Summary of Contents for Meinberg UA32S
- Page 1 Technical Information Operating Instructions UA32S...
- Page 2 Meinberg Funkuhren GmbH & Co. KG Lange Wand 9 D-31812 Bad Pyrmont Phone: ++49 52 81 / 9309-0 Fax: ++49 52 81 / 9309-30 Internet http://www.meinberg.de E-Mail info@meinberg.de January 16, 2007...
-
Page 3: Table Of Contents
Table of Contents General Information about DCF77 ............5 UA32S Overview ................. 7 Antenna and LF Receiver ............8 Mounting the Antenna..............8 Microprocessor Circuit ..............8 Buffered Real Time Clock ............9 Display ..................9 Control LEDs ................9 Asynchronous Serial Port ............ -
Page 5: General Information About Dcf77
General Information about DCF77 The radio remote clocks made by Meinberg receive the signal from the long wave transmitter DCF77. This long wave transmitter installed in Mainflingen near Frankfurt/ Germany transmits the reference time of the Federal Republic of Germany. This time reference is either the Central European Time (Mitteleuropäische Zeit, MEZ) or the... -
Page 7: Ua32S Overview
7-digit LED display and a time/date switch. An asynchronous serial port is available which can be used to read out information on date, time, and status. The Meinberg standard time string can be sent automatically whenever a new second begins (default) and/or the host has sent a request character. -
Page 8: Antenna And Lf Receiver
Antenna and LF Receiver An external ferrit antenna is used to receive the signal from DCF77. Optionally, a weather-proof antenna is available which can be mounted outdoor. A coaxial cable which can be up to more than 100 meters in length is used to pass the antenna's output signal to the on-board LF receiver where it is demodulated by a synchronous detector with automatic gain control. -
Page 9: Buffered Real Time Clock
Buffered Real Time Clock If the board's power supply is turned off, a gold cap capacitor on the board lets the real time clock keep time and status for typically 300 hours (150 hours minimum). This capacitor does not need any maintenance. Alternatively, the clock can be ordered with a lithium battery which has 10 years of life time guaranteed. -
Page 10: Default Configuration
Default Configuration Unless the customer has defined his own set of parameters, the radio clock UA32S is beeing shipped with default parameters: Serial Port: 9600 baud, 7E2, time string per second Optocoupler one pulse per second one pulse per 10 seconds one pulse per minutes onc pulse per 3 minutes Relay1:... -
Page 11: Customizing The Ua32S Configuration
Customizing the UA32S Configuration The chapters below describe how to configure the serial port parameters and the output switching characteristics using the byte tables in the on-board EPROM. The configurati- on parameters start address is 0E00h. All numbers are in hex notation (rsp. packed BCD), e.g. -
Page 12: Listing Of Default Configuration
Three tables WERKT1, WERKT2, and WERKT3 are available to define 3 turn-on/ turn-off cycles per output for working days (Monday through Friday) and three additio- nal tables WOENDT1, WOENDT2, and WOENDT3 for turn-on/turn-off cycles at the weekend (Saturday and Sunday). Each table has an entry for one turn-on/turn-off cycle per output. - Page 13 ; 2. Pulse every n minutes 0E09 FF MINTAB: 0FFh ; Relay 1 0E0A FF 0FFh ; Relay 2 0E0B FF 0FFh ; Relay 3 0E0C FF 0FFh ; Optocoupler 1 0E0D FF 0FFh ; Optocoupler 2 0E0E FF 0FFh ;...
- Page 14 0F12 FFFFFF 0FFh,0FFh,0FFh ; Optocoupler 1 ON 0F15 FFFFFF 0FFh,0FFh,0FFh ; Optocoupler 1 OFF 0F18 FFFFFF 0FFh,0FFh,0FFh ; Optocoupler 2 ON 0F1B FFFFFF 0FFh,0FFh,0FFh ; Optocoupler 2 OFF 0F1E FFFFFF 0FFh,0FFh,0FFh ; Optocoupler 3 ON 0F21 FFFFFF 0FFh,0FFh,0FFh ; Optocoupler 3 OFF 0F24 FFFFFF 0FFh,0FFh,0FFh ;...
- Page 15 0F72 FFFFFF 0FFh,0FFh,0FFh ; Optocoupler 3 ON 0F75 FFFFFF 0FFh,0FFh,0FFh ; Optocoupler 3 OFF 0F78 FFFFFF 0FFh,0FFh,0FFh ; Optocoupler 4 ON 0F7B FFFFFF 0FFh,0FFh,0FFh ; Optocoupler 4 OFF ; 1. On/Off cycles for weekend (Saturday and Sunday) 0F7E FFFFFF WOENDT1: 0FFh,0FFh,0FFh ;...
- Page 16 ; 3. On/Off cycles for weekend (Saturday and Sunday) 0FD2 FFFFFF WOENDT3: 0FFh,0FFh,0FFh ; Relay 1 ON 0FD5 FFFFFF 0FFh,0FFh,0FFh ; Relay 1 OFF 0FD8 FFFFFF 0FFh,0FFh,0FFh ; Relay 2 ON 0FDB FFFFFF 0FFh,0FFh,0FFh ; Relay 2 OFF 0FDE FFFFFF 0FFh,0FFh,0FFh ;...
-
Page 17: Setting The Clock Manually
Technical Specifications UA32S RECEIVER: Synchronous demodulator with automatic gain control bandwidth: approx. 50Hz ANTENNA: Active external ferrite antenna in a plastic case Length of the cable: up to more than 100m Standard version: SMB type connector, 5m of RG174 cable Outdoor version: N type connector, RG58 cable, adapter RG58/RG174 RF AMPLITUDE,... - Page 18 MODE OF OPERATION: time string transmitted automatically once per second, or after request character '?' has been received OUTPUT STRING: Meinberg standard time string CONNECTORS: 32 pin rear VG edge connector DIN 41612 Subminiature coaxial RF connector (SMB type) POWER SUPPLY:...
-
Page 19: Ce Label
CE Label This device conforms to the directive 89/336/EWG on the approximati- on of the laws of the Member States of the European Community relating to electromagnetc compatibility. -
Page 21: Component Layout
Component Layout... -
Page 23: Ua32S Connector Pin Assignments
UA32S Connector Pin Assignments VCC in (+5V) VCC in (+5V) REL_3A_off REL_3A_on REL_3A_com REL_3B_com REL_3B_off REL_3B_on REL_2_com REL_2_on REL_1A_off REL_1A_on REL_1A_com REL_1B_com REL_1B_off REL_1B_on OPTO_1_Collector OPTO_1_Emitter OPTO_2_Collector OPTO_2_Emitter OPTO_3_Collector OPTO_3_Emitter OPTO_4_Collector OPTO_4_Emitter COM0 TxD out COM0 RxD in...
