- Page 1 V4873 V4873 IMPORTANT! KEEP FOR FUTURE REFERENCE. www.fi sher-price.co.uk www.fi sher-price.co.uk...
-
Page 2: Consumer Information
Consumer Information Parts IMPORTANT! Please remove all parts from the package and identify them before assembly. Some parts may be packed in the pad. WARNING To prevent serious injury or death from falls and being strangled in the restraint system: •... - Page 3 IMPORTANT! Before assembly and each use, inspect this product for damaged hardware, loose joints, missing parts or sharp edges. DO NOT Base Tube use if any parts are missing or broken. Contact Fisher-Price ® replacement parts and instructions if needed. Never substitute parts.
- Page 4 Assembly 2 Screws 2 Screws • Insert a screw into the hole in each swing housing. Tighten the screws. • Insert a screw into the hole in each seat hub. Tighten the screws. Seat Frame • Fit the end of each swing arm into the sockets on the seat hubs, as shown.
- Page 5 Assembly Upper Slots Upper Slots Slot Slot Slot Slot Shoulder Belts Waist Belts • Insert the waist belts into the lowest slots in the seat pad. Make sure the belts are not twisted. Waist Belt Lower Slots Lower Slots Larger Baby •...
-
Page 6: Battery Installation
Battery Installation WARNING To prevent serious injury or death from falls and being strangled in the Battery Compartment Door restraint system: • Always use the restraint system. • Not recommended for children who can sit up by themselves (6 months approximately, until 9 Kg/20 lbs). -
Page 7: Securing Your Child
Securing Your Child TIGHTEN LOOSEN Free End Free End Waist/ Shoulder Restraint Belts Anchored End Anchored End • To tighten the waist belts: Feed the anchored end of the belt up through the buckle to form a loop A. Pull the free end of the belt B. Repeat this procedure to tighten the other belt. - Page 8 Swinging and Music Storage PRESS PRESS PRESS PRESS • While pushing both recline buttons, fold the seat. Swing Power/ Music/Sound Sound Power/ Speed Switch Selection Switch Volume Switch PRESS PRESS • Place your child in the seat and secure properly. •...
