Fairchild FSA3357 Specification Sheet

FSA3357
Low Voltage SP3T Analog Switch
(3:1 Multiplexer/Demultiplexer)

General Description

The FSA3357 is a high performance, single-pole/triple-throw
(SP3T) Analog Switch or 3:1 Multiplexer/Demultiplexer. The
device is fabricated with advanced sub-micron CMOS technol-
ogy to achieve high speed enable and disable times and low On
Resistance. The break before make select circuitry prevents
disruption of signals on the B
switches temporarily being enabled during select pin switching.
The device is specified to operate over the 1.65 to 5.5V V
operating range. The control input tolerates voltages up to 5.5V
independent of the V operating range.
CC
Ordering Code:
Product
Order Package
Number Number
FSA3357K8X MAB08A
FSA3357L8X MAC08A
Pb-Free package per JEDEC J-STD-020B.
MicroPak is a trademark of Fairchild Semiconductor Corporation.
© 2005 Fairchild Semiconductor Corporation
, B , or B Ports due to the
0 1 2
CC
Code
Top Mark
A357 8-Lead US8, JEDEC MO-187, Variation CA 3.1mm Wide 3k Units on Tape and Reel
FE Pb-Free 8-Lead MicroPak, 1.6 mm Wide
Features
Useful in both analog and digital applications
Space saving US8 8-lead surface mount package
Low On Resistance;
Broad V operating range; 1.65V to 5.5V
CC
Rail-to-Rail signal handling
Power down high impedance control input
Overvoltage tolerance of control input to 7.0V
Break before make enable circuitry
250 MHz - 3dB bandwidth
Space saving Pb-Free MicroPak
Applications
Cell Phone
PDA
Video
Package Description
DS500805
December 2002
Revised August 2005
:
9 on typ @ 3.3V V
CC
¥
packaging
Supplied As
5k Units on Tape and Reel
www.fairchildsemi.com
