FSA266 • NC7WB66
Low Voltage Dual SPST
Normally Open Analog Switch or 2-Bit Bus Switch

General Description

The FSA266 or NC7WB66 is an ultra high-speed (UHS) dual
single-pole/single-throw (SPST) analog switch or 2-bit bus
switch. The device is fabricated with advanced sub-micron
CMOS technology to achieve high speed enable and disable
times and low On Resistance over a broad V
device is specified to operate over the 1.65 to 5.5V V
ing range. The device is organized as a dual switch with inde-
pendent CMOS compatible switch enable (OE) controls. When
OE is HIGH, the switch is ON and Port A is connected to Port B.
When OE is LOW, the switch is OPEN and a high-impedance
state exists between the two ports. The enable inputs tolerate
voltages up to 5.5V independent of the V
Ordering Code:
Order Package
Number Number Top Mark
FSA266K8X MAB08A
FSA266L8X MAC08A
NC7WB66K8X MAB08A
NC7WB66L8X MAC08A
Pb-Free package per JEDEC J-STD-020B.
MicroPak is a trademark of Fairchild Semiconductor Corporation.
© 2005 Fairchild Semiconductor Corporation
range. The
CC
operat-
CC
operating range.
CC
Product
Code Package Description
WB66 8-Lead US8, JEDEC MO-187, Variation CA 3.1mm Wide 3K Units on Tape and Reel
P4 Pb-Free 8-Lead MicroPak, 1.6 mm Wide
WB66 8-Lead US8, JEDEC MO-187, Variation CA 3.1mm Wide 3K Units on Tape and Reel
P4 Pb-Free 8-Lead MicroPak, 1.6 mm Wide
DS500373
Features
Useful in both analog and digital applications
Space saving US8 surface mount package
MicroPak Pb-Free leadless package
:
Typical 7 On Resistance @ 5V V
Broad V operating range: 1.65V to 5.5V
CC
Rail-to-Rail signal handling
Power down high impedance control inputs
Control inputs are overvoltage tolerant
Control inputs are CMOS compatible
!
300 MHz 3dB bandwidth
May 2000
Revised December 2005
CC
Supplied As
5K Units on Tape and Reel
5K Units on Tape and Reel
