4 Navigating the Software

HP System Management Homepage
The
Software
that provides information. In addition, HP SMH displays various categories (in boxes) that have
icons defining the status of the items.
The HP SMH main page is divided into two major areas: the header and the standard container.
Header Frame
contains the following four subareas:
Master header. In Windows and Linux, the links show the path you are viewing, the user, and a
Sign Out link.
Menu. Each item is a direct link to a page or section including:
Main title area. The area under the master header and menu contains the following items.
The header frame is constantly visible regardless of the page you are viewing and
Home
Settings
Tasks
Tools
Logs
Webapps (Windows and Linux only)
Support
Help
Title. The title of the section of page you are viewing.
Host Name. The name of the system.
System Model. The model appears as Unknown if the HP Insight Management Agent for
servers is not installed on the system.
Management Processor.
Icons. An option that enables you to switch between icon and list view modes when clicked.
Data Source Indicates which source is populating management data. For instance, WBEM
for HP Insight Management WBEM Providers or SNMP for HP Insight Management Agents.
If no source is installed, no data string will appear.
Bread crumbs. The area under the main title that is divided into four parts.
First level menu item
Legend. A link that, when clicked, displays a floating box listing all possible statuses
of webapps.
Refresh. A link that reloads the header and information areas.
Time. Displays the time the page was loaded. When you mouse over the time area,
you can see the date the page was loaded.
HP Web-enabled System Management
(HP SMH) displays all
The name of the management processor.
25
