Summary of Contents for Sanyo PLC-WR251 - True WXGA Projector
Page 1
Multimedia Projector Network Supported Refer to the Owner's Manuals below for PLC-WR251 details about network function. MODEL Network Set-up and Operation □ PJ Network Manager □ Owner’s Manual...
Features and Design This Multimedia Projector is designed with the most advanced technology for portability, durability, and ease of use. This projector utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display (LCD) technology. ♦ ♦...
To the Owner Before installing and operating this projector, read this Safety Precaution manual thoroughly. This projector provides many convenient features and ● WARNING: THIS APPARATUS MUST BE EARTHED . functions. Operating the projector properly enables ● TO REDUCE THE RISK OF FIRE OR you to manage those features and maintains it in good ELECTRIC SHOCK, DO NOT EXPOSE THIS condition for many years to come.
Safety Instructions All the safety and operating instructions should be read Do not install the projector near the ventilation duct of before the product is operated. air-conditioning equipment. Read all of the instructions given here and retain them This projector should be operated only from the type for later use.
Safety Instructions Installing the Projector in Proper Position Air Circulation Openings in the cabinet are provided for ventilation. To Install the projector properly. Improper Installation may reduce the lamp life and cause a fire hazard. ensure reliable operation of the product and to protect it from overheating, these openings must not be blocked Do not tilt the projector more than 20 or covered.
Model Number : PLC-WR251 Trade Name : Sanyo Responsible party : SANYO NORTH AMERICA CORPORATION Address : 21605 Plummer Street, Chatsworth, California 91311 Telephone No. : (818)998-7322 AC Power Cord Requirement The AC Power Cord supplied with this projector meets the requirement for use in the country you purchased it.
Part Names and Functions ① Infrared Remote Receiver Front ② Zoom Ring ③ Focus Ring ④ Projection Lens ⑤ Lens Cap (See page 63 for attaching.) CAUTION Do not turn on a projector with lens cap attached. High temperature from light beam may damage lens cap and result in fire hazard.
Part Names and Functions Rear Terminal ① ② ③ ⑤ ④ ⑨ ⑧ ⑦ ⑥ ⑩ ① CONTROL PORT ⑦ AUDIO OUT (VARIABLE) When the projector is controlled by a computer, Connect an external audio amplifier to this jack connect to this jack with serial control cable. (pp.14-16).
Part Names and Functions Top Control ⑨ ⑤ ⑧ ④ ⑦ ③ ② ① ⑥ ① SELECT button ⑥ MENU button – Execute the selected item (p.21). Open or close the On-Screen Menu (p.21). – Expand or compress the image in the Digital zoom mode (p.36).
Part Names and Functions Remote Control ① ON/STAND-By button Turn the projector on or off. (pp.18-20) ② AUTO SET button Execute the setting of Auto setup (includes Input search, Auto PC adj. and Auto Keystone functions) in the setting menu. (pp.23, 45) ③...
Part Names and Functions Remote Control Battery Installation Open the battery Install new batteries Replace the compartment lid. into the compartment. compartment lid. Two AAA size batteries For correct polarity (+ and –), be sure battery terminals are in contact with pins in compartment.
Installation Positioning the Projector For projector positioning, see the figures below. The projector should be set perpendicularly to the plane of the screen. Note: • The brightness in the room has a great influence on picture quality. It is recommended to limit ambient lighting in order to obtain the best image.
Installation Connecting to a Computer Cables used for connection • VGA cables (Mini D-sub 15 pin) * • Audio cables • HDMI-DVI cable (*One cable is supplied; other cables are not supplied with the projector.) Monitor Output DVI output Audio Output Monitor Output /Monitor Input External Audio Equipment...
Installation Connecting to Video Equipment Cables used for connection • Video and Audio cable (RCA x 3) • S-Video cable • Audio cable (Cables are not supplied with the projector. ) External Audio Equipment Video and Audio Output Audio Input (Video) S-Video Output Video and audio cable...
Installation Connecting the AC Power Cord This projector uses nominal input voltages of 100-120 V or 200–240 V AC and it automatically selects the correct input voltage. It is designed to work with single-phase power systems having a grounded neutral conductor. To reduce the risk of electrical shock, do not plug into any other type of power system.
Basic Operation Turning On the Projector Complete peripheral connections (with a computer, VCR, etc.) before turning on the projector. Connect the projector’s AC power cord into an AC outlet. The POWER indicator lights red. Open the lens cap (see pages 8, 63). Press the ON/STAND-BY button on the top control or on the remote control.
Page 19
Basic Operation Enter a PIN code Use the Point buttons to enter a number. Press the ▲▼ PIN Code Input Dialog Box Point button to fix the number and move the red frame ► pointer to the next box. The number changes to . If you fixed an incorrect number, use the Point button to move ◄...
Basic Operation Turning Off the Projector Press the ON/STAND-BY button on the top control or on the remote control, and Power off? appears on the screen. Press the ON/STAND-BY button again to turn off the projector. The POWER indicator starts to blink red, and the cooling fans keep running.
Basic Operation How to Operate the On-Screen Menu The projector can be adjusted or set via the On-Screen Top Control Menu. The menus have a hierarchical structure, with a main menu that is divided into submenus, which are further divided into other submenus. For each adjustment and setting procedure, refer to respective sections in this POINT buttons manual.
Basic Operation Menu Bar For detailed functions of each menu, see “Menu Tree” on pages 70-71. Main Menu Sub-Menu Input Used to select an input source from Computer 1, Computer 2, HDMI, Video or S-video (pp.27-28,37-38). PC adjust ...
Basic Operation Zoom and Focus Adjustment Rotate the Zoom Ring to zoom in and out. Rotate the Focus Ring to adjust the focus of the image. Focus Ring Auto Setup Function Auto setup function is provided to automatically execute the setting of Auto setup (includes Input search, Auto PC adj.
Basic Operation Sound Adjustment Top Control Direct Operation VOLUME+/- Volume buttons Press the VOLUME+/– buttons on the top control or on the remote control to adjust the volume. The volume dialog box appears on the screen for a few seconds. Mute Remote Control Press the MUTE button on the remote control to select On...
Basic Operation Remote Control Operation Using the remote control for some frequently used operations is advisable. Just pressing one of the buttons enables you to make the desired operation quickly without calling up the On-Screen Menu. COMPUTER 1/2, HDMI, VIDEO, S-VIDEO and Remote Control COMPONENT buttons HDMI...
Page 26
Basic Operation NO SHOW button Press the NO SHOW button on the remote control to black out the image. To restore to normal, press the NO SHOW button again or press any other button. The screen changes each time you press the NO SHOW button as follows. black out →...
Computer Input Input Source Selection (Computer 1: RGB ) Direct Operation Choose Computer 1(RGB) by pressing the INPUT button on the top control or press the COMPUTER 1 button on the remote control. Before using INPUT button, correct input source should be selected through Menu operation as described below.
Computer Input Input Source Selection (Computer 2: RGB) Direct Operation Choose Computer 2(RGB) by pressing the INPUT button on the top control or press the COMPUTER 2 button on the remote control. Remote Control Top Control INPUT button COMPUTER 2 button Computer 1 Computer 2(RGB) Computer 2...
Computer Input Computer System Selection This projector automatically tunes to various types of computers with its Multi-scan system and Auto PC adjustment. If a computer is selected as a signal source, this projector automatically detects the signal format and tunes to project a proper image without any additional settings. (Signal formats provided in this projector are shown on pages 73-74.) One of the following messages may appear when: The projector cannot recognize the connected...
Computer Input Auto PC adjustment Auto PC adjustment function is provided to automatically adjust Fine sync, Total dots, Horizontal and Vertical positions to conform to your computer. Menu Operation PC adjust Menu Auto PC adj . Press the MENU button to display the On-Screen Menu.
Computer Input Manual PC adjustment Some computers employ special signal formats which may not be tuned by Multi-scan system of this projector. Manual PC adjustment enables you to precisely adjust several parameters to match those signal formats. The projector has five independent memory areas to store those parameters manually adjusted. It allows you to recall the setting for a specific computer.
Page 32
Computer Input Reset Mode free To reset the adjusted data, select Reset and press the SELECT button. A confirmation box appears and then select yes. All adjustments will return to their previous figures. Mode free To clear the stored data, select Mode free and then press the Point or the SELECT button.
Computer Input Image Mode Selection Direct Operation Remote Control IMAGE button Select the desired image mode among Dynamic, Standard, Real, Blackboard (Green), Colorboard, Image 1, Image 2, Dynamic Image , and Image 4 by pressing the IMAGE button on the remote control.
Computer Input Image Adjustment Press the MENU button to display the On-Screen Image adjust Menu Menu. Use the Point buttons to select Image ▲▼ adjust and then press the Point ► or the SELECT button. Use the Point buttons select the desired item ▲▼...
Computer Input Store To store the adjusted data, select Store and press the Point the SELECT button. Use the Point buttons to ► or ▲▼ select one from Image 1 to 4 and press the SELECT button. A confirmation box appears and then select yes. Stored data can be called up by selecting an Image (1–4) in the Image Mode Selection on page 33.
Page 36
Computer Input Custom Adjust the screen scale and position manually with this function. Press the Point ► button at Custom and the Custom is displayed on the screen, you can use the Point ▲▼ buttons to choose the item you want to adjust. Scale H/V ..Adjust the Horizontal/Vertical screen scale. H&V ....When set to On, the aspect ratio is fixed. Scale V appears dimmed and becomes unavailable.
Video Input Input Source Selection (Video, S-video) Direct Operation Top Control INPUT button Choose Video or S-video by pressing the INPUT button on the top control or the VIDEO button or the S-VIDEO button Computer 1 on the remote control. Before using INPUT button, correct input source should be Computer 2 ...
Video Input Input Source Selection (Component, RGB Scart 21-pin, HDMI) Direct Operation Choose Computer 1 by pressing the INPUT button on the top control or press the COMPUTER button on the remote control; choose HDMI by pressing the INPUT button on the top control or press the HDMI button on the remote control.
Video Input Video System Selection AV System Menu (Video or S-video) Press the MENU button to display the On-Screen Menu. Use the Point buttons to select Input and ▲▼ then press the Point or the SELECT button. ► Use the Point buttons to select Video or S-video ▲▼...
Video Input Image Mode Selection Direct Operation IMAGE button Remote Control Dynamic Select the desired image mode from among Dynamic, Standard, Cinema, Blackboard (Green), Colorboard, Image 1, Image 2, Image and Image 4 by pressing the Standard IMAGE button on the remote control. Cinema Blackboard (Green) Colorboard...
Video Input Image Adjustment Press the MENU button to display the On-Screen Image adjust Menu Menu. Use the Point buttons to select the Image ▲▼ adjust and then press the Point ► or the SELECT button. Use the Point buttons select the desired item ▲▼...
Page 42
Video Input Sharpness Press the Point ◄ button to decrease the sharpness of the image; press the Point ► button to increase the sharpness of the image (from 0 to 15). Gamma Use the Point ◄► buttons to adjust the gamma value to obtain a better balance of contrast (from 0 to 15).
Video Input Screen Size Adjustment This projector has the picture screen resize function, which enables you to customize the image size. Screen Menu Press the MENU button to display the On-Screen Menu. Use the Point buttons to select Screen and ▲▼...
Setting Setting This projector has a Setting menu that allows you to set up Setting Menu the other various functions described below. Press the MENU button to display the On-Screen Menu. Press the Point buttons to select Setting ▲▼ and press the Point or the SELECT button to access ►...
Setting Auto setup Auto setup This function enables Input search, Auto Keystone correction and Auto PC adjustment by pressing the AUTO SETUP button on the top control or the AUTO SET button on the remote control. Settings for those functions can be altered as follows: Input search This function detects the input signal automatically.
Page 46
Setting Keystone This function is used to store or reset the keystone Keystone correction when the AC power cord is unplugged. Use the Point buttons to switch between each option. ▲▼ Store ..Keep the keystone correction even when the AC power cord is unplugged.
Page 47
Setting Logo (Logo and Logo PIN code lock settings) Logo select This function allows you to customize the screen logo with Logo select, Capture, Logo PIN code lock and Logo PIN code change functions. Note: When On is selected in the Logo PIN code lock function, Logo select and Capture functions cannot be selected.
Page 48
Setting Capture This function enables you to capture an image being projected to use it for a starting-up display or interval of Capture presentations. Select Capture and press the SELECT button. A confirmation box appears and select yes to capture the projected image.
Page 49
Setting Enter a Logo PIN code Enter a Logo PIN code Use the Point buttons to enter a number. Press the ▲▼ Point button to fix the number and move the red frame ► pointer to the next box. The number changes to “”. If you fixed an incorrect number, use the Point button to ◄...
Page 50
Setting Ceiling Ceiling When this function is set to On, the picture will be top/ bottom and left/right reversed. This function is used to project the image from a ceiling-mounted projector. Rear When this function is set to On, the picture will be left/right Rear reversed.
Page 51
Setting Picture in Picture Picture in Picture This function is used to project two videos simultaneously by placing a separate small sub screen within the main screen. (Picture in Picture combinations provided in this projector are shown on pages 75.) Only the sound on the main picture is heard, the sound on the sub picture cannot be heard.( In P in P, the big picture is main picture, and the small one is sub picture;...
Page 52
Setting Standby mode This function is available when operating the projector via network. Network ..Supply the power to the network function even after turning off the projector. You can turn on/ off the projector via network, modify network environment, and receive an e-mail about projector status while the projector is powered off.
Page 53
Setting On start When this function is set to On, the projector will be On start automatically turned on just by connecting the AC power cord to a wall outlet. Note: • Be sure to turn off the projector properly (see "Turning Off the Projector"...
Page 54
