CentaurStat 1
User Operating Instructions
Central Heating Programmable Room ThermoStat
The Horstmann CentaurStat 1 is a programmable room thermostat that
provides precise temperature control from a single point with up to 6
different temperature settings possible over a 24 hour cycle. Temporary
temperature adjustments can be made by means of the temperature
override buttons on the front of the unit.
1

Advertisement

Table of Contents
loading

Related Manuals for Horstmann CentaurStat 1

Summary of Contents for Horstmann CentaurStat 1

  • Page 1 User Operating Instructions Central Heating Programmable Room ThermoStat The Horstmann CentaurStat 1 is a programmable room thermostat that provides precise temperature control from a single point with up to 6 different temperature settings possible over a 24 hour cycle. Temporary temperature adjustments can be made by means of the temperature override buttons on the front of the unit.
  • Page 2 The CentaurStat 1 Programmable ThermoStat The simple instructions contained in this user guide are designed to help with the programming and operation of the unit. Located under flap SET indicator SET positions SET button OVERRIDE (MINUS) button OVERRIDE (PLUS) button ENTER button Time or current temperature display Target temperature...

  • Page 3: Target Temperature Lock

    Manual Overrides Target Temperature Override The CentaurStat Use the PLUS and will operate on Ensure the SET MINUS buttons   indicator is in the this new setting to increase or normal RUN position until the next time decrease settings period Where an override temperature has been set, this altered setting will remain until the next time and temperature setting is reached.

  • Page 4: Setting The Time Of Day

    Setting the Time of Day Press the SET Press the SET Use the PLUS button until button until SET and MINUS Press    indicator is next SET indicator is buttons to ENTER to clock position returned to the adjust the time on the display RUN position...
  • Page 5 Changing the Times and Target Temperatures Press the SET button until SET indicator is next to the PROG position The time setting for the 1st period will now flash. Use the PLUS and MINUS buttons to alter the start time if required Press ENTER The target temperature setting for the 1st period will now flash.

  • Page 6: Battery Replacement

    Reducing the Number of Time and Temperature Settings To reduce the number of temperature settings available in a day from six to four, proceed as follows: Set the 3 and 4 period temperatures to the same temperature as set on period 2. Periods 1 and 2 will now operate as normal.

  • Page 7: Battery Replacement Diagrams

    Resetting the CentaurStat Electronic equipment can in some circumstances be affected by electrical interference. If the programmer’s display becomes frozen or scrambled; or if you wish to revert back to the default time settings please use the following procedure. Lower the flap and press the SET and ENTER buttons together, release the buttons and the CentaurStat will return to preset factory default time settings.
  • Page 8 Programmable room thermostats need a free flow of air to sense the temperature, so they must not be covered by curtains or blocked by furniture. Nearby electric fires, televisions, wall or table lamps may prevent the thermostat from working properly. Email: sales@horstmann.co.uk Website: www.horstmann.co.uk Horstmann Controls Limited, Bristol BS4 1UP Leaflet number P82161 – Issue 2...
