P8H61-M2 series specifications summary

CPU
Chipset
Memory
Expansion slots
Graphics
Storage
LAN
LGA1155 socket for Intel
Core™ i5 / Core™ i3 Processors
Supports 32nm CPU
Supports Intel Turbo Boost Technology 2.0
®
* The Intel Turbo Boost Technology 2.0 support depends on the
®
CPU types.
** Refer to www.asus.com for Intel
Intel H61 Express Chipset
®
Dual-channel memory architecture
- 4 x 240-pin DIMM sockets support unbuffered non-ECC
DDR3 1333/1066MHz memory modules
- Supports up to 16GB* system memory
- Support Intel Extreme Memory Profile (XMP)
®
* Hyper DIMM support is subject to the physical
characteristics of individual CPUs. Some hyper DIMMs only
support one DIMM per channel. Refer to Memory QVL for
details.
** Refer to www.asus.com for the Memory QVL (Qualified
Vendors Lists).
*** When you install a total memory of 4GB capacity
or more, Windows
recognize less than 3GB. We recommend a maximum
of 3GB system memory if you are using a Windows
32-bit operating system.
1 x PCI Express 2.0 x16 slot
1 x PCI Express 2.0 x1 slots
2 x PCI slot
Integrated Intel HD Graphics
®
- Supports single link DVI with max. resolution up to 1920 x
1200 @60Hz
- Supports D-Sub with max. resolution up to 2048 x 1536
@75Hz
- Supports DirectX 10.1
- Hardware Decode Acceleration for H.264, VC-1, and MPEG-2
Intel H61 Express Chipset:
®
- 4 x Serial ATA 3Gb/s ports (blue)
Realtek 8111E Gigabit LAN controller
®
(continued on the next page)
Second Generation Core™
®
CPU support list.
®
32-bit operating system may only
®
®
ix
