Please keep this
instructions sheet for
future reference, as it
contains important
information.
Adult assembly is required.
Tool required for assembly:
Philips screwdriver (not included)
For children 6 to 36 months
and up to 44 lbs (20 kg).
www.fi sher-price.com
www.fi sher-price.com
V7597
V7597

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V7597 and is the answer not in the manual?

Questions and answers

Summary of Contents for Fisher-Price V7597

  • Page 1 V7597 V7597 Please keep this instructions sheet for future reference, as it contains important information. Adult assembly is required. Tool required for assembly: Philips screwdriver (not included) For children 6 to 36 months and up to 44 lbs (20 kg). www.fi...
  • Page 2: Consumer Information

    Consumer Information WARNING Falls onto hard surfaces could result in head or other serious injuries. • Never place over concrete, asphalt, wood or other hard surfaces. • Always use the restraint system. • Never leave child unattended. • Do not allow use of this swing until it has been properly installed by an adult, according to these instructions.
  • Page 3 Assembly Canopy Stay • Slide the canopy stay through the canopy sleeve. Bracket • Fit an end of the canopy stay into the socket in a bracket. Hint: The long end of the canopy should face the front of the swing.
  • Page 4: Inside View

    Assembly INSIDE VIEW • Insert a #8 x 1¼" (3,2 cm) screw into the canopy bracket and tighten with a Phillips screwdriver. Do not over-tighten. • Repeat steps 2 and 3 to assemble the other end of the canopy stay to the other bracket.
  • Page 5 Placement and Play Area Surfacing Before installing the swing, select and prepare a play area. Placement Install the swing at least three feet (1 m) from any structure or obstruction such as a tree trunk, fence, garage, house, overhanging branches, laundry lines or electrical lines.
  • Page 6: Consumer Assistance

    CONSUMER ASSISTANCE 1-800-432-5437 (US & Canada) 1300 135 312 (Australia) Fisher-Price, Inc., 636 Girard Avenue, East Aurora, NY 14052. Hearing-impaired consumers: 1-800-382-7470. Outside the United States: Canada: Mattel Canada Inc., 6155 Freemont Blvd., Mississauga, Ontario L5R 3W2;...
  • Page 7 Swing Set Installation IMPORTANT! When installing this swing, be sure it cannot swing to within three feet (1 m) of any other object in front of, behind, or to the side of it. CAUTION Periodically inspect S-hooks for wear. Metal to metal contact between hooks may cause premature wear.
  • Page 8: Front View

    Pole or Tree Branch Installation IMPORTANT! Before installing, check the strength and stability of the pole or tree branch. Place the swing at least three feet (1 m) from a tree trunk or any other structure. Ropes S-Hook • Wrap the S-hook end of the swing ropes around the pole or tree branch. •...
  • Page 9 Recline for Infant Push Push Squeeze Squeeze Squeeze Squeeze Upper Upper Upper Upper Groove Groove Groove Groove SIDE VIEW BACK VIEW • From the back of the swing, grasp the top edge of the swing. Squeeze the tabs and push the top edge of the swing down. •...
  • Page 10: Securing Your Child

    Securing Your Child Tray Tab Waist Belt Tray Tab Crotch Belt • Locate the tray tabs under the armrests of the swing. • Pull the tray tabs out and lift the tray slightly. • Rotate the tray out of the way. •...
  • Page 11 Securing Your Child Anchored End Anchored End Buckle Free End Free End TIGHTEN TIGHTEN LOOSEN LOOSEN To tighten the waist belts: • Feed the anchored end of the waist belt up through the buckle to form a loop . Pull the free end of the waist belt •...
  • Page 12 Removing Your Child Tray Tray • Locate the tray tabs under the armrests of the swing. • Pull the tray tabs out and lift the tray slightly. • Rotate the tray out of the way. • Squeeze tabs on the waist restraint buckles to unfasten the restraint system.
