NC7SB3257
TinyLogic
UHS
2:1 Multiplexer/Demultiplexer Bus Switch

General Description

The NC7SB3257 is a high performance, 2:1 NMOS pass-
gate multiplexer/demultiplexer from Fairchild's Ultra High
Speed Series of TinyLogic . The device is fabricated with
advanced sub-micron CMOS technology to achieve high
speed enable and disable times and low On Resistance.
The device is specified to operate over the 4.0 to 5.5V V
operating range. The control input tolerates voltages up to
5.5V independent of the V
operating range.
CC
Ordering Code:
Order
Package
Number
Number
NC7SB3257P6X
MAA06A
NC7SB3257L6X
MAC06A
TinyLogic
and MicroPak
are trademarks of Fairchild Semiconductor Corporation.
© 2002 Fairchild Semiconductor Corporation
Features
CC
Product Code
Package Description
Top Mark
B7B
6-Lead SC70, EIAJ SC88, 1.25mm Wide
B7
6-Lead MicroPak, 1.0mm Wide
DS500325
January 2000
Revised April 2002
Space saving SC70 6-lead surface mount package
Ultra small MicroPak
leadless package
Typical 3 switch resistance @ 5.0V V
Minimal propagation delay through the switch
Power down high impedance control input
Zero bounce in flow through mode
TTL compatible control input
Overvoltage tolerance of control input to 7.0V
Break before make enable circuitry
3k Units on Tape and Reel
5k Units on Tape and Reel
CC
Supplied As
www.fairchildsemi.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NC7SB3257 TinyLogic and is the answer not in the manual?

Questions and answers

Related Manuals for Fairchild NC7SB3257 TinyLogic

Summary of Contents for Fairchild NC7SB3257 TinyLogic

  • Page 1: General Description

    General Description Features The NC7SB3257 is a high performance, 2:1 NMOS pass- Space saving SC70 6-lead surface mount package gate multiplexer/demultiplexer from Fairchild’s Ultra High Ultra small MicroPak leadless package Speed Series of TinyLogic . The device is fabricated with Typical 3 switch resistance @ 5.0V V...
