  • Page 1 L O U D S P E A K E R S M U S I C A L o w n e r s PRINTED IN CANADA 7AIEAP552 T R U T H A u d i s s e y A P S - 5 + 2 m a n u a l ®...

  • Page 2: Important Safety Instructions

    A u d i s s e y A P S 5 + 2 IMPORTANT SAFETY INSTRUCTIONS • Read Instructions - All safety and operating instructions should be read before the product is operated. • Retain Instructions - The safety and operating instructions should be retained for future reference.
  • Page 3 o w n e r s m a n u a l • Power Cord Protection - Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.

  • Page 4: Table Of Contents

    A u d i s s e y A P S 5 + 2 TABLE OF CONTENTS FEATURES AND BENEFITS ......... . 4 ROOM ACOUSTICS AND SPEAKER PLACEMENT .

  • Page 5: Features And Benefits

    Low Level RCA Input Jack The RCA Input jack allows you to connect the subwoofer section of the APS 5+2 to EITHER: The subwoofer mono output of an A/V Receiver/Processor or The output of a Pre-Amp or A/V Processor when used with an external power amplifier.

  • Page 6: Room Acoustics And Speaker Placement

    7. Spiked feet are recommended for stability on carpeted floors. 8. The APS 5+2 pair should be placed 6 to 10 feet (2-3 m) apart.The distance from the loudspeakers to the listener should be about 1 to 1.5 times the distance separating the speakers.

  • Page 7: Speaker Placement

    Note: The ENERGY APS 5+2 impedance is 6 ohms nominal (4 ohm minimum) and will function well with most amplifiers sold today. If you are connecting two speakers to the same channel of an amplifier/receiver, check with the amplifier manufacturer to ensure that it can handle minimum impedance of 2 ohms.

  • Page 8: Setting Up Your Energy Speakers

    We, therefore, recommend using the “Speaker Level” connection method for best performance. (See Figure 2,3 or 4) The APS 5+2 utilizes two sets of binding posts.The upper set is for high frequencies and the lower set for mid and low frequencies. Bi-amp/bi-wire allows three different wiring options.
  • Page 9 o w n e r s m a n u a l A u d i s s e y A P S 5 + 2...
  • Page 10 A u d i s s e y A P S 5 + 2 o w n e r s m a n u a l...

  • Page 11: Level Control

    Y Connector splits the mono subwoofer output signal into two outputs. One is fed to the left APS 5+2 RCA input and the other is fed to the right APS 5+2 RCA input.The above connection would normally be made with long RCA interconnect cables, one for each speaker Make sure the subwoofer input selector switch is in the upper (180°) or lower (0°) position.
  • Page 12 A u d i s s e y A P S 5 + 2 CONNECTION METHOD USING THE “SUBWOOFER” OUTPUT AUDIO/VIDEO RECEIVER o w n e r s m a n u a l (FIGURE 5) NOTE: ENSURE THAT ONE GOLDE SHORTING BAR IS CONNECTED AS SHOWN BETWEEN THE TWO RED INPUT TERMINALS AND...

  • Page 13: Pre-Amp Or A/V Processor

    o w n e r s m a n u a l CONNECTION METHOD USING “PRE-AMP OR A/V PROCESSOR” RCA INTERCONNECT FROM OUTPUT OF AV PROCESSOR OR PRE AMP TO RCA INPUT PRE AMP OR AV PROCESSOR NOTE: REPEAT CONNECTIONS FOR EACH ADDITIONAL CHANNEL (FIGURE 6) “Y”...

  • Page 14: Care Of Finish

    A u d i s s e y A P S 5 + 2 o w n e r s m a n u a l Care of Finish Your ENERGY speakers are attractively finished and should be gently wiped clean, from time to time, with a damp cloth to remove any dust or stains.

  • Page 15: Specifications

    o w n e r s m a n u a l SPECIFICATIONS System Type Tweeters: Mid Range Drivers: Woofers: System Frequency Response: 20Hz-22KHz Sensitivity: Impedance: Recommended Amplifier: Crossover Frequencies: Internal Subwoofer Amplifier Type: Power Output: Low Frequency Equalization: Continuously variable from –3dB @ 20Hz to Inputs: Dimensions: (HxWxD)

  • Page 16: Limited Warranty Policy

    A u d i s s e y A P S 5 + 2 o w n e r s m a n u a l LIMITED WARRANTY POLICY Warranty in the United States and Canada ENERGY warrants this product to the retail purchaser against any failure resulting from original manufacturing defects in workmanship or materials.The warranty is in effect for a period of: Speaker Section - five (5) years , Amplifier Section one (1) year from date of purchase from an authorized ENERGY dealer and is valid only if the original dated bill of...

  • Page 17: Warning

    o w n e r s m a n u a l A u d i s s e y A P S 5 + 2 WARNING IMPORTANT TECHNICAL NOTE PLEASE READ BEFORE OPERATING SPEAKERS THE WARRANTY ON SPEAKERS IS VOID IF THE VOICE COILS ARE BURNED OR DAMAGED AS A RESULT OF OVERPOWERING OR CLIPPING.
