Door Alarm
The Door Alarm feature sounds a chime every few seconds when
the refrigerator door has been left open for 5 continuous minutes.
The chime will sound until the door is closed or Door Alarm is
turned off.
Press the Door Alarm touch pad to turn this feature on or off.
The indicator light will be lit when the Door Alarm feature is on.
®
®
DOOR ALARM
Filter Reset
The Filter Reset control allows you to restart the water filter status
tracking feature each time you replace your water filter. See
"Water Filtration System."
Press and hold the Filter Reset touch pad for 3 seconds, until
the Order or Replace light turns off.
ORDE@EPLACE
FILTER RESET
_RESSA_DHOLD
User Preferences
The control center allows you to set user preferences, if desired.
Temperature
Display
(F_C)
This preference allows you to change the temperature display.
F - Temperature in degrees Fahrenheit
C - Temperature in degrees Celsius
Alarm (AL)
This preference allows you to turn off the sound of all alarms.
ON - You will hear the alarm sound.
OFF - You will not hear the alarm sound.
Auto Light Level Selection
(LL)
This preference allows you to adjust the dispenser light level from
dimmest to brightest (settings 1 through 9).
NOTE: The Auto Light feature on the control center must be
selected to activate this preference.
Sabbath
Mode (SAB)
ON - All control center lights, interior lights and alarm tones will be
disabled.
OFF - All control center lights, interior lights and alarm tones will
be enabled.
NOTE: Press the door alarm touch pad for three seconds to
restore all lights.
To Access the User Preferences
Menu:
1. Press and hold the Door Alarm touch pad for three seconds.
The preference name will appear in the Freezer display and
the preference status (F or C) or (ON or OFF) will appear in the
Refrigerator display.
2. Use the Freezer (+) or (-) touch pads to scroll through the
preference names. When the desired preference name is
displayed, press the Refrigerator (+) or (-) touch pads to
change the preference status.
3. Set your preferences by pressing and holding the Door Alarm
touch pad for three seconds.
You can control the amount of humidity in the moisture-sealed
crisper. Depending on your model, adjust the control to any
setting between FRUIT and VEGETABLES or LOW and HIGH.
FRUIT / LOW (open) for best storage of fruits and vegetables with
skins.
VEGETABLES / HIGH (closed) for best storage of fresh, leafy
vegetables.
The ice maker and storage bin are located in the upper left-hand
side of the refrigerator compartment.
Turning the Ice Maker On/Off
The On/Oft switch is located on the ice maker.
To turn on the ice maker, press the switch to the ON position.
To manually turn off the ice maker, press the switch to the OFF
position.
NOTE: Your ice maker has an automatic shutoff. The ice maker
sensors will automatically stop ice production,
but the control will
remain in the ON position.
Removing and Replacing Ice Storage Bin
To Remove the Ice Storage Bin:
1. Hold the base of the storage bin and press the release button
on the lower right.
2. Pull the storage bin out until resistance is felt. Lift up the front
of the ice bin and remove.
3. Press the switch to the OFF position
To Replace the Ice Storage Bin:
IMPORTANT: It may be necessary to turn the auger driver, behind
the ice bin, counterclockwise
to properly align the ice bin with the
auger driver. The ice storage bin must be locked in place for
proper ice dispensing.
1. Press the switch to the ON position
2. Slide the ice bin into the guide rails located on either side of
the enclosure.
3. Push the ice bin in until resistance is felt. Raise the front
slightly and push the ice bin in until an audible "click" is heard.
................
All
I
L&
A. ON position
B. Auger driver
10
