
Class B emissions limits ................................................................................................................................................................2
Important Safety Instruction ........................................................................................................................................................2
Precautions .....................................................................................................................................4
Eye Safety Warnings .....................................................................................................................6
Introduction ....................................................................................................................... 7
Product Features ...........................................................................................................................7
Package Overview ........................................................................................................................8
Product Overview .........................................................................................................................9
Main Unit ........................................................................................................................................................................................9
Control Panel ................................................................................................................................................................................10
Rear View ......................................................................................................................................................................................11
Remote Control ............................................................................................................................................................................12
Installation ........................................................................................................................ 13
Connecting the Projector ............................................................................................................13
Connect to Computer / Notebook ............................................................................................................................................13
Connect to Video Sources ...........................................................................................................................................................14
Installing or Removing the Optional Lens ..............................................................................15
Removing the Existing Lens From the Projector .....................................................................................................................15
Installing the New Lens ..............................................................................................................................................................16
Powering On/Off the Projector ................................................................................................17
Powering On the Projector .........................................................................................................................................................17
See Security Setting on page 43 if security lock is enabled. ..................................................................................................18
Powering Off the Projector .........................................................................................................................................................19
Warning Indicator........................................................................................................................................................................19
Adjusting the Projected Image ..................................................................................................20
Adjusting the Projector's Height ...............................................................................................................................................20
Adjusting Projected Image Position Using PureShift ............................................................20
Adjusting the vertical image position .......................................................................................................................................21
Adjusting the horizontal image position ..................................................................................................................................22
PureShift Range Diagram ...........................................................................................................................................................22
Adjusting the Zoom / Focus ......................................................................................................................................................23
Adjusting Projection Image Size (XGA) ...................................................................................................................................24
Adjusting Projection Image Size (WXGA) ...............................................................................................................................25
User Controls ................................................................................................................... 26
Control Panel ...............................................................................................................................26
Remote Control ...........................................................................................................................27
On-screen Display Menus ..........................................................................................................29
How to operate .............................................................................................................................................................................29
Menu Tree .....................................................................................................................................................................................30
Image ............................................................................................................................................31
Display ..........................................................................................................................................37
Setup .............................................................................................................................................39
Options .........................................................................................................................................50
LAN_RJ45 .....................................................................................................................................55
Appendices ...................................................................................................................... 58
Troubleshooting/Help On-screen Display Menu ..................................................................58
Image Problems............................................................................................................................................................................58
Intermission Problems ................................................................................................................................................................63
HDMI Q & A ................................................................................................................................................................................64
Projector Status Indication..........................................................................................................................................................65
LED Error Code Messages ..........................................................................................................................................................66
Remote Control Problems ..........................................................................................................................................................67
Audio Problems ...........................................................................................................................................................................68
Replacing the Lamp .....................................................................................................................................................................69
Cleaning the Projector ................................................................................................................71
Cleaning the Lens ........................................................................................................................71
Cleaning the Case ........................................................................................................................................................................71
Compatibility Modes ...................................................................................................................................................................72
RS232 Commands .......................................................................................................................74
RS232 Protocol Function List .....................................................................................................75
Ceiling Installation ......................................................................................................................82
Optoma Global Offices ...............................................................................................................83
Regulation & Safety notices .......................................................................................................85
Operation conditions ..................................................................................................................86
Table of Contents
Advertisement
Table of Contents
Related Manuals for Optoma TW775
Summary of Contents for Optoma TW775
-
Page 1: Table Of Contents
Replacing the Lamp ..................................69 Cleaning the Projector ........................71 Cleaning the Lens ........................71 Cleaning the Case ..................................71 Compatibility Modes ...................................72 RS232 Commands ........................74 RS232 Protocol Function List .....................75 Ceiling Installation ........................82 Optoma Global Offices .......................83 Regulation & Safety notices .......................85 Operation conditions ........................86... -
Page 2: Usage Notice
Usage Notice Safety Information The lightning flash with arrow head within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of import operating and maintenance (servicing) instructions in the literature accompanying the appliance. - Page 3 Do not attempt to service this projector yourself. Opening or removing covers may expose you to dangerous voltages or other hazards. Please call Optoma to be referred to an authorized service center near you. 8. Do not let objects or liquids enter the projector as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock.
-
Page 4: Precautions
Usage Notice Precautions Please follow all warnings, precautions and maintenance as recommended in this user’s guide. ▀■ Warning - Do not look into the projector’s lens when the lamp is on. The bright light may damage your eyes. ▀■ Warning - To reduce the risk of fire or electric shock, do not expose this projector to rain or moisture. - Page 5 Usage Notice Turn off the product before cleaning. Use a soft cloth moistened with a mild detergent to clean the display housing. Disconnect the power plug from the AC outlet if the product is not being used for a long period of time. Do not: Block the ventilation slots and openings on the unit.
-
Page 6: Eye Safety Warnings
Usage Notice Eye Safety Warnings ▀■ Avoid staring directly into the projector’s beam of light at all times. ▀■ Minimize standing facing into the beam. Keep your back to the beam as much as possible. ▀■ Using a stick or laser pointer is recommended to avoid the need for the presenter to enter the beam. -
Page 7: Introduction
Introduction Product Features This product is a single chip 0.7” XGA and 0.65” WXGA series projector. Outstanding features include: ® Texas Instruments Single chip DLP Technology ® Computer Compatibility: Apple Macintosh, iMac, and VESA Standards: UXGA, SXGA+, SXGA, WXGA, XGA, SVGA, VGA Video Compatibility: ■... -
Page 8: Package Overview
Introduction Package Overview This projector comes with all the items shown below. Check to make sure your unit is complete. Contact your dealer immediately if anything is missing. Display Volume Enter/Help Menu Format Brightness HDMI Component Source D I V VGA-1 Video S-Video... -
Page 9: Product Overview
Introduction Product Overview Main Unit 12 13 17 16 10. Focus Front IR Receiver 11. Lens CAP Top Cover Lens Release Button 12. Power Button Vertical and Horizontal Lens 13. LED Indicators Shift Adjustment Controls 14. Input/Output Connections Control Panel 15. -
Page 10: Control Panel
Introduction Control Panel 1. Source / ◄ 2. Keystone + / ▲ 3. Re-Sync / ► 4. Menu Enter / Help (See page 58 Appendices for help function.) 6. Keystone - / ▼ English... -
Page 11: Rear View
Introduction Rear View Temp LED 12V OUT A/B Connector Lamp LED AUDIO IN L/R RCA (YPbPr) Connectors DVI-D Connector AUDIO IN L/R RCA (Video/ S-Video) Connectors VGA 2/ YPbPr Connector VIDEO Connector HDMI Connector S-VIDEO Connector USB Connector YPbPr Connectors RJ-45 Connector BNC Connectors AUDIO IN (VGA2) Connector... -
Page 12: Remote Control
Introduction Remote Control AV Mute Power On/Off Re-Sync Freeze Display Keystone Due to the Volume Page Up difference in Volume +/- applications for each Page Down country, PC/Mouse control some regions 10. Mouse Right Click may have different 11. Enter/Help accessories. -
Page 13: Installation
Installation Connecting the Projector Connect to Computer / Notebook Due to the difference in applications for each country, some regions may have different accessories. 1. Power Cord 2. VGA2 Cable 3. VGA1 Cable 4. Audio-in Cable 5. DVI-D Cable (Optional) 6. -
Page 14: Connect To Video Sources
Installation Connect to Video Sources DVD Player, Set-top Box, HDTV receiver Due to the difference in applications for each country, some regions may have different accessories. DVD Player, Set-top Box, Video Output HDTV receiver 1. Power Cord 2. Component Cable (Optional) 3. -
Page 15: Installing Or Removing The Optional Lens
Installation Installing or Removing the Optional Lens Caution • Do not shake or place excessive pressure on the projector or the lens components as the projector and lens components contain precision parts. • Before removing or installing the lens, be sure to turn off the projector, wait until the cooling fans stop, and turn off the main power switch. -
Page 16: Installing The New Lens
Installation 5. Pull out the existing lens slowly. Installing the New Lens 1. Align the notches and correctly position the electrical contact pad as Pin of IRIS shown in the picture. should be in the direction as shown in the Pin of IRIS picture. -
Page 17: Powering On/Off The Projector
Installation Powering On/Off the Projector Powering On the Projector 1. Remove the lens cover. 2. Connect the power cord to the projector. 3. Turn On the connected devices. 4. Ensure the Power LED turns amber and then press the power button to turn On the projector. -
Page 18: See Security Setting On Page 43 If Security Lock Is Enabled
Installation See Security Setting on page 43 if security lock is enabled. 5. If more than one input device is connected, press the “Source” button sequentially to switch between devices. For direct source selection, see page 28. English... -
Page 19: Powering Off The Projector
Installation Powering Off the Projector 1. Press POWER to turn off the projector lamp, a message displays on the projector’s screen. 2. Press POWER again to confirm, otherwise the message disappears after 15 seconds. 3. The cooling fans continue to operate for about 10 seconds for cooling cycle and the Power Led will turn blue. -
Page 20: Adjusting The Projected Image
Installation Adjusting the Projected Image Adjusting the Projector’s Height The projector is equipped with elevator foot for adjusting the image height. To raise the image: Use screw in foot u to rise the image to the desired height angle and fine-tune the display angle. To lower the image: Use screw in foot u to lower the image to the desired height angle and to fine-tune the display angle. -
Page 21: Adjusting The Vertical Image Position
Installation The PureShift function can be used to adjust the position of the projected image either horizontally or vertically within the range detailed below. Adjusting the vertical image position The vertical image height can be adjusted between 100% and -10% for XGA, 105% and -15% for WXGA of image height. -
Page 22: Adjusting The Horizontal Image Position
Installation Adjusting the horizontal image position With the lens in the center position the Screen Width horizontal image position can be adjusted to the left or right by up to a maximum of 5% of the image width. Note that the maximum horizontal image height adjustment can be limited by the vertical image position. -
Page 23: Adjusting The Zoom / Focus
Installation Adjusting the Zoom / Focus You may turn the zoom ring to zoom in or out. To focus the image, rotate the focus ring until the image is clear. The projector will focus at distances. See pages 24-25. Use the keystone buttons to correct image distortion. -
Page 24: Adjusting Projection Image Size (Xga)
Installation Adjusting Projection Image Size (XGA) 65.6' (20.00m) 32.0' (9.76m) 42.0' (12.80m) 26.2' (8.00m) 30.2' (9.20m) 20.2' (6.16m) 9.8' (3.00m) Width 18.4' (5.60m) 14.4' (4.40m) 8.2' (2.50m) 8.9' (2.72m) 6.6' (2.00m) 6.6' (2.00m) 4.9' (1.50m) 4.9' (1.50m) 3.3' (1.00m) 1.6' (0.50m) STD lens: offset=100% 46.1’’... -
Page 25: Adjusting Projection Image Size (Wxga)
Installation Adjusting Projection Image Size (WXGA) 65.6' (20.00m) 53.8' (16.40m) 34.4' (10.47m) 42.0' (12.80m) 28.2' (8.59m) 30.2' (9.20m) 21.7' (6.61m) 9.8' (3.00m) Width 18.4' (5.60m) 15.5' (4.72m) 8.2' (2.50m) 9.6' (2.92m) 6.6' (2.00m) 6.6' (2.00m) 4.9' (1.50m) 4.9' (1.50m) 3.3' (1.00m) 1.6' (0.50m) STD lens: offset=110% 43.0’’... -
Page 26: User Controls
User Controls Control Panel Using the Control Panel ▲/Keystone+ •Adjust the image Keystone positively. (Up arrow) •Navigates and changes settings in the OSD. ◄/Source •Press Source to select an input signal. (Left arrow) •Navigates and changes settings in the OSD. Confirm your item selection./ Press to activate Help function Enter / Help... -
Page 27: Remote Control
User Controls Remote Control Using the Remote Control Refer to the “Power On/Off the Power Projector” section on page 17. Aim the remote at the viewing screen, Laser press and hold this button to activate Display the laser pointer. Volume Momentarily turns off/on the audio AV Mute and video. - Page 28 User Controls Using the Remote Control Four Directional Use ▲▼◄► to select items or make Select Keys adjustments to your selection. Brightness Adjust the brightness of the image. Display Format Press Format to select the image ratio. Volume HDMI Press HDMI to choose HDMI source. Press Component to choose Component Component source.
-
Page 29: On-Screen Display Menus
User Controls On-screen Display Menus The Projector has multilingual On-screen Display menus that allow you to make image adjustments and change a variety of settings. The projector will automatically detect the source. How to operate 1. To open the OSD menu, press Menu on the Remote Control or Projector Keypad. -
Page 30: Menu Tree
Security Timer Month/Day/Hour/Exit Change Password Security Setting Enable/Disable Exit SETUP | Audio Mute On/Off Volume Exit SETUP | Advanced Logo Optoma/User Logo Capture Closed Captioning CC1/CC2/Off Exit OPTIONS Source Lock On/Off High Altitude On/Off Information Hide On/Off Keypad Lock On/Off... -
Page 31: Image
User Controls Image Display Mode There are many factory presets optimized for various types of images. Presentation: Good color and brightness from PC input. Bright: Maximum brightness from PC input. Movie: For home theater. sRGB: Standardised accurate color. Blackboard: Tuned for blackboard usage. Classroom: Recommended settings for classroom. -
Page 32: Color Setting
User Controls Image Saturation Adjusts a video image from black and white to full color saturation. Press ◄ to decrease the amount of saturation in the image. Press ► to increase the amount of saturation in the image. Tint Adjusts the color balance of red and green. Press ◄... - Page 33 User Controls Image | Color Setting Increase or decrease the color value for red. Green Increase or decrease the color value for green. Blue Increase or decrease the color value for blue. Cyan Increase or decrease the color value for cyan. Yellow Increase or decrease the color value for yellow.
- Page 34 User Controls Image | Color Setting / HSG Adjust the color balance of red and green. Press ◄ to increase the amount of green in the image. Press ► to increase the amount of red in the image. Saturation Adjusts a video image from black and white to full color saturation. Press ◄...
-
Page 35: Color Temp
User Controls Image | Advanced BrilliantColor This adjustable item utilizes a new color-processing algorithm and system level enhancements to enable higher brightness while providing true, more vibrant colors in picture. The range is from 0 to 10. If you prefer a stronger enhanced image, adjust toward the maximum setting. For a smoother, more natural image, adjust toward the minimum setting. -
Page 36: Input Source
User Controls Image | Advanced | Input Source Input Source Use this option to enable / disable input sources. Press ▲ or ▼ to select a source, then press ◄ or ► to enable / disable it. Press Enter to finalize If all sources the selection. -
Page 37: Display
User Controls Display Format Use this function to choose your desired aspect ratio. 4:3: This format is for 4x3 input sources not enhanced for Wide screen TV. 16:9 I (XGA) | 16:9 (WXGA): This format is for 16x9 input sources, like HDTV and DVD enhanced for Wide screen TV. -
Page 38: Image Shift
User Controls Display Overscan Overscan function removes the noise in a video image. Overscan the image to remove video encoding noise on the edge of video source. Zoom Press ◄ to reduce the size of the image. Press ► to magnify an image on the projected screen. H Image Shift Shifts the projected image position horizontally. -
Page 39: Setup
User Controls Setup Language Enter the Language menu. Select the multilingual OSD menu. See page 41 for more information. Projection Select projection method: Front Desktop The factory default setting. Rear Desktop When you select this function, the projector reverses the image so you can project from behind a translucent screen. - Page 40 User Controls Setup Signal Enter the Signal menu. Set projector signal properties. See page 42 for more information. Security Enter the Security menu. Access the projector’s security features. See page 43 for more information. Projector ID Select a two digit projector ID from 0 through 99. Audio Enter the Audio menu.
- Page 41 User Controls Setup | Language Language Choose the multilingual OSD menu. Press ENTER ( ) into the sub menu and then use the Left (◄) or Right (►) key to select your preferred language. English...
- Page 42 User Controls Setup | Signal Frequency Change the display data frequency to match the frequency of your computer’s graphics card. If you experience a vertical flickering bar, use this function to make an adjustment. Phase Phase synchronizes the signal timing of the display with the graphics card.
-
Page 43: Security Timer
User Controls Setup | Security Security Timer Enter the Security Timer sub menu. No password is required to Enter the Months, Days, and hours that the projector can be used without access Setup entering the password. Exiting to the Setup menu activates the Security | Security Timer. -
Page 44: Change Password
User Controls Setup | Security Change Password If the incorrect Use this submenu to change the security password for the projector. password is 1. Select Change Password from the Security submenu. The Confirm entered three Change Password dialog box displays. times, the 2. -
Page 45: Security Setting
User Controls Setup | Security Security Setting Enable or disable the security password. Enabled—the current password is required to power on the projector and access the Security menu. Disabled—no password is required for any function. When security is enabled, the following screen displays at startup and before access to the Security menu is allowed: English... - Page 46 User Controls Setup | Audio Volume Press ◄ to decrease the volume of voice. Press ► to increase the volume of voice. Mute Toggle the audio on or off. Off—the speaker volume is turned on. On–the speaker volume is turned off. English...
-
Page 47: Logo Capture
User Controls Setup | Advanced Logo Select the screen to display during startup. Optoma—the supplied default startup screen. User—customized screen capture using the Logo Capture function. Logo Capture Capture a displayed screen to use as the startup screen. 1. Display the desired screen on the projector. - Page 48 User Controls Setup | RS232 RS232 Press Enter to enter the RS232 sub menu and use the Left (◄) or Right (►) key to select your preferred RS232 control. When selecting Network, a message displays as below: English...
- Page 49 User Controls Setup | Network Network Press Enter to apply Network settings. If the connection is successful, the OSD display will show the following dialogue box. Network State—to display network information. DHCP: On: Assign an IP address to the projector from the DHCP server automatically.
-
Page 50: Options
User Controls Options Source Lock Lock the current source as the only available source, even if the cable is unplugged. On—only the current source is recognized as an input source. Off—all sources selected in Image | Advanced | Input Source are recognized as an input source. -
Page 51: Background Color
User Controls Options Background Color Select the desired background color for the projected image when no source is detected. Advanced Enter the Advanced menu. See page 52 for more details. Lamp Setting Enter the Lamp Setting menu. See pages 53-54 for more details. Reset Reset all Options to default factory settings. -
Page 52: Direct Power On
User Controls Options | Advanced Direct Power On Enable or disable Direct Power On. On—the projector powers on automatically when AC power is supplied. Off— the projector must be powered on as normal. Auto Power Off Set the Auto Power Off interval. The projector powers off the lamp after 30 minutes of no signal by default. -
Page 53: Lamp Hour
User Controls Options | Lamp Setting Lamp Hour Displays the number of hours the lamp has been active. This item is for display only. Lamp Reminder Enable or disable the lamp life span reminder. On—a warning message displays when remaining lamp life is less than 30 hours. - Page 54 User Controls Options | Lamp Setting Lamp Reset After replacing the lamp, reset the lamp counter to accurately reflect the new lamp’s life span. 1. Select Lamp Reset. A confirmation screen displays. 2. Select Yes to reset the lamp counter to zero. English...
-
Page 55: Lan_Rj45
User Controls LAN_RJ45 For simplicity and ease of operation, the Optoma projector provides di- verse networking and remote management features. The LAN/RJ45 function of the projector through a network, such as re- motely manage: Power On/Off, Brightness and Contrast settings. Also, Projector projector status information, such as: Video-Source, Sound-Mute, etc. - Page 56 User Controls 3. Right Click on your Local Area Connection, and select Property. 4. In the Properties window, select the General tab, and select Internet Protocol (TCP/IP). 5. Click Properties. 6. Fill in the IP address and Subnet mask, then press OK. English...
- Page 57 User Controls 7. Press the Menu button on the projector. 8. Select OSD-> SETUP-> Network-> Enabled. 9. Input the following: IP Address: 10.10.10.10 Subnet Mask: 255.255.255.0 Gateway: 0.0.0.0 DNS: 0.0.0.0 10. Press Apply (Enter) to confirm settings. 11. Open a web browser (ex, Microsoft Internet Explorer with Adobe Flash Player 9.0 or higher).
-
Page 58: Appendices
Appendices Troubleshooting/ Help On-screen Display Menu If you experience a problem with your projector, please refer to the following information. If a problem persists, please contact your local reseller or service center. Image Problems No image appears on-screen Ensure all the cables and power connections are correctly and securely connected as described in the Installation section. - Page 59 Appendices Check if the projection lamp has been securely installed. Please refer to the Replacing the lamp section. Make sure you have removed the lens cap and the projector is switched on. Partial, scrolling or incorrectly displayed image Press “Re-Sync” on the remote. If you are using a PC: For Windows 95, 98, 2000, XP: 1.
- Page 60 Appendices If you are using a Notebook: 1. First, follow the steps above to adjust resolution of the computer. 2. Press the toggle output settings. Example: [Fn]+[F4] Acer � [Fn]+[F5] IBM/Lenovo � [Fn]+[F7] [Fn]+[F4] Asus � [Fn]+[F8] HP/Compaq � Dell � [Fn]+[F8] NEC �...
-
Page 61: Image Is Unstable Or Flickering
Appendices The screen of the Notebook or PowerBook computer is not displaying your presentation If you are using a Notebook: Some Notebooks may deactivate their own screens when a second display device is in use. Each has a different way to be reactivated. -
Page 62: Image Has Vertical Flickering Bar
Appendices Image has vertical flickering bar Use Frequency to make an adjustment. See page 42 for more information. Check and reconfigure the display mode of your graphic card to make it compatible with the projector. Image is out of focus Make sure the lens cap is removed. -
Page 63: Intermission Problems
Appendices Image has slanted sides If possible, reposition the projector so that it is centered on the screen and below the bottom of the screen. Press [Keystone +/-] on the remote control until the sides are vertical. Image is reversed Select Setup | Projection from the OSD and adjust the projection direction. -
Page 64: Hdmi Q & A
Appendices HDMI Q & A What is the difference between a “Standard” HDMI cable and a “High-Speed” HDMI cable? Recently, HDMI Licensing, LLC announced that cables would be tested as Standard or High-Speed cables. Standard (or “category 1”) HDMI cables have been tested to perform at speeds of 75Mhz or up to 2.25Gbps, which is the equivalent of a 720p/1080i signal. -
Page 65: Projector Status Indication
Appendices Projector Status Indication Power LED Power LED Temp LED Lamp LED Message (Blue) (Amber) (Red) (Red) Standby State (Input power cord) Standby State Flashing (Burn in Mode) Power on with OSD (Press power button) Power on without Over Temperature Flashing Fan Fail Lamp error... -
Page 66: Led Error Code Messages
Appendices LED Error Code Messages Power LED Lamp LED Error Code Message (Blink) (Blink) T1 temperature over temperature Thermal Break G794 fail T1 fail Lamp error Ballast Over Temperature Ballast shot circuit in output detected End of lamp lift detected Ballast lamp did not ignite Lamp extinguished during normal opera- tion... -
Page 67: Remote Control Problems
Appendices Message Reminders Replacing the lamp: Out of range: (see the following for more information) Remote Control Problems If the remote control does not work Check the operating angle for the remote control is approximately ±15°. Make sure there are no obstructions between the remote control and the projector. -
Page 68: Audio Problems
Appendices Audio Problems There is no sound Adjust the volume on the remote control. Adjust the volume of the audio source. Check the audio cable connection. Test the source audio output with other speakers. Have the projector serviced. The sound is distorted Check the audio cable connection. -
Page 69: Replacing The Lamp
Appendices Replacing the Lamp The projection lamp should be replaced when it burns out. It should only be replaced with a certified replacement part, which you can order from your local dealer. Important: The lamp contains a certain amount of mercury and should be disposed of according to local ordinance regulations. - Page 70 Appendices 1. Switch off the power to the projector by pressing the Power button. 2. Allow the projector to cool down at least 30 minutes. 3. Disconnect the power cord. 4. Unlock the lamp cover. 5. Pull up and remove the cover. 6.
-
Page 71: Cleaning The Projector
Appendices Cleaning the Projector Cleaning the projector to remove dust and grime will help ensure trouble-free operation. Warning: Be sure to turn off and unplug the projector at least an hour before cleaning. Failure to do so could result in a severe burn. Use only a dampened cloth when cleaning. -
Page 72: Compatibility Modes
Appendices Compatibility Modes Computer Compatibility Signal Resolution Refresh Rate (Hz) NTSC PAL/SECAM VESA 640 x 350 70.1/ 85.1 640 x 400 70.1 / 85.1 720 x 350 720 x 400 70/ 85 720 x 576 50/ 60 640 x 480 60/ 67/ 72.8/ 75/ 85 SVGA 800 x 600... - Page 73 Appendices Signal Resolution Refresh Rate (Hz) 720 x 480i 720 x 480p Apple Mac Compatibility Macbook Pro Power Mac Power Mac Resolution Macbook (Intel) Analog Analog Analog Analog 800x600 800x600 800x600 800x600 1024x768 1024x768 1024x768 For wide screen 1024x768 resolution 1280x720 (WXGA), the 1280x720...
-
Page 74: Rs232 Commands
Appendices RS232 Commands RS232 Connector Pin No Specification English... -
Page 75: Rs232 Protocol Function List
None UART16550 FIFO Disable Lead Code Projector ID Command ID space variable carriage return Set in OSD Defined by Optoma Fix code 00~99 Per item Fix code 2 or 3 Digit One Digit One Digit Two Digit Definition One Digit... - Page 76 Appendices Function ASCII Pass Fail Saturation n= -50 - +50 ~XX45 n Tint n= -50 - +50 ~XX44 n TM 1 BrilliantColor n= 0 - 10 ~XX34 n Film ~XX35 n Video Degamma Graphics Warm ~XX36 n Color Temp. Medium Cold n=-50 ~ 50 ~XX170 n...
- Page 77 Appendices OSD/Display Function ASCII Pass Fail ~XX60 n 16:9 I/16:9 Format 16:9 II / 16:10 Native Auto Overscan n=0-10 ~XX61 n Zoom n= -30 - +100 ~XX62 n H Image Shift n= -50 - +50 ~XX63 n V Image Shift (16:9) n= -24 - +24 ~XX64 n V Keystone...
- Page 78 Optoma). The poll is "AMX" in ASCII followed by a carriage return '\r'. On recognition of the poll, the Optoma projector will respond with a beacon string (in ASCII) identifying your device. The AMX controller (Branded NetLinx) can then download the interface from the amx website to control your device. An example beacon string for Optoma could be: AMXB<-SDKClass=VideoProjector><-Make=Optoma><-Model=EX???><-Revision=1.0.0>...
- Page 79 Appendices Information Format: INFOa Status Code Definition Standby Mode Warming up Cooling Down Out of Range Lamp Fail Thermal Switch Error Fan Lock Over Temperature Lamp Hour Running Out Information display: Function ASCII Display Format Fail Information ~XX150 n Okabbbbccdddde Format Definition Code Definition a = Power State...
- Page 80 Appendices Status Code Definition None HDMI DVI-D VGA 1 VGA 2 Component RCA S-Video Video Software Version Function ACCII Display Fail Software Version ~XX122 n Okdddd Display Mode Function ACCII Display Fail Display Mode ~XX123 n Status Code Definition Presentation Bright Movie sRGB...
- Page 81 Appendices Color Temperature Function ASCII Display Fail Color Temperature ~XX128 n Status Code Definition Warm Medium Cold Projection Mode Function ASCII Display Fail Projection Mode ~XX129 n Status Code Definition Front-Desktop Rear-Desktop Front-Ceiling Rear-Ceiling Remote control Customer code : 0x32CD Item Key Definition ASCII...
-
Page 82: Ceiling Installation
Appendices Ceiling Installation To prevent damage to your projector please use the recommended mounting package for installation. To ensure compliance, only use a UL Listed ceiling mount and Damage to the screws that meet the following specifications: projector as a Screw Type: M4 result of incorrect... -
Page 83: Optoma Global Offices
Appendices Optoma Global Offices For service or support please contact your local office. 715 Sycamore Drive Milpitas, CA 95035, USA Tel : 408-383-3700 Fax : 408-383-3702 www.optomausa.com Service : services@optoma.com Canada 5630 Kennedy Road, Mississauga, ON, L4Z 2A9, Canada Tel : 905-361-2582 Fax : 905-361-2581 www.optoma.ca... - Page 84 Appendices Scandinavia Optoma Scandinavia AS Lerpeveien 25 3040 Drammen Norway PO.BOX 9515 3038 Drammen Norway Tel : +4732988990 Fax : +4732988999 Service : info@optoma.no Latin America 715 Sycamore Drive Milpitas, CA 95035, USA Tel : 408-383-3700 Fax : 408-383-3702 www.optoma.com.br www.optoma.com.mx...
-
Page 85: Regulation & Safety Notices
Appendices Regulation & Safety notices This appendix lists the general notices of your projector. FCC notice This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 86: Operation Conditions
Appendices Operation conditions This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Notice: Canadian users This Class B digital apparatus complies with Canadian ICES-003.
