Figure 4-14 Transmit Load Balancing Method Configuration
Table 4-8 Transmit Load Balancing method comparison
Preserves Frame
Transmission Order
Automatic
TCP Connection
Destination IP
address
Destination MAC
address
Round Robin

TLB Automatic Method

Automatic is a load-balancing method that is designed to preserve frame ordering.
This method will load balance outbound traffic based on the highest layer of information in the
frame. For instance, if a frame has a TCP header with TCP port values, the frame will be load
balancing by TCP connection (refer to
an IP header with an IP address but no TCP header, then the frame is load balanced by destination
IP address (refer to "TLB Destination IP Address Method"
IP header, the frame is load balanced by destination MAC address (refer to
MAC Address Method"
Automatic is the HP-recommended setting for outbound load balancing. Although in the current
product Automatic mode is identical to TCP Connection mode, future releases may augment
Load Balances
through Router
√
√
√
√
"TLB TCP Connection Method"
below).
Guarantees Equal
Load Balancing
√
√
√
√
below). If the frame doesn't have an
Types of HP Integrity Network Adapter Teams
HP Recommendation
√
below). If the frame has
"TLB Destination
